FPM Agromehanika 627 712 Assembly / Operation/ Maintenance, Spare Parts List

Rotary multi-disc mowers
Hide thumbs

Advertisement

Quick Links

Download this manual
ROTARY
MULTI-DISC
MOWERS
ASSEMBLY / OPERATION / MAINTENANCE
________________________________________________________________________________
Email: razvoj @ fpm-agromehanika rs
info @ fpm-agromehanika rs
prodaja@ fpm-agromehanika.rs
SPARE PARTS LIST
SERBI
FPM 627 712
FPM 627 713
FPM 627 726
FPM 627 678
03.2017
Web: www.fpm-agromehanika.rs

Advertisement

loading
Need help?

Need help?

Do you have a question about the 627 712 and is the answer not in the manual?

Questions and answers

Related Manuals for FPM Agromehanika 627 712

Summary of Contents for FPM Agromehanika 627 712

  • Page 1 FPM 627 712 ROTARY FPM 627 713 MULTI-DISC FPM 627 726 MOWERS FPM 627 678 ASSEMBLY / OPERATION / MAINTENANCE SPARE PARTS LIST 03.2017 ________________________________________________________________________________ Email: razvoj @ fpm-agromehanika rs Web: www.fpm-agromehanika.rs SERBI info @ fpm-agromehanika rs prodaja@ fpm-agromehanika.rs...
  • Page 2 IMPROVEMENT: FPM Agromehanika d.o.o. strives to continuously improve its products and therefore reserves the right of modification or improvement, without having to modify or improve previously manufactured or sold equipment.
  • Page 3 065053 C O N T E N T S TABLE OVERVIEW PAGE PARTS GROUP Limited warranty 6 - 9 Safety 10 - 12 Warning labels Technical specifications General information 15 - 18 Assembly instruction Hydraulic installation Joint coupling — PTO shaft Attaching the mower to the tractor Transporting the mower Adjusting the cutting unit for operation...
  • Page 4 PLEASE READ CAREFULLY! You will find warning labels “ATTENTION;” “CAUTION;” and “DANGER” in this manual and on the machine. The warnings bring your attention to personal safety and safety of others who work with you, since they need to read the warnings, too. PERSONAL SAFETY ATTENTION: The word “ATTENTION”...
  • Page 5 LIMITED WARRANTY For each original unit delivered to the user by the FPM Agromehanika AD Boljevac distribution network, the manufacturer issues a warranty in accordance with the Standardization Act and Machinery Safety Regulation (Official Gazette of the Republic of Serbia No. 13/2010) guaranteeing...
  • Page 6 - Every time before using the mower check whether all parts (nuts, screws, etc.) are sufficiently tightened, and secure the discs and cutters. If worn out or damaged, cutters, discs and their fasteners (nuts, screws, etc.) must be replaced with FPM AGROMEHANIKA d.o.o BOLJEVAC original parts. Page 6...
  • Page 7 - For safety reasons, check whether the canvas cover is properly secured and attached to the frame. If damaged or worn out, replace it immediately with original cover by FPM AGROMEHANIKA DOO BOLJEVAC. - Before adjusting, lubricating, or cleaning the mower, lower it to the ground, turn off the tractor engine, remove the ignition key, turn off the PTO shaft, and apply the tractor parking brake.
  • Page 8 S A F E T Y ATTACHING THE MOWER TO THE TRACTOR - Before coupling and decoupling the mower to or from the tractor, lock the hydraulic controls in order to prevent unintended raising or lowering. - When coupling your tedder, observe the category of the tractor and tedder linkages; they have to match.
