- Page 1 Translation of the original user guide PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H Operating instructions 03/2020 READ THE OPERATING INSTRUCTIONS MANUAL CAREFULLY BEFORE USE...
-
Page 3: Table Of Contents
2. SAFETY ........................... 5 2.1. SAFETY MEASURES ASSOCIATED WITH THE USE OF THE TOOL ......... 2.2. SAFETY MEASURES ASSOCIATED WITH BATTERY USE ............2.3. SAFETY MEASURES WHEN USING THE "PELLENC" CHARGER ..........2.4. STICKERS ............................3. DESCRIPTION AND TECHNICAL CHARACTERISTICS ............8 3.1. -
Page 4: Introduction
Refer to Section 2.4, “Stickers” for the location diagram of the safety stickers affixed to the tool. No part of this manual may be reproduced without the written permission of the company PELLENC. The illustrations given in this manual are for information purposes and are in no way contractual. The PELLENC company reserves the right to make any modification or improvement to its products as deemed necessary without informing customers already in possession of a similar model. -
Page 5: Safety
• Battery alone: product that is classified as class 9, UN3480. 14. Use of a battery other than that provided by Pellenc SA is dangerous (risk of serious injury). If a different battery is used, Pellenc SA cannot be held responsible for any consequences. -
Page 6: Safety Measures When Using The "Pellenc" Charger
In the event of contact with eyes, seek professional medical help. The liquid leaking from the batteries can cause irritations or burns. 19. Pellenc power tools must only be used with the battery units designed for the purpose. Use of other battery units can present a risk of injury and fire. -
Page 7: Stickers
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 2.4. STICKERS OLIVION + battery Do not expose to rain. Read the user guide. This equipment must be used at a temperature of between -5° and +35°C. Lithium-ion battery. At the end of its life, the battery must be returned to the authorized distributor from whom it was purchased to be recycled in accordance with waste regulations. -
Page 8: Description And Technical Characteristics
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 3. DESCRIPTION AND TECHNICAL CHARACTERISTICS 3.1. TECHNICAL CHARACTERISTICS - BATTERY Characteristics of OLIVION + battery Nominal\battery voltage 43.2 V Type of battery 12 times 6 elements included in 1 pack Battery capacity 17.4 Ah... -
Page 9: Description
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 3.3. DESCRIPTION Battery Charger indicator light ON/OFF switch 10. Charger power connector Tool power cable connector 11. Equipment carrier vest Charging connector (battery) 12. Retaining strips Charge connector cap 13. Straps Gauge display 14. -
Page 10: Commissioning
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 4. COMMISSIONING Important The battery must be fully charged (100 %) before being using for the first time in the new season. -
Page 11: Fitting The Battery On The Harness
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 4.1. FITTING THE BATTERY ON THE HARNESS... -
Page 12: Fitting The Harness
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 4.2. FITTING THE HARNESS... - Page 13 PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H...
- Page 14 PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H Caution Protect your back by taking the necessary time to adjust your vest correctly. Important Never force the connectors.
-
Page 15: Charging The Battery
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H Only use batteries with electric supply tool (3) connectors the same color as those present on the battery connector of the tool. In any other event, please seek confirmation with your approved dealer of compatibilty of the battery with the tools. - Page 16 PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H Connect the charging cord (7) to the battery's charg- ing connector (4). 56_20_012 When the gauge display (6) flashes, the battery is charging. Note Charging is complete when the message 99 ap- pears steadily on the gauge display (6).
-
Page 17: Upkeep
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 5. UPKEEP Warning Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers. • Disconnect the charger before cleaning it. Clean the charger case using a damp cloth and a gentle detergent. -
Page 18: Incidents And Troubleshooting
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 6. INCIDENTS AND TROUBLESHOOTING 6.1. SUMMARY OF GAUGE DISPLAY AND BEEP MESSAGES Normal messages Battery charge level (0 to 99) fixed Battery empty, recharge immediately with 1 beep per minute Stop using, recharge immediately... -
Page 19: Storage And Transport
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 7. STORAGE AND TRANSPORT 7.1. BATTERY STORAGE CONDITIONS • Store the battery unit and its charging device in a place away from any heat, dust or dampness, and ensure that the switch is on the "0" off position. -
Page 20: Warranties
The warranty is fully integral to the product sold by PELLENC. 8.1.2.1.2. SPARE PARTS The commercial warranty also covers original PELLENCspare parts, excluding labour and to the exclusion of certain... -
Page 21: Paid After-Sales Service
PELLENC Products are guaranteed under the commercial warranty as from delivery to the customer for a period of two (2) years for products connected to a PELLENC battery, and for a period of one (1) year for other PELLENC products. - Page 22 Paid after-sales service also covers original PELLENC spare parts, excluding labour and outside the legal and commercial warranty period. In case of replacement of original PELLENC spare parts in the context of after-sales service, said latter are covered by a warranty of one year as from the installation date.
-
Page 23: Compliance Statements
PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H 9. COMPLIANCE STATEMENTS 9.1. "EC" DECLARATION OF CONFORMITY: OLIVION + MANUFACTURER PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis (France) ENTITY AUTHORIZED TO COMPILE THE TECHNICAL FILE PELLENC ADDRESS Quartier Notre-Dame - 84120 Pertuis... - Page 24 PELLENC POWER TOOL BATTERY OLIVION + 56_131087-H...
- Page 28 PELLENC Quartier Notre Dame - 84120 Pertuis (France)
