Pressure
ATTENTION: Always open the gate away from the dangerous position, to avoid dangerous
installation
Step 1
Place the gate compartments (a) and (b) flush next to each other so that there is no gap.
Only push the gate compartments far enough apart so that the gate compartment (a) has a
distance of exactly 28 mm between the last gate slat and the wall or door surface and the gate
compartment (b) has a distance of min. 30mm - max. 63 mm between the last gate slat and the
wall or the door surface. Ill. 1
Screw both of the gate compartments (a) and (b) respectively to each other at the top and the bottom.
For this purpose, insert the connection screws (i) in the drilled holes and tighten firmly with the screw
sleeves (j) from the other side. Ill. 2 and Ill. 3. Tighten the screws slightly with a Phillips screwdriver.
Check if both of the gate compartments are tightly attached to each other.
Step 2
Attach the Adjustment screws (c) to the top and the bottom of the gate compartment (b). Ill. 20 and
Ill. 21 Before attaching the Adjustment screws, nuts (e), insert the horizontal slats of the gate
compartment (b) in the provided slits on the top and bottom on the sides. Ill. 20 and Ill. 21
Step 3
Pull the lower adjustment screws on both sides of the door gate out evenly until they touch the
mounting surface, Ill.23 and Ill.25
Set the position of the adjustment screw using the setting wheels.
Step 4
Open the closure by pressing the 2 buttons on both sides of the handle gently and simultaneously,
Adjustment of the lift the handle. Ill. 13
adjustment screws Only pull out the adjustment screw until the distance between the attachment surface and the
on the gate adjustment screw is 7 - 8 mm. Ill. 14
compartment (a)
situations! The amount the safety gate is opened can be limited by installing
the stopper (n), which comes with the gate. (Step 5)
