3.1 Connecting Speakers

NOTE:
If you are installing either OBERON C,
CALLISTO C or RUBICON C speakers at the
same time as you are installing your SOUND
HUB COMPACT, we recommend that you
have their user manual to hand.
When you have positioned your SOUND
HUB COMPACT and connected it to mains
power, follow the steps below.
• Check that the speakers you wish to
use are connected to mains power and
switched on. Refer to the speaker user
manual to identify their power switch if
necessary.
• Press the LINK & CONNECT button on
your SOUND HUB COMPACT
panel input indicators will flash slowly to
indicate speaker connection mode.
11
• Go to one of the speakers and press its
rear panel LINK & CONNECT button
The speaker channel matrix indicators will
illuminate cyclically while connection to the
SOUND HUB COMPACT is underway.
• When connection is established, the
cyclic illumination will stop, leaving just the
left and right channel matrix indicators
flashing slowly. The speaker will play a short
confirmation tone.
• With the speaker connected to the
SOUND HUB or SOUND HUB COMPACT,
it can be assigned to either the left or right
channel. The channel matrix display on the
speaker rear panel incorporates indicators
at each channel position. Pressing the
speaker LINK & CONNECT button changes
the channel specified for the speaker
If the first speaker is to be assigned to the
. The top
A left channel, the LINK & CONNECT button
will only need to be pressed once because
the left channel is the default.
• If the first speaker is to be assigned to the
. right channel, press the LINK & CONNECT
B
button twice to select the right channel.
• With the first speaker connected to the
SOUND HUB COMPACT and its channel
specified, repeat the process for the
second speaker
D
• When both speakers in the system are
connected and their channels specified,
return to your SOUND HUB COMPACT
and press its LINK & CONNECT button
to complete the speaker connection
process . Both speakers will play a short
F
confirmation tone and the SOUND HUB
COMPACT top panel indicators will stop
flashing.
The SOUND HUB COMPACT connection
.
C
procedure is illustrated in
.
E
Diagram 8.
