In this user manual we have tried to describe the matters
concerning the operation of this CNC system to the greatest extent.
However, it is impossible to give particular descriptions for all
unnecessary or unallowable operations due to length limitation and
products application conditions；Therefore, the items not presented
herein should be regarded as ＂impossible＂ or ＂unallowable＂.
Copyright is reserved to GSK CNC Equipment Co., Ltd. It
is illegal for any organization or individual to publish or reprint this
manual. GSK CNC Equipment Co., Ltd. reserves the right to ascertain
their legal liability.
Advertisement
Table of Contents
Related Manuals for GSK GSK983Ta-H
Summary of Contents for GSK GSK983Ta-H
- Page 1 ＂impossible＂ or ＂unallowable＂. Copyright is reserved to GSK CNC Equipment Co., Ltd. It is illegal for any organization or individual to publish or reprint this manual. GSK CNC Equipment Co., Ltd. reserves the right to ascertain their legal liability.
- Page 2 Be responsible for the failure to observe the provisions for operation, adjustment, maintenance, installation and storage in the manual. This manual is reserved by end user. We are full of heartfelt gratitude to you for supporting us in the use of GSK’s products.
-
Page 3: Table Of Contents
17. I/O Points Definition (X1) ....................... 19 Appendix 1 Installation Dimension Drawings ................23 Appendix 2 Connection between NC Unit and DA98D Drive Unit（obsolete product） ..28 GSK983Ta-H/ GSK983Ta- V Turning CNC System Connection Manual ........30 Version Upgrading Records ......................30... - Page 4 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual...
-
Page 5: Precautions
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Precautions 、 The system-matched power supply box is exclusive for GSK 983Ta. Do not supply this power to other devices (such as bake and magnetic valve);otherwise, serious danger may occur！ 2、 Requirements for electrical cabinet The electrical cabinet adopts full-enclosed structure and dustproof design. - Page 6 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual The joints between wires and the system or drive unit should be tight and firm. The low-current type wires such as signal wires and control wires should be laid far away from heavy current and electromagnetic interference, and be arranged in an uncurled manner as far as possible, because winding annularly could easily cause the acquisition of interference signal.
-
Page 7: Nc Unit Interfaces
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 1. NC Unit Interfaces Front View U disk read/write interface Communication interface to PC C232 Back View +24V +3.3V SVY(M) SVZ(T) SVZ(M) SP(T) -
Page 8: Interconnect Block Diagram
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 2. Interconnect Block Diagram SVZ(T) SVY(M) SP(T) SVZ(M) +3.3V +24V +24V CC 1 Y0.0 Y1.0 Y0.1 Y1.1 33.3 Y0.2 32.0 34.6 Y1.2 Y0.3 33.4 32.1 34.7 Y1.3 33.5 Y0.4 Y1.4 32.2 35.0 33.6 Y0.5... -
Page 9: Connection Between Nc Unit And Gs2000T-Ca1 Drive Unit
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 3. Connection between NC Unit and GS2000T-CA1 Drive Unit (without brake) GS2000T suffixing with C(CAN bus) AC servo drive unit NC unit PBO- PZO- PBO+ PZO+ PAO- DGND PAO+ PULS- SIGN- PULS+ SIGN+... -
Page 10: Connection Between Nc Unit And Gs2000T-Ca1 Drive Unit
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 4. Connection between NC Unit and GS2000T-CA1 Drive Unit (with brake) GS2000Tsuffixing with C(CAN bus) AC servo drive unit NC unit PBO- PZO- HOLD- HOLD+ +24V PBO+ PZO+ PAO- DGND PAO+ PULS- SIGN-... -
Page 11: Full Closed-Loop Connection With Grating Ruler
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 5. Full closed-loop connection with Grating Ruler Grating ruler 983Ta PCZ X *PCZ X PCA X *PCA X PCB X *PCB X GS2000T-CAI Servo Drive Unit SRDYX 04 ALM+ +24V VCMD+ VCMD- SONX+ 09... -
Page 12: Connection Between Nc Unit And Dap03 Spindle Servo Drive Unit
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 6. Connection between NC Unit and DAP03 Spindle Servo Drive Unit Spindle Servo Drive Unit: DAP01or DAP03 983Ta-00-785 NC Unit 16 PA+ 07 PCA Encoder A phase 12 *PCA differential signa 17 PB+... -
