Brugsvejledning
DK/NO (2-15)
Bedienungsanleitung
DE (16-30)
User Manual
UK (31-43)
p
Eldningsinstruktion
SE (44-56)
Mode d'emploi
FR (57-69)
Manual de usuario
ES (70-82)
Manuale d'uso e manutenzione
IT (83-96)
Aduro 9.3 Lux
Ecolabel – EN13240
aduro.dk / aduro.no / adurofire.de / adurofire.com
adurofire.se / aduro.fr / aduro.es / aduro.it
Version 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9.3 Lux and is the answer not in the manual?

Questions and answers

Related Manuals for ADURO 9.3 Lux

Summary of Contents for ADURO 9.3 Lux

  • Page 1 Eldningsinstruktion SE (44-56) Mode d’emploi FR (57-69) Manual de usuario ES (70-82) Manuale d’uso e manutenzione IT (83-96) Aduro 9.3 Lux Ecolabel – EN13240 aduro.dk / aduro.no / adurofire.de / adurofire.com adurofire.se / aduro.fr / aduro.es / aduro.it Version 3...
  • Page 2 Congratulations on your new Aduro Stove! To get the best possible experience and benefit from your new Aduro wood burning stove, it is important that you read the user manual thoroughly through before you install the stove and start using it. Errors or incorrect settings can cause hazardous conditions and/or poor operation.
  • Page 3 Europe. At the same time, the manufacturing process is subject to external quality control. Aduro 9.3 Lux also carries the Nordic Ecolabel, which guarantees that the wood burning stove complies with the most stringent environmental requirements and has been manufactured in an environmentally correct manner.

  • Page 4: Installation Of The Stove

    2. Installation of the stove You are welcome to install your wood burning stove yourself – but we strongly recommend that you consult your chimney sweep before you begin the installation. It is important to ensure that all local rules and regulations, including ones relating to national and European standards, are complied with when installing this device.

  • Page 5: Pipe Connection

    2.2 Pipe connection Aduro 9.3 Lux leaves the factory with the flue outlet mounted on the top. If you require the flue outlet on the back, “brake” the two cover plates on top of the back of the stove. Exchange the exhaust connector (from the top outlet) with the cover plate from the rear outlet.
  • Page 6 (plastic). It is important that the lead-in between the pipe and the wall (or floor) is sealed with jointing compound. You can eventually use the complete Aduro fresh air kit. The pipe with external supply of combustion air can be taken out at the bottom of the back side of the stove or under the stove (see illustration below): 2.5 Ways of installation...

  • Page 7: Lighting The Stove

    Do not install the stove in the following ways: With air intake upwards: Through a damp crawl space: If the air intake is turned upwards, If the air is drawn from a damp crawl there will be too much resistance for space, you won’t achieve an optimum air the air intake.
  • Page 8 1: Fully open primary, secondary, and tertiary air inlet. This position can be maintained with the Aduro key, which must be placed in the two holes. 2: Closed primary air inlet, fully open secondary and tertiary air inlet.
  • Page 9 What’s more important is that the primary air is not allowed in for too long. This is to ensure optimum combustion. The Aduro-tronic control will ensure intake of primary air at the right tempo. The automatic is activated by pulling the primary damper out each time fresh wood is put in the stove.
  • Page 10 combustion. The optimum combustion is achieved by placing two logs in the stove. If you want an enhanced effect, you can add more logs. The ideal heat output is reached by burning approx. 1.5 kg per hour. If you experience problems lighting the fire or the fire dies after a short time, it can be due to the following reasons: The fire wood is not dry enough.
  • Page 11 3. Keep the door approx. 1 cm ajar, until the glass is too hot to touch. Then close the door. When there are distinct, visible flames and the fire has taken hold, close the primary air intake/damper (see section 3.1.2). The control handles will get warm when the wood burning stove is in use.
  • Page 12 When a layer of embers has been formed, add 2-3 dry logs. If it is impossible to establish a sufficiently natural chimney draft, the chimney can be fitted with a smoke exhauster, e.g. Aduro DraftOptimizer. 4.2 Chimney and Smoke If you experience smoke coming out of the stove or the start section of the smoke pipe, it could be due to certain weather conditions.
  • Page 13 This work can also be carried out by the chimney sweep or your local Aduro GO partner. Repairing the surface Aduro stoves are painted with a heat-resistant paint that can withstand temperatures up to 500 degrees.

  • Page 14: Right Of Complaint

    6. Accessories For Aduro stoves we offer a wide product range of accessories to fulfil the experience: Companion sets, firewood baskets and buckets, fireplace grid, briquette buckets, floor hearths in glass and steel, flue pipes, Aduro Easy Firelighter, and Aduro Easy Clean pad.
