PROGRAM MODE (CONTINUED)
Program Mode Menu
Special Unit
Features and CONFIGUR
Hardware MENU
Configurations
[SUB-MENU]
PRESET
Preset Feature
SUB-MENU
Configuration
List
* Indicates this feature is only available on iQ units.
** Additional details are available in the Input/Output Functionality section.
*** This menu is hidden unless the optional feature is purchased and installed.
Two (2) virtual limit sets are available with a standard iQ unit. More virtual limit sets are possible with custom programming.
1
The minimum distance between any two Virtual Limits is 1", 1/2", 1/4" and 1/8" for any 165 lb (75Kg), 330 lb (150Kg), 660lb (300Kg), and 1320
2
lb (600Kg) actuators correspondingly, with the exception that the gap between the Upper and Lower Virtual Limits must be greater than 1". The
motion control position accuracy to any Virtual Limit is as follows:
+/- 1/4" for G-Force®, Easy Arm® 330 lb (150Kg); +/- 1/8" for G-Force® 660 lb (300Kg), +/- 1/16" for G-Force® 1320 lb (600Kg)
Note that the actual total accuracy is motion control accuracy plus any mechanical component accuracy constraints. For example, if
mechanical component accuracy is +/- 1/4", the total cumulated accuracy is +/- 1/2" for G-Force® 165 lb (75Kg unit.
This entire section or item selection requires cycling the main 220 VAC power for the setting(s) to take effect.
3
Chart D. (continued from pages 30-34) Program Mode Menu and Selection Settings.
9/18 - Rev. U
LCD Text
Record the current unit system configuration settings such as unit type and capacity set-
RECORD
ting, factory overload settings, loadcell calibration parameters, virtual limit software pack-
CONFIG
age enabling flag for Q unit, burn-in status and all the custom feature setup parameters.
ZERO Set loadcell bias signal with no weight attached to define a "zero" value (requires
LOD BIAS Float Mode option).
Set loadcell signal slope coefficient with a lifted weight equal to the rated capacity
CALIBRAT of the unit below the wire rope. Any different lifting weight will result in false
LOD COEF calibration and inaccuracy such as weight readout feature (requires Float Mode
option). This step must be performed after zero load bias.
HARDWARE Configure the unit to apply external OPS for FSH. The IO point is AUX input (Q)
OPS ON or X67 IO Block (iQ).
HARDWARE Configure the unit to apply software OPS as default. IO point will be set back to
OPS OFF default.
PRESET Access predefined sets of Q/iQ feature configurations including factory default
SUB-MENU setup.
I/O Expansion I/O Block (Assignment for one I/O Anti-Drop)
1 Input - Dual Float Mode
2 Input - Anti-Drop
3 Output - Anti-Drop
4 Input - Auto Home
PRESET
5 Input - External device control (combine with Actuator I/O Module point 5)
1*
6 Input - External device control (combine with Actuator I/O Module point 6)
7 Output - mimic OPS
8 Output - mimic stack
WARN: A unit equipped with a custom program would have its custom features
disabled and reconfigured to the above settings.
I/O Expansion I/O Block (Assignment for two I/O Anti-Drop)
1 Input - Dual Float Mode
2 Input - Anti-Drop (Clamp)
3 Input - Anti-Drop (Unclamp)
4 Input - Auto Home
PRESET
5 Input - External device control (combine with Actuator I/O Module point 5)
2*
6 Input - External device control (combine with Actuator I/O Module point 6)
7 Output - Anti-Drop (Clamp)
3
8 Output - Anti-Drop (Unclamp)
WARN: A unit equipped with a custom program would have its custom features
disabled and reconfigured to the above settings.
I/O Expansion I/O Block (Two I/O Anti-Drop & System Switches Output)
1 Input - Dual Float Mode
2 Input - Anti-Drop (Clamp)
3 Input - Anti-Drop (Unclamp)
4 Input - Auto Home
5 Output - Handle Operator Present Sensor Status
PRESET
6 Output - Slack or Down Travel Limit Switch Status
3*
7 Output - Anti-Drop (Clamp)
8 Output - Anti-Drop (Unclamp)
The external device control feature previously on I/O5 and 6 is disabled; therefore its
corresponding outputs on Actuator I/O Module I/O points 5 and 6 are disabled as well.
WARN: A unit equipped with a custom program would have its custom features
disabled and reconfigured to the above settings.
FACTORY Reset feature resets back to factory default equivalent PRESET 2. A unit equipped with
DEFAULT a custom program is reset to its default configuration with its custom features enabled.
Feature Description
