ROTARY RAKE – HAY
HARVESTER WITH
ADJUSTABLE PYRAMID
ASSEMBLY / OPERATION/ MAINTENANCE
Email: razvoj @ fpm-agromehanika.rs
info @ fpm-agromehanika.rs
SPARE PARTS LIST
FPM AGROMEHANIKA D.O.O.
Đorđa Simeonovića br.25
Boljevac-Srbija
www.fpm-agromehanika.rs
SERBIA
FPM 627 152
FPM 627 168
FPM 627 169
Internet: www.fpm-agromehanika.rs
o
N
39811
12.2016.
Advertisement
Table of Contents
Related Manuals for FPM Agromehanika 627 152
Summary of Contents for FPM Agromehanika 627 152
- Page 1 ROTARY RAKE – HAY FPM 627 152 HARVESTER WITH FPM 627 168 ADJUSTABLE PYRAMID FPM 627 169 39811 ASSEMBLY / OPERATION/ MAINTENANCE SPARE PARTS LIST 12.2016. FPM AGROMEHANIKA D.O.O. Đorđa Simeonovića br.25 Boljevac-Srbija www.fpm-agromehanika.rs Email: razvoj @ fpm-agromehanika.rs info @ fpm-agromehanika.rs Internet: www.fpm-agromehanika.rs...
- Page 2 IMPROVEMENT: FPM Agromehanika d.o.o. strives to continuously improve its products and therefore reserves the right of modification or improvement, without having to modify or improve previously manufactured or sold equipment.
- Page 3 C O N T E N T S № 39811 TABLE OVERVIEW PAGE PARTS GROUP Safety warning Limited warranty 6 - 7 Safety Safety – Attaching the rake to the tractor 8 - 9 Safety – Using the PTO shaft Safety –...
-
Page 4: Please Read Carefully
PLEASE READ CAREFULLY! You will find the warning labels “ATTENTION”, “CAUTION”, and “DANGER” in this manual and on the machine. The warnings draw your attention to personal safety and the safety of others who work with you, since they need to read the warnings, too. PERSONAL SAFETY ATTENTION: The word “ATTENTION”... -
Page 5: Limited Warranty
LIMITED WARRANTY For each original unit delivered to the user by the FPM Agromehanika AD Boljevac distribution network, the manufacturer issues a warranty in accordance with the Standardization Act and Machinery Safety Regulation (Official Gazette of the Republic of Serbia No. 13/2010) guaranteeing that each rotary rake... - Page 6 S A F E T Y Most accidents occur during work, maintenance or transport due to the non-observance of the fundamental safety requirements. This is why you are the most important person for operating and maintaining your rake. Regardless of whether you are working alone, with your family members or other persons, always read and observe the basic method of operation.
- Page 7 - For the sake of safe transport on public roads, check whether all the protective components and reflex reflectors are properly affixed and secured to the frame, and replace any damaged or broken parts using original parts manufactured by FPM AGROMEHANIKA DOO BOLJEVAC.
- Page 8 S A F E T Y ATTACHING THE RAKE TO THE TRACTOR Before coupling and decoupling the rake to or from the tractor, lock the hydraulic controls in order to prevent unintended raising or lowering. When coupling your rake, observe the category of the tractor and rake linkages; they must match. - The area around the attachment points is especially hazardous.
- Page 9 - If you have doubts about the PTO shaft operation, or if the shaft guard is missing, worn or broken, replace the PTO shaft with one labelled with a CE mark. - Before turning on the tractor output shaft, check whether the selected rpm matches the permissible rpm of the rotary mower.
-
Page 10: Warning Labels
WARNING LABELS FPM Boljevac The following warning labels are affixed to your rotary rake for your safety and the safety of others working with you. Holding the manual in your hand, walk around the machine and check all the warning labels and instructions from the manual. - Page 11 WARNING LABELS FPM Boljevac The rake is identified by the nameplate (label no. 2) containing the following numbers: ― The field marked »Z« contains the occupational safety certificate number. ― The field marked »MASA/WEIGHT« contains the product weight. ― The field marked »GODINA/YEAR« contains the year of manufacture (last two digits). ―...
