- Page 1 Wheel hay rakes SUNCE”- “ FPM 627 154 FPM 627 155 FPM 627 156 INSTRUCTIONS MANUAL AND LIST OF SPARE PARTS PLEASE, READ CAREFULLY BEFORE USE...
- Page 2 Dear Users, Congratulations on your purchase of the FPM Agromehanika product and thank you for your trust. We believe that you will be satisfied, since decades of experience in the production of agricultural machinery, application of the latest technology, the use of quality materials and the application of proven technical solutions guarantee high quality and relevant characteristics of the product.
- Page 3 CONTENT...
- Page 4 Failure to follow the provided recommendations and instructions may result in product damage or serious injury to the user and other persons present. REMARK: FPM Agromehanika is constantly striving to enhance and improve its products and therefore reserves the right to make changes or improvements as necessary, without any obligation to change previously manufactured or sold equipment.
- Page 5 1.1 General information about the product Wheel hay rakes “SUNCE” – duplex are designed for raking, spreading and turning mowed mass, which shortens drying time. Due to good ground contour adaptation, this type of wheel rake is suitable for every type of terrain, and is very reliable and easy to use due to simple and robust construction.
- Page 6 I General terms Company FPM AGROMEHANIKA AD (hereinafter referred to as FPM) provides a guarantee that the product will operate properly for a period of 2 years from the date of delivery of the product to the customer. This warranty covers all parts that are manufactured by FPM, whose life is longer than two years and that are found to be defective due to defects in materials, poor workmanship and / or faulty installation, according to the assessment of FPM or authorized service.
- Page 7 2. Safety warnings Safety warnings of potential danger are expressed in two ways: 1. Recommendations for safe use in the manual; 2. Warning labels on the product. 2.1 The meaning of warning symbols Symbols and warnings in this manual describe the potential danger during use, control or maintenance of the product and are divided into 4 groups according to the level of potential dangers.
- Page 8 2.2.2 Connecting the machine to the tractor 1. Before each connecting and disconnecting of the machine to the tractor, block hydraulic controls to prevent any unwanted lifting or lowering. 2. When connecting the machine to the tractor, make sure that the connection points of the tractor correspond to connection points of the machine.
- Page 9 2.3 Warning labels Warning labels are placed on the machine to ensure your safety and the safety of people who work with you. The labels must be clearly visible and legible, otherwise replace them with the new ones. REMARK: Each label has its own catalogue number and can be ordered directly from the manufacturer or authorized dealer.
-
Page 10: Installation
3. Installation To facilitate transport of the machine some parts and assemblies are dismantled. The level of dismantling may vary depending on the market where the machine is delivered. The main parts and assemblies of the wheel hay rakes are: Left Right CONNECTION STRUCTURE 627-154/155/156... -
Page 11: Left Side
3.1 INSTALLATION OF THE LEFT AND RIGTH INTER-BEARING TO THE CONNECTION STRUCTURE Install the inter-bearing structure (figure 1, position 1) to the connection structure (position 2) and secure it with the small axle (position 3) and the clip (position 4). Figure 1 3.2 INSTALLATION OF THE MAIN FRAME TO THE INTER-BEARING For installation of the main frame (Figure 2 pos. - Page 12 3.3 INSTALLATION OF COLLECTING WHEELS BEARINGS TO THE MAIN FRAME For installation of the collecting wheels bearings (Figure 3 pos. 1) to the main frame, first remove the flat washer and the clip from the sleeve of the collecting wheels bearings (pos. 3 and 4), then pull the sleeve in the opening on the main frame and secure the connection by placing the flat washer and clip on the sleeve.
-
Page 13: Connecting To The Tractor
4. CONNECTING TO THE TRACTOR Connecting is performed as follows: 1. Move the tractor backwards, then, by means of the hydraulics, lower the bottom tractor levers (figure 6, pos. 2) at the height of the axle of the connecting points of the collector and make the connection of the lever, too, as shown in (A) (figure 6) 2. - Page 14 5. USE OF THE COLLECTOR 5.1 Before first use Before the first use of the collector be sure to make the following checks: Description OK () Completeness of the product Checking the tightness of the screws of the collecting wheels Checking the tightness of all the screws Checking the position of collecting elements 5.2 WORKING WITH THE COLLECTOR...
- Page 15 ATTENTION: BEFORE STARTING WORK, REMOVE STONES, FOREIGN OBJECTS AND HIDDEN OBSTACLES FROM THE AREA. DANGER! BEFORE STARTING WORK, MAKE SURE THE OTHER PERSONS OR ANIMALS ARE NOT IN THE ZONE OF MACHINE. 5.2.2 TURNING AND RAKING OF HAY The collector can also be used for turning and raking of hay to shorten the drying time of hay. For this operation, the main frame (pos.
- Page 16 BEFORE YOU START SETTING UP, MAINTENANCE OR FIXING OF THE MACHINE, TURN OFF THE TRACTOR, REMOVE THE IGNITION KEY AND PULL THE PARKING BRAKE OF DANGER! THE TRACTOR. REMARK: USE ONLY ORIGINAL AND RECOMMENDED PARTS OF FPM AGROMEHANIKA. 6.1 Schedule of regular service and maintenance INTERVAL OF SERVICE Before AFTER...
-
Page 17: Parking And Storage
7. PARKING AND STORAGE 7.1 Parking To park the collector, do the following: Lower the supporters from the upper, transporting position to the standby position (picture 7); Use the tractor hydraulics to lower the collector to lean on the supporters; Turn the main frame from the transporting, vertical position (photo 8), to the horizontal, operating position (Photo 9). -
Page 18: Troubleshooting
REMARK: Using original spare parts approved by the FPM Agromehanika guarantee the safe operation of the machine, as well as relevant characteristics. The use of spare parts and equipment that is not approved by the FPM... - Page 19 The machine meets the relevant safety requirements of EC directives for machines.
-
Page 20: Declaration Of Conformity (Ec)
FPM Agromehanika DOO, Djordja Simeonovića 25, 19370, Boljevac, Serbia hereby declare, as manufacturers within our responsibility that the product Type: Wheel hay rakes “SUNCE” Model: FPM 627 652 – 4 wheels FPM 627 139 – 5 wheels FPM 627 350 – 8 wheels FPM 627 154 –... - Page 21 FPM Agromehanika DOO, Djordja Simeonovića 25, 19370, Boljevac, Serbia www.fpm-agromehanika.rs TEL: +381 (0) 30 463 531 FAX: +381 (0) 30 463 405...
