Spin Master Air Hogs FoxFire Instructions Manual

Ducted Fan
Engine
Check to make sure contents are complete:
• 1 Air Hogs Fox Fire™
®
• 1 Charger/Controller • 1 Instruction Sheet
Experience radio-controlled flight with the Air Hogs
want to fly and move the controller toggle. The ultra-light Fox Fire™ is powered by a lithium battery for long flights, features precision
speed control and damage-resistant foam. The Fox Fire™ also includes an integrated Charger/Controller unit for convenient portability
and easy handling on the field. This is an outdoor plane, do not fly indoors.
1. Use a Phillips screwdriver to loosen the
battery door.
2. Slide the battery door towards the bottom of the
unit and remove. Install six AA 1.5-V alkaline
batteries (not included). Be careful to align the
positive (+) and negative (-) polarities with
the corresponding markings inside the battery
compartment as shown.
3. Reinstall the battery compartment door and
re-tighten the hold down screw.
IMPORTANT TIP: TURN YOUR CONTROLLER
ON TO ENSURE THAT THE BATTERIES ARE
INSTALLED PROPERLY. THE RED LIGHT ON
THE FRONT OF THE CONTROLLER SHOULD
TURN RED.
After each flight, store the jet in the package to
prevent damage.
REPAIRS
®
Vertical
Stabilizers
Fox Fire™
Fuselage
Fox Fire™! The Fox Fire™ makes flying fun & easy! Just choose the direction you
®
CHARGER/CONTROLLER BATTERY INSTALLATION
If the wings
on your jet get
damaged they
can be easily
repaired with
clear tape as
shown.
Repair
INSTRUCTIONS
Ducted Fan
Main Wing
Throttle
Charging
LED
Charge Door
(to access Charge Nozzle)
1
Battery
Compartment
Door
2
Six AA
1.5-V
Alkaline
Batteries
Charger/Controller
CARE AROUND DUCTED FAN ENGINES
Ensure the Fans can spin freely. You may use a toothpick or
tweezers to clear debris out of the Ducted Fan engines. Never stick
your finger into the path of the fan blades.
CAUTION: Never place fingers or hair in or near Ducted Fan
engines. Never run Ducted Fans when examining Fan Engines,
as debris from grass or dust may get in your eyes and cause injury.
IMPORTANT – Adult Supervision is Recommended.
