Summary of Contents for Montarbo W17As
- Page 1 W17As connection examples Parallel connection of two or more W17As always use balanced shielded cables W17As W17As W17As W17As W17As W17As W17As W17As MIXER MIXER MIXER L/R OUTPUTS W17As INPUTS W17As OUTPUTS INPUTS of other W17As...
- Page 2 W17As connection examples Two W17As + one active subwoofer always use balanced shielded cables W17As W17As W17As W17As Montarbo Montarbo active subwoofer active subwoofer MIXER MIXER MIXER L/R OUTPUTS SUBWOOFER L/R INPUTS SUBWOOFER L/R X-over OUTPUTS W17As INPUTS...
- Page 3 W17As connection examples Two W17As + two active subwoofers always use balanced shielded cables W17As W17As W17As W17As Montarbo Montarbo Montarbo Montarbo active subwoofer active subwoofer active subwoofer active subwoofer MIXER MIXER MIXER L/R OUTPUTS SUBWOOFERS 'R/mono' INPUTS SUBWOOFERS 'R' X-over OUTPUTS...