  • Page 9 - If you have doubts about the PTO shaft operation, or if the shaft guard is missing, worn or broken, replace the PTO shaft labelled with a CE mark. - Before turning on the tractor output shaft, check whether the selected number and direction of rotation match with the permissible number and direction of rotation of the mower.
  • Page 10 WARNING LABEL FPM Boljevac The following warning labels are affixed to your mower for your safety and the safety of others working with you. Holding the manual in your hand, walk around the machine and check all warning labels and instructions from the manual. The labels must be legible. If not, they must be replaced.
  • Page 11 TO ENSURE PROPER OPERATION OF YOUR MOWER ALWAYS USE ORIGINAL PARTS FROM FPM AGROMEHANIKA ALWAYS USE ORIGINAL PARTS FROM FPM AGROMEHANIKA BOLJEVAC. BOLJEVAC TO ENSURE PROPER OPERATION OF YOUR MOWER. PRIOR TO DETACHING THE MACHINE FROM THE TRACTOR: LOWER THE CUTTING UNIT IN THE HORIZONTAL POSITION.
  • Page 12 WARNING LABELS FPM Boljevac WARNING WHEN REPLACING WORN BELTS, REPLACE THE ENTIRE BELT SET, REGARDLESS OF V-BELTS THE INDIVIDUAL BELTS’ To ensure proper operation of your mower, the V-belts must be CONDITION. properly tensioned! Ensure a 10 mm sag. The mower is identified by the nameplate (label no. 2) containing the following numbers: ―...
  • Page 13 Loose items are not attached, but packed separately and placed into wooden boxes. FPM 627 712 a x b x c =1650 x 860 x 1950 FPM 627 726/FPM 627 678 a x b x c = 1625 x 800 x 2000...
  • Page 14 TECHNICAL SPECIFICATION Boljevac MOWER LABELS FPM 627 712/712MPS FPM 627 726/678 FPM 627 713 No. of discs Swath width 1.3m 2.10 m 2.1m Tractor operating speed 16 kmph or above Performance 2.0ha/h 2.5ha/h 3.2ha/h Required tractor output shaft 18 KW (24.5 HP)
  • Page 15 ASSEMBLY INSTRUCTION Boljevac For easier transport of FPM 627 726678 and FPM 627 713 rotary mowers, few parts and assemblies have been removed in order to minimize the size. To properly assemble the mower, proceed as follows: 1. - To mount the support frame to the cutting unit Secure the free yoke connecting the support frame and the step-up gear unit with two self-locking nut (A) (Abb.
  • Page 16 ASSEMBLY INSTRUCTION Boljevac Mount the read guard end (I; Fig. 6), and attach it with six M8x20 screws (B) applying a 5 daNm torque. 3. - To assemble the balancing rod Fasten the balancing rod (L; Fig. 8) to the attachment point on the frame as shown (Fig. 8). 4.
  • Page 17 ASSEMBLY INSTRUCTION Boljevac - To mount the mouldboard The entire mouldboard is mounted by attaching the plate (U) to the mouldboard support (R) on three places (O) using the M8x18 screw, flat washer (Y), spring washer (V), and nut (W) as shown in Fig.
  • Page 18 ASSEMBLY INSTRUCTION Boljevac Connect the front half of the frame (C) using the M10x25 screws (F) to the corresponding brackets (B) using the flat and plastic washers (Q; ø10), M10 nuts (O) as shown in Fig. 17. Attach the assembled frame half to the openings (N) using the M10x75 screws and secure it using the M10 self- locking nuts.
  • Page 19 Hydraulic installation A-- When attaching the mower to the tractors with a control distributor for external hydraulic, attach the hydraulic cylinder lines to the hydraulic outlet. B - -For attaching the mower to the tractors manufactured by IMT - BEOGRAD: - On the gearbox housing, loosen two screws (A) and remove the cover (B) (Fig.
