VITRA V-Care Manual

Smart panel
Hide thumbs Also See for V-Care:

Advertisement

Quick Links

Download this manual
B a t h r o o m A p p l i a n c e

Advertisement

loading
Need help?

Need help?

Do you have a question about the V-Care and is the answer not in the manual?

Questions and answers

Marie-Christine Grenham
April 11, 2025

How do you descale Vitra smart toilet

0
1 comments:
Mr. Anderson
April 11, 2025

To descale the Vitra V-Care smart toilet:

1. Open the toilet lid and seat.
2. Put on the water shield included in the V-Care package.
3. Press and hold the water temperature and seat temperature buttons on the remote control for 3 seconds. A beep will signal the start of the decalcification process.
4. When it finishes, the remote will beep twice.
5. Open the decalcification cover and pour in Durgol descaler liquid using the provided funnel.
6. Remove the funnel, close the cover, and wait three minutes.
7. The system will perform a 40-second rear wash, 40-second female wash, and nozzle cleaning.

This answer is automatically generated

0
Dr I G Simmons
March 21, 2025

left side panel shows red light (not original green light) when on. Paperwork no indication of how to troubleshoot.

0
1 comments:
Mr. Anderson
March 21, 2025

The provided context does not mention a red light issue on the VITRA V-Care left side panel. However, it does provide troubleshooting steps for different LED indicators and error codes. If the issue involves an LED light on the left side panel, check the troubleshooting section for relevant symptoms, such as power or washing function issues, and follow the suggested steps:

1. Ensure there is no power outage.
2. Press the STOP/POWER button for 3 seconds.
3. Verify that the power switch is turned on.
4. Check if the waterproof connector is properly connected.
5. Make sure you are seated properly on the unit.
6. Inspect the remote control’s battery and signal transmission.
7. Confirm that temperature adjustments are turned on.

For error codes with LED indicators, refer to the error code explanations and contact authorized service if necessary.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for VITRA V-Care

Summary of Contents for VITRA V-Care

  • Page 1 B a t h r o o m A p p l i a n c e...
  • Page 3 C O N T E N T S Quick Start User Guide...
  • Page 4 V-Care Smart Panel Optimised usage The V-Care Smart Panel prepares reports to support sustainability and raise awareness of water usage. It also relays local announcements such as water- and power shortages or cuts, allowing you to better manage the flushing systems.

  • Page 5: Mobile App

    The mobile app proffers the user optimum functionality and performance. Connectivity Secure pairing between the control panel and the mobile app over wi-fi prevents misuse, ensuring only one user is paired at any one time. The V-Care Smart Panel software is always updated through an internet connection.
  • Page 6 V-Care Smart Panel Create VitrA Download Pair your device user account The V-Care Smart Panel Following creating user For additional benefits such Mobile App is available for account, mobile app directs as ease of use, comfort and IOS and Anroid platforms.
  • Page 7 V-Care Smart Panel Usage statistics for weekly and monthly reports Wellcome Weekly Weekly & Weekly & Weekly & Report Weekly Weekly Monthly Comparison Comparison Reports Reports Reports Usage statistics for weekly and monthly reports • Number of half and full flushes, and the volume of water used •...
  • Page 9 U s e r G u i d e...

  • Page 10: Installation

    Installation For installation, please check out the Installation Manual flyer in the package. Sticker A temporary transparent sticker on V-Care Smart Panel expresses the functions of buttons for easy to start. After a while, you can remove it. Care instructions How to clean the panel? •...
  • Page 11 Panel features Smart Panel is at stand-by mode with VitrA logo illumination as a night light feature in case of not used for a while. The function buttons are hidden as in the below image. After user detection, Smart Panel awakes...
  • Page 12 Functions of Smart Panel Full Half Warning Flush Flush Menu Auto Lock Periodic Flush Flush Connectivity...
  • Page 13 Connectivity: Secure pairing between the control panel and the mobile app over wi-fi prevents misuse, ensuring only one user is paired at any one time. The V-Care Smart Panel software is always updated through an internet connection. Lock: The Lock feature allows the user to deactivate the panel when required for maintenance or security reasons.
  • Page 14 The application is available for Android and iOS devices to access remotely to Smart Panel. Please go to your smart phone’ s application store to download V-Care Smart Panel mobile application and then follow the directives given by mobile application to connect the panel.
  • Page 15 Technical specifications Product Model Name Name DC Working 6.6VDC Voltage Max.Power Consumption Product Size 159 x 238x 45 Weight 860 gr IP Rating IP67 (Water and dust proof) Glass Type Tempered Button Type Capacitive Touch Sensor Type Optical Proximity Bluetooth Connectiviy Wifi 802.11b/g/n...

  • Page 16: Troubleshoot

    Troubleshoot Warning Type Symptom Cause Remedy A power shortage The back-up power may occur. Back-up supply unit will be power supply unit Power Device has no power charged automatically may also run out after power shortage due to long duration ends up.

  • Page 17: Warranty

    Compliance with WEEE Regulation and Disposal of The Waste Product This product does not contain harmful and forbidden materials described in the “Directive on the Restriction of the Use of Certain Hazardous Substances in Waste Electrical and Electronic Equipment” (EEE) issued by the T.R. Ministry of Environment and Urbanization. Complies with the WEEE Directive.
