nbf Signature 51795 Assembly Instructions

Congratulations on the purchase of your new Signature Series chair!
PARTS
PAR T DESCRIPTION
1 Casters
2
5-Star Base
3 Cylinder
4 Seat Plate
Seat Cushion
5
6A Left Arm
6B Right Arm
Back Cushion
7
Back Support Plate
8
(Already attached to
the back cushion)
9
1-1/4" Big Screws
1" Big Screws
10
11
1-1/4" Small Screws
12
3/4" Big Screws
13
Hexagonal Wrench
CUSTOMER SERVICE HOTLINE
800-626-6060
ATTENTION:
Make certain to fully tighten all screws
before using chair.
INSTRUCTIONS
QTY
5
1
1
1
1
1
1
1
1
2
2
8
3
1
INSTRUCTIONS
A. Remove all parts from the carton and separate them into part number groups as indicated in the parts list.
B. To begin assembly, place the base (2) upside down and insert casters (1) into bottom of base (2).
C.
Turn the base (2)
Tighten the brackets of arms (6A & 6B) onto the bottom of the seat cushion (5) (with front of arms facing
D.
the front of seat cushion) by using 1-1/4" small screws (11). Tighten the screws completely.
Attach the seat plate (4) to the bottom of the seat cushion (5) (with front of seat plate facing the front of the
E.
seat cushion) by using 1-1/4" big screws (9) into the front holes of the seat plate (4) and 1" big screws (10)
into the rear holes of the seat plate (4) and tighten the screws.
Insert back support plate (8) into the rear hole of the seat plate (4) as shown in Diagram 1. Then secure
F.
with 3/4" big screws (12) as shown in Diagram 1 and tighten the screws.
G. Place the assembled chair on top of the cylinder (3) and press down until fully engaged.
H. Periodically (every 90 days) make sure that the screws are still fully tightened.
WE SUGGEST TAPING THE WRENCH UNDER THE SEAT FOR FUTURE USE.
A S S E M B LY I N S T R U C T I O N S
WWW. NBF. COM
800-558-1010
TASK CHAIR
(3) into the center hole on the base (2).
