Assembly Instructions & Flight Manual
Getting To Know Your AIR HOGS
DOCKING STATION/PUMP
PUMP HANDLE
NOZZLE
TM
TM
TOP ELEVATION
PROPELLER
NOSE CONE
PUMP SHAFT
PROPELLER
BASE
NOSE CONE
Congratulations! You are the proud owner
of one of the loudest, fastest and farthest
flying air-powered plane ever! AIR HOGS
Red Hornet
TM
can fly over 90 metres (100 yards)!
Red Hornet
TM
is also incredibly fast with top
speeds of up to 240KMH (150MPH)
read and follow these instructions to assemble
and fly your plane. Happy Flying!
PLEASE READ THESE INSTRUCTIONS
BEFORE FLYING!
TM
Red Hornet
Check to make sure the contents are
complete:
1 Plane
1 Pump
1 Main Wings
REAR WING ASSEMBLY
MAIN WING
SIDE ELEVATION
MAIN WING ELASTIC
FUSELAGE
ENGINE HOUSING
TM
1
. Please
TM
1 Rear Wing Assembly
1 Set of Stickers
VERTICAL REAR WING
HORIZONTAL REAR
WING
REAR WING
REAR WING
SLOT
REAR WING
ELASTIC
1. 240KMH (150MPH) SCALE SPEED, 1:15 SCALE.
CLIP
