INSTALLATION AND OPERATION
Installing an Arduino Shield with a SocketModem
If using an Arduino Shield with a SocketModem:
1.
Move jumpers for JP98 as follows:
2.
Mount the MTSMC device on the Arduino shield as shown in the following image.
3.
Connect the Arduino Shield to the developer board.
16
Move Jumper 3-4 to Jumper 5-6
Move Jumper 7-8 to Jumper 9-10
Universal Developer Kit 2.0 MTUDK-ST-Cell Developer Guide