  • Page 20 JOINT COUPLING — PTO SHAFT Boljevac It is extremely important to properly adjust the 4:- Remove any sharp edges, Figure 28. PTO shaft for attaching the mower to the tractor. Never allow the universal joints to get jammed when the machine is raised in the topmost or lowered in the bottommost position.
  • Page 21 ATTACHING THE MOWER TO THE TRACTOR Boljevac In order to ensure proper operation, To perform the attaching operation: attach the mower to the linkages of a 1.- Remove the paint from the mower tractor with 1.32 m wheel track as shown trunnions.
  • Page 22 ROTARY MOWER TRANSPORT FPM Boljevac For transporting the mower on public roads 4. Fold the front end of the canvas or from one field to another, remember and cover (A) backwards (see arrow), Fig. do the following: and fasten it using the provided 1.
  • Page 23 ADJUSTING THE CUTTING UNIT Boljevac 1. Place the locking pin (A; Fig. 40) in the 3. Lower cutting unit operating position. This releases the operating position using spring enabling the cutting unit to copy hydraulic cylinder. the terrain properly. 4. Use the tractor linkages to adjust the WARNING: FOR REPOSITIONING THE mower so that the attachment point LOCKING PIN, THE CUTTING...
  • Page 24 ADJUSTING THE CUTTING HEIGHT Boljevac The cutting height is adjusted by turning Reverse the tractor slightly and raise the the entire cutting unit along its roll axis. mower using the linkages. Using a swinging This is performed by shortening or motion, draw the cutting unit towards the extending the upper linkage (B;...
  • Page 25 OPERATING THE MOWER Boljevac After lowering the cutting unit from the transport 3. Ensure that the cutter turns when the in the operating position, let the cutting unit cutting edge hits an obstacle. shaft rotate for a while at low revolutions to 4.
  • Page 26 CUTTING UNIT CAPACITY THE CUTTING UNIT HOUSING FOR EXCESS HEAT BUILDUP DURING OPERATION BY TOUCHING IT WITH Mower series Litres YOUR RIGHT PALM. NORMAL FPM 627 712 OPERATING TEMPERATURE IS ABOUT FPM 627 716/678 90 ºC. FPM 627 713 Page 26...
  • Page 27 LUBRICATION FPM Boljevac WARNING: IT IS RECOMMENDED TO REDUCE THE QUANTITY OF OIL IN THE CUTTING UNIT DRAWING A POSITIVE OR NEGATIVE ANGLE DURING OPERATION WITH THE HORIZONTAL LINE BY ABOUT 25 PER CENT. IT IS ALSO RECOMMENDED TO HOLD THE CUTTING UNIT HORIZONTALLY FOR A FEW MINUTES EVERY HALF AN HOUR.
  • Page 28 ADJUSTMENTS AND MAINTENANCE Boljevac CAUTION: Remove objects when adjusting your mower. Foreign objects and parts may be ejected in the direction ATTENTION: Prior to performing any of individual standing by. adjustments or configurations to the machine, switch off both the PTO shaft and the tractor engine.
  • Page 29 ADJUSTMENTS AND MAINTENANCE Boljevac V-BELTS The V-belts must be properly tensioned in order to prevent excess sliding. Insufficiently tensioned V-belts will cause poor performance of the cutting unit, as well as premature damage and tears (see Section 2 on page 15).
  • Page 30 PARKING THE MOWER Boljevac To park the mower, proceed as follows: Lower the foot (D) from the upper transport position into the support position. Using the tractor hydraulic, lower the mower until it is resting on the ground. Bring the cutting unit from the vertical transport position in the horizontal position.
  • Page 31 MAINTENANCE TABLE Boljevac ISSUE POSSIBLE CAUSE CORRECTIVE ACTION Cutting unit does not float Support frame not properly Adjust the support frame to (does not copy the ground) adjusted. bring the attachment points to a 400 mm height from the ground and be parallel.
