CONTENTS PAGE 1 - USER TERMINAL AND RADIO-FREQUENCY REMOTE CONTROL 2 - CLOSE-UP OF DISPLAY TERMINAL SCREENS 3 - MEANING OF SYMBOLS 4 - INSTALLATION PARAMETERS 5 - DIAGNOSTIC 6 - AIR TEMPERATURE MEASUREMENT 7 - SPECIFICATIONS OF SENSORS USED BY THE V3000 8 - WATER TEMPERATURE MEASUREMENT 9 - CONTROL ALGORITHM 10 - CONNECTING THE FRAME CONTACT...
Page 4: User Terminal And Radio-Frequency Remote Control
1 - USER TERMINAL AND RADIO-FREQUENCY REMOTE CONTROL Display terminal Radio-frequency Remote control Flush-mounted terminal Dial terminal  Display: - This continuously displays the temperature detected by the sensor, the current operating mode, the chosen ventilation speed, and any alarm present. ...
Page 5: Close-Up Of Display Terminal Screens
2 - CLOSE-UP OF DISPLAY TERMINAL SCREENS Display of temperature measured in Displays the parameter values in % from the room controller set-up menu Temperature unit Bar graph of setpoint offset Delayed comfort mode Heating active Off for Economy/Standby/or Cooling active Frost protection modes, depending on set-up Alarm:...
Page 6: Installation Parameters
4 - INSTALLATION PARAMETERS To modify the installation parameters, a display terminal is essential (wall-mounted display terminal, flush-mounted display terminal or radio remote control terminal). To enter set-up mode, you need to simultaneously press the standby , ventilation buttons for 5 seconds, then press button twice, and finally the standby button for 5 seconds.
Page 7 Parameter Name Explanation Setting range Default value Control sensor selection Temperature sensor selection (if Depending on 0 = Return sensor priority recycled air application) application 1 = Indoor environment sensor priority Correction factor for sensor S1 (return or supply air sensor, Sensor S1 calibration -9.9…+9.9 resol.
Page 8: Diagnostic
Parameter Name Explanation Setting range Default value If an electric heater is used, the power (in kW) must be indicated Heating electrical power (based in this parameter, rounded up to the nearest 100W. Used for 0…20,0 résolution de 0,1 on 230 V) certain energy consuming applications The low speed ventilation power must be indicated in this 5…990...
Page 9 Diagnostic Name Explanation 1 = Recycled air sequence Application type 2 = Fresh air sequence 1 = Room control without supply air limiting Function to limit the temperature of 2 = Room control with supply air limiting blown air. 3 = Control at constant supply air temperature 1 = 3 points 2 = On/off Type of valve motor, fan coil...
Page 10 Certain problems may be resolved by checking some fundamental points. Check using the list below before requesting servicing. N.B.: When the controller is switched on, control will only take effect after a few minutes of system initialisation. If you have a display terminal, this displays its version number (e.g. 101) for around 5 seconds after switching on. Upon a mains power cut: 1.
Page 11 Faults are automatically released once the problem related to the fault is resolved (sensor replaced…). *Only the "Filter" fault requires manual release - to do so: - replace or clean the filter - In the Diagnostic menu, access d19 "Filter maintenance time meter" - Set this meter to 0 by pressing and holding the button for 5 seconds.
Page 12: Air Temperature Measurement
6 - AIR TEMPERATURE MEASUREMENT ● Parameter P24 Diagnostics d08, d09 The V3000 offers the possibility of controlling the air temperature via a return sensor or an indoor environment sensor (P24). If you can choose between the two, it is preferable to opt for the indoor environment sensor, since it provides a better picture of the room temperature.
Page 13: Control Algorithm
Diagnostic d11: - If the controller is working based on its changeover sensor wired to S2 and C, d11 indicates the temperature read by this sensor. - If the controller is working based on an On-off contact wired to S2 and C, or based on information from the centralised changeover - d11 indicates 127°C if D2/C is shunted or centralised changeover = hot water.
Page 14: Connecting The Frame Contact
● Universal inputs The V3000 controller is equipped with 2 configurable potential free inputs. These 2 inputs D1-C and D2-C are delivered from the factory with a bridge. If you want to connect contacts to the inputs (frame contact for example), the bridges must be removed. - Universal input D1 ...
Page 15: Fresh Air
11 - FRESH AIR ● Diagnostic d05, d06 The fresh air function can be carried out in various ways: - Ambient temperature control with supply air series (all fresh air): The room temperature measurement must be taken with the sensor of a terminal located in the room. In Comfort mode, the controller applies PID room control with all fresh air;...
Page 16 ● Configuration method for Master/Slave operation  The connection bus between the controllers must meet the KNX specifications and be fed by a KNX supply.  This configuration is performed using a wall-mounted display terminal (using 2 display terminals is advised). ...
Page 17 2 - Case of a Master unit with several slaves: - 1 master must be associated with 1 slave only - This must therefore be repeated as many times as there are slaves - Perform the same operation as in paragraph 1 with the first slave . - Do the same operation as in paragraph 1 with all other slaves associated with this mastere.
Page 18: Radio-Frequency Remote Control (Set-Up)
These exchanges may take longer than with a wire terminal and need a few seconds. Batteries: the V3000 system CIAT remote control operates with 2 LR03 alkaline batteries (provided). It is advised that these batteries are replaced once a year. (depending on the use).
Page 19 In parallel, the symbol displayed on the remote control reacts according to the fan coil unit status. This enables you to check that the receiver and its remote control have been "coupled". To remove links between a remote control and a receiver already associated. Switch the radio receiver to configuration mode, pressing and holding its button for around 10 s, until the LED starts flashing rapidly.
Page 20: Technical Specifications
14 - TECHNICAL SPECIFICATIONS a) Blank terminal b) Wall-mounted dial terminal EN7515935-00 EN - 18...
Page 21 c) Display terminal d) Radio-frequency receiver EN - 19 EN7515935-00...
Page 22: Wiring Diagram
15 - WIRING DIAGRAM Quick-release connector Screws Faston terminals, male 2.8 Faston terminals, male 2.8 Quick-release Screws connector N.B.: If the user terminal is used in the room, the connection to the controller is provided by means of flexible wires with a maximum length of 30 m and section 1 mm²...
