A 72"x30" Table Top
*1pc
E 24" End Panel
*1pc
I 29" Pedestal*1pc
a Self-tapping
Screw 4*10mm-20pcs
e Glide-8pcs
B 48"x24" Table Top
*1pc
F Modesty Panel
*1pc
J 23" Pedestal*1pc
b Self-tapping
Screw #10*3/4"-14pcs
f Flat Head Screw
#10*1" -8pcs
For Right Return
Follow Page 2~3
MIDLAND COLLECTION
72"x30" , 48"x 24" L- DESK
ASSEMBLY INSTRUCTION
C 30" End Panel-R
*1pc
G Return Modesty Panel
*1pc
c Screw
M6*40mm-9pcs
g Screw
M6*12mm-4pcs
D 30" End Panel-L
*1pc
H Connecting Plate
*1pc
d M6 Washer-9pcs
h Bracket-4pcs
For Left Return
Follow Page 4~5
Page 1 of 5
