SMART MODE
10
In this mode, the appliance will choose the fan
speed automatically, based on the air quality level.
This is the default mode each time the appliance
is turned on.
NOTE: In "SMART" mode the fan speed cannot be
changed manually.
About the Air quality light
11
The appliance has an air quality sensor that
analyzes the air quality.
The air quality light will show the real-time air
quality through different colors of light. As shown
below:
LIGHT'S COLOR
PM 2.5 (μg/m
Green
0-12
Yellow
13-35
Orange
36-55
Red
56-150
Purple
151-250
Maroon
>250
NOTE: It will take about 10 seconds for the sensor
to analyze the air quality each time the appliance
is turned on. During this time, the air quality light
will pulsate slowly in white.
Very high humidity conditions in the room might
produce condensation in the sensors. This could
affect the accuracy of the sensor readings.

MANUAL MODE

12
Tap the "MODE" button to switch the appliance to
"MANUAL" mode. In this mode, the fan speed can
be changed manually by touching the Fan speed
slider.
NOTE: The fan speed will change gradually after a
new fan speed is selected.
WIFI FUNCTION
13
This appliance is equipped with a WiFi module,
which enables remote control and access to the
full functionality of the system via our smartphone
app. Download our Wellbeing App and follow the
instructions for how to connect it with your
appliance. When the connection is stablished, the
WiFi indicator will light up.
CHILD LOCK FUNCTION
14
The Child lock can be activated and deactivated
by long pressing the On/Off and the Mode button
simultaneously for 4 seconds. This function can
also be activated or deactivated via the Wellbeing
App. When the Child lock is activated, the control
panel of the appliance cannot be interacted with
and the Child lock indicator light up.
10
3
)
AIR QUALITY
Very Good
Good
Poor
Very Poor
Bad
Very Bad
FILTER CHANGE INDICATOR
15
The filter change indicator will light up to remind
you to change the filter. Refer to the instructions
in the Wellbeing App or the Electrolux website on
where to purchase replacement filters. Ensure
the plastic protective bag is removed from the
replacement filter before use. After the filter is
replaced, the filter change indicator will turn off
automatically.
NOTE: The multi-layer filter cannot be washed, it
can only be replaced.
IONIZER FUNCTION
16
The ionizer function can only be activated and
deactivated by using the Wellbeing App (smartphone
application). When this function is activated,
the ionizer indicator lights up and the appliance
generates ions to improve the unit's performance
and with it the room's air quality.
SCHEDULE FUNCTION
17
In the Wellbeing App (smart phone application) you
can set different schedules, for example that the
fan speed goes down during night time and then
goes back to normal speed during day time. When
a schedule is set, the schedule indicator on the
appliance will light up.
CARE AND CLEANING
Unplug the appliance before cleaning to prevent
shock or fire hazards.
18
The plastic parts of the appliance may be cleaned
with an oil-free dry cloth or by using a vacuum
cleaner with a soft brush.
19
The fabric on the appliance cannot be removed.
Clean the fabric by using an oil-free dry cloth or a
vacuum cleaner with a soft brush.
20
Dust accumulated in the Air quality sensor can
result in incorrect sensor readings and affect
performance. Use a vacuum cleaner with a soft
brush to remove any dust that might accumulate
in this area. Vacuum at least monthly.
21
Never use abrasive, harsh cleaners or wax when
cleaning the unit.
22
NOTE: The multi-layer filter can not be washed, it
can only be replaced.
CAUTION! Do not touch the fan blade when
removing the multi-layer filter.
Storage
23
If you are not planning to use the appliance for
a long time, cover it with plastic or return it to its
carton.
Enjoy a great cleaning experience with your
Electrolux air purifier AX9-40/ AX9-60!
Electrolux reserves the right to change products,
information and specifications without notice.
