ILLUMINATE THE SOUL
INSTALLATION INSTRUCTIONS
LIGHTPLANE 9
LP9WE/LP9WH | Wall End, Wall Horizontal | LED
A
1035 22nd Avenue, Unit 1
Oakland, CA 94606
P
510.489.2530
E
TalkToUs@alwusa.com
W
alwusa.com
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIGHTPLANE 9 and is the answer not in the manual?

Questions and answers

Summary of Contents for ALW LIGHTPLANE 9

  • Page 1 ILLUMINATE THE SOUL INSTALLATION INSTRUCTIONS LIGHTPLANE 9 LP9WE/LP9WH | Wall End, Wall Horizontal | LED 1035 22nd Avenue, Unit 1 Oakland, CA 94606 510.489.2530 TalkToUs@alwusa.com alwusa.com...
  • Page 2 Safety & Warnings! 1. Read all instructions. 2. Install in accordance with national and local electrical code regulations. 3. This product is intended to be installed and serviced by a qualified, licensed electrician. 4. Only install with a compatible Class 2 LED Driver. This product has not been evaluated for use when connected to an LED driver that does not comply with Class 2 voltage and energy limited supplies.
  • Page 3: Table Of Contents

    Table of Contents Luminaire Overview Diagrams Components Parts (by others) Tools Required Quick Specs Installation Prepare Wall Standard Mounting Tie-Backs Troubleshooting Wiring Diagrams LP9 Wall Installation Guide 3 of 9 102-000028 - IG090320-A.0 ILLUMINATE THE SOUL...
  • Page 4: Luminaire Overview

    LUMINAIRE OVERVIEW To Building Power (High Voltage) J-BOX 4 (By Others) Universal Adapter (Optional) Framing/ Blocking Fixture Body STANDARD WALL MOUNT COMPONENTS Cable Universal Adapter Wall Fitting Wall Bullet Quick Specs Parts (by others) Tools Required Input Voltage / Frequency: Wood Screws, #8, 1.5”...
  • Page 5: Installation

    Installation: Prepare Wall Installation: Standard Mounting WALL ” See Final/Record Drawings for Mounting Locations Install Universal Adapter (If Necessary) See final/record drawings for mounting locations. Install Install Universal Adapter(provided) using appropriate framing or strut channels with consideration for alignment hardware screws (by others) to allow Fixture Mount on Step 7.
  • Page 6: Tie-Backs

    Installation: Standard Mounting Installation: Tie-Back Supports (Cont.) Fixture Alignment Install Wall Fitting - Framing Ensure Fixture is properly aligned and leveled. Wall Fittings may be installed directly into framing with appropriate hardware. NOTE: Cables should be installed at a 45° angle. 45 °...
  • Page 7 Installation: Tie-Back Supports (Cont.) Route Tie-Back Cable and Attach to Wall Fixture Alignment Route Tie-Back Cable through Tie-Back Bullet. Ball end Ensure Fixture is properly aligned and supported. should sit in Tie-Back Bullet. Screw Tie-Back Bullet to Wall Fitting. Turn Power On Insert Tie-Back Cable into Gripper Insert Tie-Back Cable through Cable Grippers, as shown.
  • Page 8: Troubleshooting

    Troubleshooting Only a certified electrician can service and troubleshoot product field issues. Always turn main power off before servicing fixture. Full Fixture does not illuminate • Ensure all wire connections are made. • Ensure fixture is wired correctly and power is on. •...
  • Page 9: Wiring Diagrams

    Wiring Diagrams (Colors and driver quantity may vary, consult Final/Record Drawing for more details) Traditional On/Off Black Line Voltage (Hot) White Line Voltage (Neutral) AC 50/60Hz Green Ground 0-10V Dimming Line Voltage Black Line Voltage Neutral White Green Ground Ground AC 50/60Hz 0-10V DC Dimming -...
