Spin Master AIR HOGS DEFENDER Instructions

DEFENDER
Check to make sure contents are complete:
1 Defender 1 Instruction Manual
1 Charger-Controller 1 Set of Stickers
2 Spare Propellers
Charge ON-OFF/ CHARGE
Button
Rod
Slide
Door
Open
Charge
Door
CHARGER-CONTROLLER
Charge the plane's internal batteries for 2 minutes. Note: If you notice your flight time decreasing over time, you may increase the
charge time up to a maximum of 4 minutes for better performance. Never charge more than 4 minutes or you may burn out the batteries.
1
Push the
plane's
ON/OFF switch
backwards to
set the plane
to OFF.
4
Push Charge
Rod into the
Plane's
Charge Port,
located in
the bottom
of the airplane.
Because the Defender's AA batteries are used for 2 functions, charging and controlling, they will need to be replaced
after every 20 flights.

PRE-FLIGHT ENVIRONMENT CHECK

1. Location – Fly in a large, wide-open, grassy location
that is free of buildings, trees, overhead wires, and other
obstructions. Do not fly near people or animals.
2. Weather – Fly on mild, sunny days. Do not fly in
electrical storms, rain, sleet, snow, or other adverse
weather conditions. Do not fly if the temperature is below
45°F/7°C. In very cold temperatures, the plane will become
fragile and the engine performance will decrease.
3. Wind Conditions – Do not fly in wind. Winds may
overpower the plane and make it difficult to control.
In windy conditions, it may appear as though you have
no control over the plane.
REV 1
®
TM
Indicator Light
Charge
Button
Toggle
2
Set the Charger-
Controller to
OFF/CHARGE.
INSTRUCTIONS
Experience radio-controlled (R/C) flight micro-sized with
the AIR HOGS
makes flying easy! Just choose the direction you want to
fly, and press the controller toggle. The Defender
full-function radio control so you can control up, down,
left or right. The Defender
is made of damage-resistant, high-density foam. The
Defender
unit for convenient portability and easy handling on the
field. Take flight and master the skies!
PLEASE REFER TO INSTRUCTIONS BEFORE FLYING.

BATTERY INSTALLATION

Battery
Door
Six
1.5-Volt
AA
Batteries
Battery
Compartment
CHARGING
5
Press and hold
the Charge
Button. During
charging,
the Indicator
Light will blink.

FLYING INSTRUCTIONS

Before flying, insert the Stand
1
into the slot on the bottom of the
Stand
R/C DEFENDER ! The Defender
® TM
is powered by 2 motors and
TM
also features an integrated charger-controller
TM
1. Use a Phillips screwdriver
to unscrew and remove the
battery door.
2. Install six 1.5-Volt AA
alkaline batteries (not
included). Be careful to align
the positive (+) and negative
(–) polarities with the
corresponding markings inside
the battery compartment.
3. Reinstall the battery door and
tighten the screw.
3
Slide the
Charge Door
open to
reveal the
Charge Rod.
6
Indicator
Light
When charging
is complete the
Indicator Light will
turn solid red.
Remove Defender
gently from the
Charge Rod and
close the Charge Door.
2
plane. The stand
will prevent
the plane's
propellers from
hitting the
ground and will
prolong the
plane's engine
life.
TM
has
TM
TM
Push Switch forward
to turn ON plane.
ON / OFF
Switch
