Step 4
Open the handle by pressing the 2 buttons on both sides of the handle gently and
simultaneously, lift the handle. Ill. 13
Adjustment of the
Only pull out the adjustment screw until the distance between the attachment surface and
adjustment screws
the adjustment screw is 7-8 mm. Ill. 14
on the gate
compartment (a)
In order to limit the opening direction, installation of the stopper (n) is optional.
Optionally, the stopper (n) can be inserted either on the left or right. Mount the stopper (n) on the
desired side of the clamp shell (fa, fb). Ill. 6 and Ill. 7
Mark the positions of the clamping shells (fa, fb) on the top and the bottom, Ill. 15. Screw the
holding cups with the wooden mounting screws (k) tight onto the wall.
Remove the gate from the hinges and screw the hinge bolts (d) out of the gate compartment B
(b) until the distance between the non-extended pressure foot of the gate compartment A (a) and
the attachment surface is exactly 8 mm. Ill. 16
You may need to try several times.
Mark the position of the clamping shell (fa, fb) between the pressure foot and the attachment
surface. Screw the holding cups with the wooden mounting screws (k) tight onto the wall. Ill.17
ATTENTION: Ensure that the pressure foot is firmly on the floor.
Put the gate back on the hinges.
Mount upper hinge parts (g), see Ill. 18 and Ill. 19
Handling the door gate
To lift the handle, gently press both buttons simultaneously. Lift handle gently from the back /
bottom. If the buttons are pressed too hard, this complicates lifting the handle. Lift gate, remove
from the support shells and swing to the side.
When closing the door, ensure that the pressure foot below and the adjustment screw at the top
are positioned correctly in the support shells when the closure handle is lowered.
