BOARD COMPONENTS
Label Description
X2 SocketModem, USB Connector.
X3 SocketModem, GPIO (not connected).
X4 SocketModem Serial Connector.
X5 SocketModem Power Connector.
X6 Arduino Shield Connector.
X7 Arduino Shield Connector.
X8 Arduino Shield Connector.
X9 Arduino Shield Connector.
X10 MTDOT Connector.
X11 MTDOT Connector.
J12 MTDOT Programming Header.
CAUTION: Take care when connecting or disconnecting USB cables to avoid detaching the connector from the
board.

LED Indicators

Label
STAT
COM
D7
D4
D5
D8
D6
D3
D0
D1
LS
RST
PWR
D2
8
LED Location
LED1 Near JP198
LED2 Near JP198
LED3 Above the SMC-USB connector
LED4 Above the SMC-USB connector
LED5 Above the SMC-USB connector
LED6 Above the SMC-USB connector
LED7 Above the SMC-USB connector
LED8 Above the SMC-USB connector
LED9 Above the SMC-USB connector
LED10 Above the SMC-USB connector
LED11 Above the SMC-USB connector
LED12 Above the SMC-USB connector
LED13 Above the SMC-USB connector
LED14 Above the SMC-USB connector
