At a glance
The following diagrams explain each part of the infrared interior camera.
V out (Front camera
connection port)
The illumination sensor detects when it is dark and activates the IR LEDs for optimal
interior recording.
4
BLACKVUE
Mounting bracket
67.4 mm
Camera lens
Illumination sensor
IR LED
Security LED
: Stays ON in all
recording modes.
