PROGRAM MODE (CONTINUED)
Lockout Feature (chart C)
To prevent tampering in Program Mode, a Lockout Feature is available.
To Lockout Program Mode:
1. Press both the G-Force® logo button and the MENU button simultaneously for five seconds.
2. The LCD will display "LOCKOUT CHECK" while both buttons are being depressed.
3. After five seconds, "PROGRAM LOCKED" will be displayed to confirm the Lockout was
successful.
If Program Mode is requested after the Lockout has been enabled, the LEDs will flash twice to indicate Program
Mode is not accessible and "PROGRAM LOCKED" will be displayed again.
To Unlock Program Mode:
1. Press both the G-Force® logo button and the MENU button simultaneously for five seconds.
2. The LCD will display "UNLOCK CHECK" while both buttons are being depressed.
3. After five seconds, "PROGRAM UNLOCKED" will be displayed to confirm the Lockout was
successful.
M
G
Locked?
Safety Program Mode
If the G-Force® has detected a fault or is running in SERVICE MODE, only a limited set of menus are accessible.
For example, if the G-Force® records a fault, when Program Mode is activated the LCD will display "LIMITED PRG
MODE" rather than "PROGRAM MODE". Safety Program Mode can be navigated just as Program Mode would be,
however the only menus available are:
• V-LIMITS MENU - Virtual Limits menu (option)
• SPEED MENU - Lift Speed adjustment
• RESPONSE MENU - Lift Responsiveness (Acceleration) adjustment
• SERVICE MENU - Customize and manage maintenance and service features
VIRTUAL LIMITS WARNINGS
If the upward speed reduction point is being used to reduce the impact of engaging the load "on the fly"
(i.e. catching the load with a hook while the G-Force® is already in motion in the upward direction), care
must be taken to ensure the speed reduction takes place before the load is engaged. Please program the
Upper Slow Down Reduction point at least half an inch below the exact point of pick-up.
Note: Setting the upper and lower virtual limits to the same position will cause the unit to not travel in either
direction.
9/18 - Rev. U
Both buttons for
5 sec to activate
LOCKOUT
No
CHECK
UNLOCK
Yes
CHECK
Chart C. Lockout Feature Process.
5 sec
5 sec
WARNINGS
29
PROGRAM
LOCKED
PROGRAM
UNLOCKED
