Spraying System eco-CONTROL SC1200
Commissioning and maintenance manual

10. Electrical Connections

10.1 Footswitch:

pins:

10.2 I/O-Port:

type:
pins:
Pin no. Input / Output
1 --
2 --
3 --
4 Output
5 --
6 Input
7 Input
8 Input
9 --
10 --
11 Output
12 Output
13 Input
14 Input
15 Input
External selection of programs:
Programm no.
Manuell
Programm 1
Programm 2
Programm 3
Programm 4
Programm 5
Programm 6
Programm 7
Copyright
©
connections between Pin 1 + 3 starts dispensing
15-pol. SubD female 2-doublerow
see following chart
Description
Reserved
GND
24V DC
BUSY
GND
START
PRG1
PRG3
Reserved
Reserved
READY
ERROR
REMOTE
ERROR-IN
PRG2
PRG-Selectbit #1
0
1
0
1
0
1
0
1
Comment:
Reserved
GND
24V DC
Dispensing procedure active
GND
Starts dispensing
Programmselect Bit #1
Programmselect Bit #3
Reserved
Reserved
Ready Signal
Error Signal
Remote active
External Error input
Program select Bit#2
PRG-Selectbit #2
0
0
1
1
0
0
1
1
PRG-Selectbit #3
0
0
0
0
1
1
1
1
11 / 16
