ADURO 9.4 User Manual

Hide thumbs Also See for 9.4:

Advertisement

Quick Links

Download this manual
Brugsvejledning
DK/NO (2-14)
Bedienungsanleitung
DE (15-27)
User Manual
UK (28-39)
Eldningsinstruktion
SE (40-51)
Mode d'emploi
FR (52-63)
Manual de usuario
ES (64-75)
Manuale d'uso e manutenzione
IT (76-87)
Aduro 9.4
Ecolabel – EN13240
aduro.dk / aduro.no / adurofire.de / adurofire.com
adurofire.se / aduro.fr / aduro.es / aduro.it
Version 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9.4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADURO 9.4

Summary of Contents for ADURO 9.4

  • Page 1 UK (28-39) Eldningsinstruktion SE (40-51) Mode d’emploi FR (52-63) Manual de usuario ES (64-75) Manuale d’uso e manutenzione IT (76-87) Aduro 9.4 Ecolabel – EN13240 aduro.dk / aduro.no / adurofire.de / adurofire.com adurofire.se / aduro.fr / aduro.es / aduro.it Version 7...
  • Page 2 Congratulations on your new Aduro Stove! To get the best possible experience and benefit from your new Aduro wood burning stove, it is important that you read the user manual thoroughly through before you install the stove and start using it. Errors or incorrect settings can cause hazardous conditions and/or poor operation.
  • Page 3 1. General 1.1 Compliance Aduro 9.4 complies with the EN13240 European standard as well as the NS3058 Norwegian standard and is thereby approved for installation and use in Europe. At the same time, the manufacturing process is subject to external quality control. Aduro 9.4 also carries the Nordic Ecolabel, which guarantees that the wood burning stove complies with the most stringent environmental requirements and has been manufactured in an environmentally correct manner.

  • Page 4: Installation Of The Stove

    2. Installation of the stove You are welcome to install your wood burning stove yourself – but we strongly recommend that you consult your chimney sweep before you begin the installation. It is important to ensure that all local rules and regulations, including ones relating to national and European standards, are complied with when installing this device.

  • Page 5: Pipe Connection

    2.3 Pipe connection Aduro 9.4 leaves the factory with the flue outlet mounted on the top. If you require the flue outlet on the back, “brake” the two cover plates on top of the back of the stove. Exchange the exhaust connector (from the top outlet) with the cover plate from the rear outlet.

  • Page 6: Lighting The Stove

    If the stove is being connected to a brick chimney, the rear outlet or a curved flue pipe via the top outlet should be used. After measuring, a hole is made in the chimney in which the pipe sleeve is placed and stove mortar is used to seal it in place.
  • Page 7 Aduro Key: The stove comes with an Aduro-key which provides easier control of the secondary damper. The key is fitted onto the control handle in order to easily adjust the airflow from side to side.
  • Page 8 10x10 cm thick) with maximum moisture content of 18%. In practice, such circumstances can differ, which is why the Aduro-tronic control can be adjusted to your circumstances. If you want a slower intake of primary air (e.g. for a slower flue draft, larger sized wood or for longer intervals between stoking), adjust the screw on the front of the control level using a small allen key to slow closure rate.
  • Page 9 If you experience problems lighting the fire or the fire dies after a short time, it can be due to the following reasons: • The fire wood is not dry enough. The fire wood should have a moisture content of max. 18%. •...
  • Page 10 Secondary air intake: Side glass Secondary damper Primary damper The control handles will get warm when the wood burning stove is in use. Please use the glove provided when you operate the wood burning stove. 3.7 Recommended fuels Wood and wood briquettes. We recommend the use of split hardwood that has been stored outdoors under cover for at least 1 year.
  • Page 11 When a layer of embers has been formed, add 2-3 dry logs. If it is impossible to establish a sufficiently natural chimney draft, the chimney can be fitted with a smoke exhauster, e.g. Aduro DraftOptimizer. 4.2 Chimney and Smoke If you experience smoke coming out of the stove or the start section of the smoke pipe, it could be due to certain weather conditions.
  • Page 12 They can easily be removed using a damp cloth that you dip in cold ash and rub on the sooty glass. Special cleaning agents are also available to remove soot from glass, e.g. the Aduro Easy Clean pad. The pad neither scratch nor damage the glass and is for multiple usage.

  • Page 13: Right Of Complaint

    This work can also be carried out by the chimney sweep or your local Aduro GO partner. Repairing the surface Aduro stoves are painted with a heat-resistant paint that can withstand temperatures up to 500 degrees. If the surface of the stove gets scratched or worn, it can easily be renewed using this type of paint.
