- Page 1 DCP-2000, DCP-2K4, ShowVault, DSV-J2 Maintenance Manual Digital Cinema Servers Version 1.6 D2K.DP.000255.DRM Page 1 Version 1.6 Doremi Cinema LLC...
-
Page 2: Table Of Contents
5.2 Tasks Required Each 50,000 Operating Hours................20 5.2.1 2U Rear Panel Fans and Dolphin Fan Replacement............20 5.2.2 Dolphin Battery Replacement.....................20 5.2.3 Motherboard Battery Replacement..................21 6 Acronyms............................23 7 Document Revision History......................24 D2K.DP.000255.DRM Page 2 Version 1.6 Doremi Cinema LLC... - Page 3 Software License Agreement The software license agreement can be found at the following location: http://www.doremilabs.com/support/cinema-support/cinema-warranties/ Hardware Warranty The hardware warranty can be found at the following location: http://www.doremilabs.com/support/cinema-support/cinema-warranties/ D2K.DP.000255.DRM Page 3 Version 1.6 Doremi Cinema LLC...
- Page 4 Do not put, or allow anyone to put, any object, especially metal objects into the unit. Use only an AC power supply. Never use a DC power supply. If water or any other liquid is spilled into or onto the server, disconnect the power and call your Doremi dealer.
- Page 5 These are considered energy hazards. REMOVAL OF HARD DRIVES MAY ONLY BE PERFORMED BY TRAINED SERVICE PERSONNEL. CONTACT DOREMI FOR TRAINING PROGRAMS. With regards to the energy hazard warning and removable drives, the equipment may only be used in a restricted access location (not accessible to the general public).
- Page 6 ( s e r v i c i n g ) i n s t r u c t i o n s i n t h e l i t e r a t u r e a c c o m p a n y i n g t h e a p p l i a n c e . D2K.DP.000255.DRM Page 6 Version 1.6 Doremi Cinema LLC...
- Page 7 EN 55022 "Limits and Methods of Measurement of Radio Interface Characteristics of • Information Technology Equipment." A "Declaration of Conformity" in accordance with the above standard has been made and is on • file at Doremi. D2K.DP.000255.DRM Page 7 Version 1.6 Doremi Cinema LLC...
-
Page 8: Introduction
This document provides instructions for preventive maintenance operations applicable to the DCP- 2000, DCP-2K4, ShowVault, and DSV-J2. 1.2 Contact If in need of help or assistance, please contact Doremi Labs Technical Support at: 24/7 Technical Support line: +1-866-484-4004 • Technical Support Email: support@doremicinema.com... -
Page 9: Digital Cinema Server Recommended Operating Conditions
2 Digital Cinema Server Recommended Operating Conditions Listed below are the recommended operation conditions for Doremi digital cinema servers: 1. AC power to the unit should be feed through UPS, greater than or equal to 600VA per player, which provides a logical signal that shows the power failure. -
Page 10: Maintenance Program
Note: The durations provided above do not include the unit preparation time corresponding to Section 5.1.1. Such preparation is estimated to be approximately 20 minutes. The technician performing the procedure should be accredited by Doremi. The corresponding maintenance procedures are provided in Section 5. -
Page 11: Required Tools
Otherwise, you might lose the security clock time and the unit will not be able to play encrypted material any more. If this happens, the unit must be returned to Doremi. **The motherboard replacement CR2032 3V Lithium Coin Battery is not provided by Doremi but can be sourced locally. -
Page 12: Soft Brush
4.4 Small Vacuum Cleaner A small vacuum cleaner will be required to remove the dust from concerned parts. This is to be used with the soft brush. Figure 4: Small Vacuum Cleaner Example D2K.DP.000255.DRM Page 12 Version 1.6 Doremi Cinema LLC... -
Page 13: Maintenance Tasks Procedure
Each 5,000 operating hours, the maintenance tasks procedure presented in this section must be performed. Follow the steps detailed below. Caution: Maintenance tasks should be performed by a technician accredited by Doremi. 5.1.1 Unit Preparation (Estimated Duration: 20 Minutes) For the following preventive maintenance tasks, the unit has to be removed from its operating location and put in a safe area: 1. -
Page 14: Dust Removal
1. Remove the dust from the CPU fan and from the 2U rear panel fans as illustrated below: Vacuum Cleaner Nose Figure 7: CPU Fan Dust Removal Figure 8: 2U Rear Panel Fans Dust Removal D2K.DP.000255.DRM Page 14 Version 1.6 Doremi Cinema LLC... - Page 15 Figure 11: Motherboard Northbridge Heatsink Cleaning 5. Clean the Dolphin fan that is mounted using a plastic tunnel. To do this, unscrew one leg of the plastic tunnel as presented in Figure 12 below. D2K.DP.000255.DRM Page 15 Version 1.6 Doremi Cinema LLC...
- Page 16 To take the hard disk drive out, press the blue button to release the handle and then pull the handle. When the drive is removed, use the soft brush and the vacuum cleaner to remove the dust as presented in Figure 14: D2K.DP.000255.DRM Page 16 Version 1.6 Doremi Cinema LLC...
-
Page 17: Fans And Dolphin Fan Shock Mounts Visual Inspection
1. Look at the rear panel. You should NOT see any first shock mount gaps (see Figure 18a below). 2. Verify, from the top of the unit, that the fans are parallel to the chassis, as presented in Figure 18b below. D2K.DP.000255.DRM Page 17 Version 1.6 Doremi Cinema LLC... -
Page 18: Noise From Fans And Rattling
Then replace that fan with a fan having the same Part Number. Contact your local Doremi Support team (Section 1.2) for fan replacement and for additional guidance. -
Page 19: Lid Closing
The unit can be put back into its rack and re-connected to the power. • Note: You might have to reconnect all the cables that were disconnected at the beginning of this procedure. D2K.DP.000255.DRM Page 19 Version 1.6 Doremi Cinema LLC... -
Page 20: Tasks Required Each 50,000 Operating Hours
According to the fan's manufacturer, it is recommended that you replace the 2U rear panel fans and the Dolphin fan each 50,000 operating hours (~ 5 years). Please contact Doremi (Section 1.2) for additional instructions about how to install new fans. -
Page 21: Motherboard Battery Replacement
Open the unit lid by removing the six screws that hold it in place. • Locate the battery on the motherboard. It is close to the South Bridge (Figure 26). • Battery Southbridge Battery Figure 26: Battery Location D2K.DP.000255.DRM Page 21 Version 1.6 Doremi Cinema LLC... - Page 22 Place the DPT back, and secure it using the two plastic rivets and the original screws. • Complete the other preventive maintenance tasks scheduled at the same time before putting the lid back according to the procedure provided in Section 5.1.5. You have now completed this procedure. D2K.DP.000255.DRM Page 22 Version 1.6 Doremi Cinema LLC...
-
Page 23: Acronyms
6 Acronyms Term Definition Power Supply Unit RAID Redundant Array of Independant Disks Uninterruptible Power Supply D2K.DP.000255.DRM Page 23 Version 1.6 Doremi Cinema LLC... -
Page 24: Document Revision History
Description 10/03/2007 First version. 03/31/2008 HDD filter and Dolphin battery maintenance tasks added 06/19/2008 Shock mounts updated. 12/23/2011 All sections modified to include all Doremi Digital Cinema Servers. 01/24/2012 Contact information revised. 07/20/2012 Logo updated. 09/13/2012 Motherboard battery replacement added.