  • Page 32 The required torque is 7.5 daNm. Inspect the discs immediately upon hitting a hidden obstacle. Perform an inspection when replacing the cutters. Always install a cutter pair from FPM AGROMEHANIKA DOO BOLJEVAC to avoid unbalancing the disc. Perform an inspection before every mowing season.
  • Page 33 When the contact protective compound inside the nut loses its elasticity, characterised by frequent loosening. When the nut wear and tear reaches the value of a = H/2. ALWAYS USE ORIGINAL PARTS FROM FPM AGROMEHANIKA BOLJEVAC TO ENSURE PROPER OPERATION OF YOUR MOWER. Page 33...
  • Page 34 2. NEVER WEAR CLOTHING THAT MAY GET CAUGHT IN THE PTO SHAFT OR OTHER ROTATING PARTS. 3. NEVER TRANSPORT OTHERS ON THE TRACTOR OR MOWER. 4. IT IS RECOMMENDED THAT A MECHANIC OF THE FPM AGROMEHANIKA DOO BOLJEVAC INSPECTS THE MOWER CONDITION, AND IN PARTICULAR THE CUTTERS AND OTHER PARTS.
  • Page 35 DECLARATION OF CONFORMITY 2006/42/EC Boljevac Page 35...
  • Page 36 Parts and components package For vineyard tractors For tractors of category I Replaceable with one or multiple parts For tractors of category 2 Washer thickness For tractors of category 3 Washer thickness for reducing clearance. FPM AGROMEHANIKA DOO BOLJEVAC Page 36...
  • Page 37 1. 627 12 892 2. 627 10 762 3. 627 14 747 4. 627 14 746 5. 627 10 319 6. 627 14 754 7. 627 14 748 8. 627 14 749 9. 627 14 750 10. 627 14 752 11.
  • Page 38 STEP-UP GEAR UNIT FOR FPM 627 712/726/678/713 IDENTIFICATION NUMBER FOR ORDERING 000 00 062 000 00 071 000 00 072 000 00 084 000 02 016 6206 000 02 191 M10x25 000 10 078 M10x20 000 05 334 A8x7x45 000 05 336...
  • Page 39 STEP-UP GEAR UNIT FOR FPM 627 712/726/678/713 IDENTIFICATION NUMBER FOR ORDERING 000 08 099 47x30x7 627 14 084 3 discs 627 10 516 4 discs 627 15 699 5 discs 627 10 529 627 10 644 627 10 645 627 10 646...
  • Page 40 CUTTING UNTI FOR FPM 627 726/678;FPM 627 713 IDENTIFICATION NUMBER FOR ORDERING 000 00 066 000 02 493 000 04 636 M10x20 000 05 324 M12x25 501 10 328 627 10 651 627 13 459 627 13 462 627 12 878 4diska 627 15 671 5 discs...
  • Page 41 CUTTING DISC TRANSMISSION IDENTIFICATION NUMBER FOR ORDERING 000 00 070 000 00 084 000 04 226 000 04 227 6007 000 05 325 a8x7x32 000 05 333 M8x25 000 07 412 6006 627 10 177 627 10 511 627 10 512 627 10 514 627 10 515 627 10 529...
  • Page 42 IDENTIFICATION CUTTING ELEMENTS BRACKETS FOR FPM 627 726/678 NUMBER FOR ORDERING 000 00 060 000 00 070 000 02 208 000 05 259 M8x25 000 07 954 627 16 659 627 16 659 627 10 543 627 10 544 627 10 753 627 15 750 627 16 659 627 15 751...
  • Page 43 CUTTING ELEMENTS BRACKETS FOR FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 060 000 00 070 000 02 208 000 05 259 M8x25 000 07 954 627 10 518 627 10 543 627 10 544 627 10 753 627 12 819...
  • Page 44 CUTTING ELEMENTS BRACKETS FOR FPM 627 713 IDENTIFICATION NUMBER FOR ORDERING 000 00 060 000 00 070 000 02 208 000 05 259 M8X25 000 07 954 627 10 518 627 10 543 627 10 544 627 10 753 627 15 504 804 91 699 627 12 934 627 12 935...
  • Page 46 IDENTIFICATION CONNECTING AND SUPPORT FRAME FOR 627 713 – GMD 55 SELEKT NUMBER FOR ORDERING 627 13 346 627 13 434 611 20 010 627 10 683 627 13 419 000 07 948 627 13 429 627 12 838 627 13 420 627 13 428 627 13 267 627 13 365...
