7) The rotary switch set value of above number of indoor units which is
connected with FF and prevents a malfunction.
(Example: The case where 3 indoor units is connected in piping 1,
sets from rotary switch 0,1,2 and 3,4,5,6,7 with FF set)
- Prerequisite for manual valve addressing: central control address of
each indoor unit must be preset differently at its wired remote
control.
No. Display and setup
- Operation: None
7-SEG SW01M
1
0
- Display: None
SW03M SW04M
SW05M
- Operation : Turn DIP S/W No.1 on to
address valve #1
7-SEG SW01M
2
0
- Display : Existing value saved in
EEPROM is displayed in 7-SEG.
SW03M SW04M SW05M
- Operation : Set the digit of 10(1) to the
number in Group High data of the wired
remote control connected to the
7-SEG SW01M
corresponding indoor unit to the valve #1
3
0
by pressing left tack S/W.
- Display : Digit increasing with the times
of pressing tack S/W is displayed in left
SW03M SW04M SW05M
7-SEG.
- Operation : SW05M : 1
7-SEG SW01M
4
- Display : Display former value.
SW03M SW04M SW05M
- Operation : Setting No. using SW03M
7-SEG SW01M
and SW04M, SW05M : 1
5
- Display : Display setting value.
SW03M SW04M SW05M
- Operation : Turn DIP S/W No.1 off to
save the address of valve #1
7-SEG SW01M
6
- Display : "11" displayed in 7-SEG
disappears.
SW03M SW04M SW05M
- Operation : Return valve of addressing
7-SEG SW01M
HR unit.
7
0
- Display : None
SW03M SW04M SW05M
- Above setup must be done for all HR unit valves.
- The valve that is not connected with any indoor unit should be
addressed with any other number than used address numbers of the
valves connected with indoor units.(The valves does not work if the
address numbers are same.)
Method of checking the pipe detection result
at HR unit
In case that an indoor unit of central control address "11" is connected to a
valve #1 of an HR unit
No. Display and setup
- Operation: Turn DIP S/W No.1 on.
1
- Display: "11" is displayed in 7-SEG
7-SEG SW01M
- Operation: Turn DIP S/W No.1 off.
2
- 7-SEG disappeared
7-SEG SW01M
Setup and Contents
Setup and Contents
Identification of Manual Valve ID (Address)
No. Display and setup
- Operation: more than 2 DIP switches
turned on.
1
- Display: "Er" is displayed in 7-SEG
7-SEG SW01M
Method of checking the pipe detection result
at outdoor unit
1) Wait for 5 minutes, after Pipe detection is completed.
2) Turn on the No.10,14,16 DIP S/W of SUB PCB at outdoor unit
3) Check the data on 7- segment, switching rotary 01,02.
ROTARY 01 ROTARY 02

Setting method of Master indoor unit in zoning

1 Turn DIP switch 5,6,10 on at system off.
2 Set the left Rotary switch for HR unit. (Rotary switch No. "0" HR unit
No. "1")
3 Set the right Rotary switch for IDU unit. (Rotary switch No. "0" HR
unit branch No. "1")
4 Display the Master IDU No. of the HR unit on 7segment. (Default
display is "00" on 7segment)
5 Press the black button. (The IDU No. increase every 1 second in the
zoning)
6 Set the Master IDU (Press the red button during 1.5 seconds stop
twinkling)
ROTARY 01 ROTARY 02
CAUTION
!
• Waiting for 80 seconds after power on.
• The zoning information and Master IDU information remove from
EEPROM after Auto-addressing.
• If there is installed the central control, it is impossible setting of
Master IDU in zoning.
Setting the function
Select the mode/function/option/value using '▶', '◀' Button and
confirm that using the '●' button after DIP switch No.5 is turned on.
7-Segment
SW01C ( :confirm)
SW02C ( :backward)
SW03C ( :forward)
27
Setup and Contents
The connected port number of
HR unit
The connected HR unit number
The auto addressing number of
indoor unit (digit of 1)
The auto addressing number of
indoor unit (digit of 10)
No. of Indoor unit.
No. of HR unit branch.
No. of HR unit.
SW01D (reset)
SW04C (x:cancel)
DIP-SWITCH
