- Page 1 FR-A350 EZ(B,S) SERVICE MANUAL RADIO RECEIVER This Service Manual is the “Revision Publishing” and replaces “Simple Manual” FR-A350 EZ<B>(S/M Code No.09-995-331-3T1). S/M Code No. 09-995-331-3R1...
-
Page 2: Specifications
SPECIFICATIONS Power source AC 230 V, 50 Hz Output 280 mW (EIAJ) Power consumption Speaker 57 mm, 8 ohms Frequency range FM : 87.5 - 108 MHz AM : 530 - 1,605 kHz Antennas FM wire antenna Ferrite bar antenna for AM Dimensions (W x H x D) 124 x 126 x 160 mm (5 x 5 x 6 in.) -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION S2-10A-063-A00 AM ANT COIL S2-24A-032-A00 AM OSC COIL 7-7-2 A106 87-A21-201-010 IC,LM8560(CLOCK) S2-14A-034-A00 CHOKE COIL 47UH TYPE 4-6 S2-516-191-000 IC,CXA1619AS(RF+1F+AUDIO) S2-01A-001-A00 LED DISPLAY(0.3) S1-87A-002-A00 IC,MC74HC4060N PT51 S4-07A-005-A00... - Page 4 SCHEMATIC DIAGRAM _ 1 MAIN C.B...
- Page 5 WIRING - 1 MAIN C.B PVC1...
- Page 6 WIRING - 2...
-
Page 7: Chip Parts
WIRING - 3 QUARTS C.B R59 R54 DISCRETE PARTS CHIP PARTS (PARTS SIDE VIEW) (PATTERN SIDE VIEW) -
Page 8: Ic Block Diagram
IC BLOCK DIAGRAM IC,LM8560 IC,CXA1619S... -
Page 9: Electrical Adjustment
ELECTRICAL ADJUSTMENT... -
Page 10: Practical Service Figure
PRACTICAL SERVICE FIGURE ELECTRICAL ADJUSTMENT <AM SECTION> 1. AM IF Adjustment Sensitivity Less than 49 dB (600 kHz) Setting : • Test point : TP1, 2(IN), TP8, 9(OUT) (S/N 10dB) Less than 46 dB (1000/1400 kHz) T2 ..... 450 kHz S/N (Input 60dB) Less than 21 dB (600 kHz) Less than 24 dB (1000/1400kHz) -
Page 11: Mechanical Exploded View
MECHANICAL EXPLODED VIEW - 1/1 SPEC LABEL SCREW SPEAKER SCREW SHIELD POWER PLATE CORD SCREW SCREW PLATE... -
Page 12: Mechanical Parts List
MECHANICAL PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION 1 S6-73A-042-A00 TOP CABINET<350EZ<B>> 1 S6-73A-043-A00 TOP CABINET<350EZ<S>> 2 S6-74A-050-A00 BOTTOM CABINET<350EZ<B>> 2 S6-74A-051-A00 BOTTOM CABINET<350EZ<S>> 3 S6-87A-086-A00 DIAL LENS 4 S6-97A-017-A00 BATTERY COVER<350EZ<S>> 4 S6-97A-011-A00 COVER BATTERY<350EZ<B>> 5 S6-12A-050-A00 BRACKET LED 6 S7-08A-053-A00 TUNING KNOB<350EZ<S>>... -
Page 13: Accessories List
ACCESSORIES LIST REF. NO PART NO. KANRI DESCRIPTION 1 S8-00A-279-A00 INSTRUCTION BOOK(B) 1 S8-00A-280-A00 INSTRUCTION BOOK(C) 1 S8-00A-278-A00 INSTRUCTION BOOK8A) - Page 14 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 Printed in Singapore 931196...