  • Page 47 MOWER SUPPORT FRAME FOR FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 060 000 00 065 000 00 066 000 02 493 000 04 087 000 04 088 6,3x45 000 04 636 M10x20 000 05 324 M12x25 000 05 342...
  • Page 48 HYDRAULIC LIFTING DEVICE FOR FPM 627 678 IDENTIFICATION NUMBER FOR ORDERING 000 00 050 5x36 000 00 057 M8x15 000 02 392 000 02 515 000 03 865 000 04 088 6,3x45 000 04 608 000 05 464 6x40 000 07 831 51108 IKL 000 07 947 000 07 949...
  • Page 49 HYDRAULIC LIFTING DEVICE FOR FPM 627 726/713 IDENTIFICATION NUMBER FOR ORDERING 627 13 216 627 13 215 000 05 390 22x27 627 13 217 627 16 382 000 05 464 6x40 000 05 344 8x50 627 16 384 000 05 389 A14x20 627 13 214 000 05 250...
  • Page 50 HYDRAULIC LIFTING DEVICE FOR FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 050 5x36 000 02 515 000 05 389 14X20 000 05 390 22x27 000 05 727 4X25 000 11 342 20x80 627 12 875 627 12 887...
  • Page 51 BALANCING ROD FOR FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 063 000 04 641 M20x1.5 627 10 618 627 12 011 627 12 012 627 12 023 627 12 035...
  • Page 52 PROTECTIVE FRAME FOR MOWER FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 054 M6x15 000 00 060 000 00 062 000 00 065 000 00 069 000 00 070 000 00 072 000 00 085 000 02 166 M8x30...
  • Page 53 FLOATING ROD FOR FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 050 5x36 000 02 515 000 11 343 20x50 627 11 970 627 11 980 627 12 055 627 12 696 627 12 857 FOR 500 20 712MPS MOWER...
  • Page 54 PROTECTION — MOULDBOARD FOR FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING VERSION I 000 00 068 000 00 070 000 00 072 000 02 392 000 04 738 A8x20 000 05 324 M12x25 000 05 336 000 13 389 M16x1.5 000 15 172 M12x1.5x25...
  • Page 55 MOULDBOARD AND SWATH BOARDS FOR FPM 627 726/678 IDENTIFICATION NUMBER FOR ORDERING 000 00 060 000 00 065 000 00 070 000 00 072 000 04 738 M8x20 000 05 324 M12x25 000 05 336 000 05 338 M8x18 000 09 987 M8x25 000 15 172 M12x1.5x25...
  • Page 56 PROTECTION — MOULDBOARD FOR FPM 627 713 IDENTIFICATION NUMBER FOR ORDERING 000 00 060 000 00 069 000 00 070 000 00 072 000 04 330 000 04 738 M8X20 000 05 324 M12X25 000 05 336 000 95 347 M8X20 000 08 110 M6X20...
  • Page 57 CONNECTING FRAME FOR MOWER FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 05 342 5x40 611 20 010 627 10 108 627 10 472 627 10 683 627 11 840 627 12 049 627 12 682 627 12 838 627 12 842...
  • Page 58 DRIVE PULLEY FPM 627 712 IDENTIFICATION NUMBER FOR ORDERING 000 00 060 000 00 062 000 00 065 000 00 088 000 02 392 000 04 088 6,3x45 000 04 233 000 05 326 000 05 335 A12x8x56 000 05 424...
  • Page 59 ASSEMBLY: CANVAS COVER...
  • Page 60 IDENTIFICATION NUMBER FOR ORDERING 51.12.00 (SJ-02)FKI Temerin <-> 660 mm 627 11 810 <-> 990 mm...
  • Page 61 THE OPERATOR MUST OBSERVE ALL OCCUPATIONAL SAFETY AND HEALTH REGULATIONS; AS WELL AS ROAD SAFETY REGULATIONS. FOR YOUR PERSONAL SAFETY, USE ONLY ORIGINAL PARTS MANUFACTURED BY FPM AGROMEHANIKA DOO BOLJEVAC. THE MANUFACTURER MAY NOT BE HELD LIABLE FOR THE CONSEQUENCES OF IMPROPER USE OR FAILURE TO COMPLY WITH THE RECOMMENDATIONS GIVEN IN THIS MANUAL.
  • Page 62 FOR YOUR PERSONAL SAFETY AND TO ACHIEVE OPTIMAL PERFORMANCE WITH YOUR MOWER, USE ONLY ORIGINAL PARTS MANUFACTURED BY FPM AGROMEHANIKA DOO BOLJEVAC FPM AGROMEHANIKA DOO 19370 Boljevac, Đorđa Simeonovića br.25 PHONE NUMBERS: +381 30/463 531; /463 455 FAX: +381 30/463 405 Distribution Centre –...

This manual is also suitable for:

627 713627 726627 678
