- Page 1 UniMod 01/I Modem Operation Manual E121801419062 Baer Energie- & Messtechnik GmbH Siemensstr. 3 D-90766 Fürth Germany Phone: +49 (0)911 970590 Fax: +49 (0)911 9705950 Internet: www.baer-gmbh.com...
- Page 2 Baer Energie- & Messtechnik GmbH preserves the right to modify or withdraw this document at any time without prior announcement.
-
Page 3: Table Of Contents
UniMod 01/I Table of Contents General ......................5 Power Supply Unit..................5 Interfaces ...................... 5 Display ......................5 Installation Hints ..................5 Programming the Modem ................6 SMS ......................11 Reset Function ................... 12 Inserting the Interface Modules ..............12 Technical Data .................... - Page 4 UniMod 01/I...
-
Page 5: General
2. Power Supply Unit The UniMod 01/I modem is equipped with a built-in, low-loss switched power supply, which enables it to operate on a wide-range AC or DC supply voltage: ... -
Page 6: Programming The Modem
3. Now you can plug the parametering adapter into the 7-pole jack (the LED’s must point downwards). 4. The UniMod 01/I can now be programmed with the software UniModSet. 5. After programming switch off the UniMod and insert the interface module carefully again. - Page 7 4. Then connect the 25 pole plug (RS232) to the PC port and switch on the voltage supply at the modem. 5. The UniMod 01/I can now be programmed with the software UniModSet. 6. After programming switch off the UniMod and insert the interface module carefully again.
- Page 8 Data transmit control Then select in the menu „Settings - Interface“ the serial port (e.g. COM1) and send („Write“) the chosen device configuration to the UniMod 01/I. Additionally you can receive („Read“) the configu- ration from a connected UniMod 01/I.
- Page 9 UniMod 01/I Programming with the terminal software First set your terminal program to the appropriate data rate and data format for reading out the target device (i.e. meter). Use one of the AT commands (e.g. ATS0?, ATI, AT&V) to check whether the modem answers.
- Page 10 UniMod 01/I Password authentication after establishment of connection Using command AT*P the password authentication can be enabled ("AT*P1", see register 14 bit 6) or disabled ("AT*P0"). As factory default it is disabled. With authentication enabled the UniMod asks the remote station immediately after the CONNECT message for the password.
-
Page 11: Sms
UniMod 01/I 7. SMS Optional it is possible to activate SMS (old device UniMod 01/It, undeliverable!). This function is monitoring of on/off state changes of DTR input (terminals 8 and 9). This function is possible only at Germany (area Deutsche Telekom / German Telecom). -
Page 12: Reset Function
UniMod 01/I 8. Reset Function Optional it is possible to activate the time-controlled modem-reset. The functionality is activated by the jumper and displayed by the Rst-LED (Rst-LED flashes every 10 seconds). Reset-Timer Jumper Function Rst-LED Disable: without re- Without flashes sets ... -
Page 13: Technical Data
Possible: every 3, 6, 12 or 24 hours License: EU-License CETECOM CE0682, reg. no. D800739K/CTR21 Extent of delivery: - UniMod 01/I including interface module as ordered - Standard cable TAE (length of cable about 3m) - Operation manual Accessories: - Adapter for parametering with USB port (Order No.: #12823) - Additional interface modules - Suspension eye (Order No.: #9141) -
Page 14: Terminal Block
UniMod 01/I 11. Terminal Block 12. Phone Line Interface TAE plug used (for Germany only). Standard configuration: a (La) white b (Lb) brown Note: Cable colours may be different. Alternative: RJ12 plug used. Standard configuration: a (La) green b (Lb) yellow... -
Page 15: Dimensions
UniMod 01/I 13. Dimensions Wall-mounted housing (DIN 43861-2) - Page 16 UniMod 01/I...