- Page 12 WARNING LABELS FPM Boljevac RISK OF INJURY! Keep safe distance during operation or transport. RISK OF INJURY! Keep safe distance during operation or transport. FPM - 627 . 627 15 420 FPM Boljevac TECHNICAL SPECIFICATION Product Characteristics: FPM-627.152 FPM-627.168 FPM-627.169 Working width (m) No.
- Page 13 INFORMATION FOR READING THE INSTRUCTIONS CORRECTLY Boljevac In this manual, “left” and “right” Metric thread is used for assembly. corresponds to the direction of Tighten screws during motion. installation. A – Front part Each figure uses symbols showing B – Rear part the installation location.
- Page 14 ASSEMBLY FPM Boljevac For easy transport, the rotary rake is supplied with the tines, tine brackets and safety guards unattached. To assemble the unattached parts, proceed as follows: Tine bracket assembly (Figure 1) Insert the tine bracket (S) into the oscillating part of the rotor (L) and secure it using two spring bolts (G) (Ø...
-
Page 15: General Information
ASSEMBLY FPM Boljevac Swath board assembly (Figure 4) Place the swath board bracket (S) inside the profile (E) and secure it to one of the provided holes using the spline (C). Attach the board (H) to the bracket (S) in one of the provided positions and secure it using two screws (J) (M8x55) and the self-locking nut (M8). - Page 16 JOINT COUPLING – PTO SHAFT FPM Boljevac It is extremely important to properly adjust the 3.- The maximum permissible angle of PTO shaft when attaching the rake to the deflection of the PTO shaft may not exceed tractor. Never allow the universal joints to get 30 degrees (Figure 9).
-
Page 17: Operating Settings
OPERATING SETTINGS FPM Boljevac During the harvesting process, the upper linkage point on the tedder frame must be in the free-floating position. Properly adjusted tines for rake operation touch the ground (soil) on the front side of the rake when looking in the driving direction. In this position, the rotor must be perfectly horizontal in relation to the ground. - Page 18 ROTARY RAKE OPERATION FPM Boljevac Never operate the rotary rake with a PTO shaft If the harvesting is unsatisfactory, this can rpm higher than manifest in two ways as follows: 540 min 1.- Poor harvesting with hay remaining in the middle of the swath (Figure 13). Depending on the thickness of the hay This is eliminated by shortening the upper harvested, you can make single or double...
-
Page 19: Swath Board
SWATH BOARD FPM Boljevac Side adjustment:4 positions (C)(15) Depending on the hay thickness, extend or retract the board support. Height adjustment:3 positions (H) (15) The swath board is factory-supplied in the middle position. Use the other two positions as necessary. For example: Upper position:... - Page 20 ROTARY RAKE PARKING FPM Boljevac To park the rotary rake after operation, use the scotch block (X) to prevent the machine resting on the operating components (tines). The block is secured with a lock (P). To protect the PTO shaft grooves from impurities and debris, put the PTO shaft in its bearing (Q) on the rake frame, preventing the PTO shaft from resting against the ground.
-
Page 21: Important Notes
IMPORTANT NOTES FPM Boljevac Before adjusting or maintaining the Prevent the PTO shaft guard from machine, turn off the tractor engine and rotating using the provided chains. remove the ignition key. Do not allow the friction clutch to slip for Check the tension of all the screws and more than a few seconds. - Page 22 CERTIFICATE AND DECLARATION OF CONFORMITY FPM Boljevac Page 22...
-
Page 23: Spare Parts List
Thickness Parts and components package For vineyard tractors For tractors of category I Replaceable with one or multiple parts For tractors of category 2 Washer thickness For tractors of category 3 Washer thickness for reducing clearance FPM AGROMEHANIKA D.O.O. BOLJEVAC...
