Modulex MMP-080S/5H Installation Manual page 2

Installation Guide Lighting Fixture
Tracklight
MMP-080S/5H/1N/10B/Z2/3
Installation Details Installation Diagram
Attaching luminaire to track
1 Lower the cover of the power
supply box cover
2 Turn the lever to the left
(turn off the power)
3 Insert luminaire into track
Insert the luminaire surely into
the track.
There is a danger of falling
if there is incompleteness.
lever
4 Turn the lever to the right
(turn on the power)
Turn lever securely to the "ON"
position.
Failure to do so may
cause a fall or fire. cover
lighting track
5 Raise the cover of the power supply
box
If you can not raise the cover,
there is a possibility that
the luminaire is not securely fixed.
Please try installing again.
e Do not install on walls and floor.
Adjustment of irradiation direction
Range of movement
Grasp the fixture and adjust
1
the irradiation direction
Do not forcibly move beyond
the movable range
Please adjust the fixture after
turning off the power and
cooling the fixture
Caution
FOR USE WITH NORDIC ALUMINIUM INC,
Series XTSC 6, TRACK SYSTEM ONLY.
NORDIC ALUMINIUM lighting track is sold separately.
This fixture can be attached to the 3 circuitrails,
but only 1 circuit can be used for power supply.
Please do not attach the fixture to the 3 circuitrails
in which more than 1 circuit are occupied
for power supply. It may cause tripping the circuitbreaker.
The terminals are connected internally
as shown in the right circuit diagram.
2
1
Lever position indication
e
4
×wall
5
×floor
10°
90°
380°
Installation Details
Optional parts installation
Turn around the body.
1
Pull out the body from the hood.
2
3 Turn around the option holder,
and put out .
4 Put a filter in hood.
5 Turn around the option holder,
L2
L1
and put in.
DA(-) DA(+)
L3 N
Please attention that
the sharpener lens is counted
two pieces of filter lenses.
Donʼt put in the filters than
f
the rule number of pieces.
Causes of falling and damage.
d Align the markings of the hood
and the body, please turn it
clockwise until it clicks.
Tilting angle setting
Please loose a screw by the
1
hexagonal wrench,and unrock.
Please regulate a point of view
to a scale.
Please use an attached hexagon
wrench by all means.
（Contact）
Concord Lighting
5/F, Longbow House,14-20 Chiswell Street, London, EC1Y 4TW, UK
Tel : +44-01273-616649
Installation Diagram Caution
Body
UP to 2FILTERS
1
2
Hood
Option
Holder
3
Sharpner
Filter
lends
Pan lock
Tilt lock
（Manufacturer）
ModuleX Inc.
#21 AraiBldg, 1-20-6 Ebisu-Minami Shibuya-ku, Tokyo
Tel : +81-3-5768-3131
To install ModuleX safety
f
Option
Holder
Sharpner
lends
d