Page 13: Connection Between Nc Unit And Gs3000Y-Np2 Spindle Servo Drive Unit
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 7. Connection between NC Unit and GS3000Y-NP2 Spindle Servo Drive Unit Suffixing with N (no-bus) GS Spindle Servo Drive Unit 983Ta-00-785G NC Unit 19 PA+ 07 PCA Encoder A phase 12 *PCA differential signal... -
Page 14: Connection Between Nc Unit And Spindle Inverter
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 8. Connection between NC Unit and Spindle Inverter NC unit, I/O unit Spindle Inverter 主轴变频器 NC单元、I/O单元 +24V I/O单元 I/O unit 主轴正转 M03 (正转控制) Spindle CW M03 (Forward ) 主轴反转 M04 (反转控制) (Reverse) Spindle CCW M04 (公共端) -
Page 15: Machine Tool Operation Panel
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 9. Machine Tool Operation Panel POFF PCOM +24V ESPC ESPB ESPA POWER COMMUNICATION POFF （Power off） PCOM （Power switch common port） +24V （Power on） ESPC （Emergency stop chain leading-out terminal2） ESPB （Emergency stop button on operation panel leading-out terminal2) ESPA （Emergency stop button on operation panel leading-out... -
Page 16: Connection Between Nc Unit And Operation Panel
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 10. Connection between NC Unit and Operation Panel Operation Panel NC unit NC 单元 (D-9 female) D-9 male) (D-Sub 9 male) TD2+ TD2- 983Ta-00-777 RD2+ RD2- (D-Sub 9 female) Communication 04 HA+ 05 HB+... -
Page 17: Connection Between External Mpg And Operation Panel
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 11. Connection between external MPG and Operation Panel 983Ta-00-783 Operation Panel External MPG Ruipu Wuxi GSK-ZSSY1468-01G-100B-05L 01* HX 02* HZ Axis select switch ×1 × 1 04* ×10 × 10 Override switch 17* ×100 ×... -
Page 18: Connection Between Nc Unit And Pc
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 12. Connection between NC Unit and PC NC unit NC单元 PC机 RS232 (3M MDR14) (D-9针) (D-9 male) 3M MDR14插头 Plug 983Ta-00-772 RS232 (D-Sub 9孔) (D-Sub 9-Pin Female) (RS232) RS232 09 RI 03 TXD 串行数据接收... -
Page 19: Connection Method For Brake And System Power-On Control
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 13. Connection Method for Brake and System Power-on Control X Axis Zero GS2000T-CA1 Servo CN1 X Axis Brake Power-on Control Speed Clamping Control Interface Connection CN1-39 COM+ CN1- 43 HOLD+ +24 V System... -
Page 20: Connection Between Nc Unit And I/O Unit
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 14. Connection between NC Unit and I/O Unit NC Unit External I/O Unit (D-9) (D-9male) (D-Sub 9 male) TX1+ TD0- TX1- TD0+ RD0- 983 T a-00-782 RX1+ RD0+ 08 TD1- 04 TD1+ RX1-... -
Page 21: General Of External I/O Unit (X1) Interfaces
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 15. General of External I/O Unit (X1) Interfaces Y6.7 Y3.7 Y6.6 40.2 Y3.6 48.5 Y6.5 43.7 40.1 Y3.5 48.4 Y6.4 43.6 40.0 Y3.4 48.3 Y6.3 43.5 38.7 Y3.3 48.2 Y6.2 43.4 38.6 Y3.2 48.1... -
Page 22: Connectivity Diagrams For I/O Unit (X1) Input/Output Signals
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 16. Connectivity Diagrams for I/O Unit (X1) Input/output Signals 1. Input Signal The COM ports of each address group determine whether the addresses are valid at high or low level： When COM port is connected to 24V,the input points are valid at low level（0V）；... -
Page 23: I/O Points Definition (X1)
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual 17. I/O Points Definition (X1) Terminal Signal Function Signal Name Address X32.COM X32 common port High/low selection for groupX32 Ｘaxis＂+＂direction limit（short it to X32.0 X32.0 *+LX（fixed） 0V when unused） Ｘaxis＂-＂direction limit （ short it to 0V X32.1... - Page 24 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Terminal Signal Name Signal Function Address X48.COM X48 common port High/low selection for group X48 X48.0 X48.0 X48.1 X48.1 X48.2 X48.2 X48.3 X48.3 X48.4 X48.4 X48.5 X48.5 X48.6 X48.6 X48.7 X48.7 X43.COM X43 common port High/low selection for group X43 X43.0...
- Page 25 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Terminal Signal Name Signal Function Address Y0.0 Y0.0 Y0.1 Y0.1 Y0.2 Y0.2 Y0.3 Y0.3 Y0.4 Y0.4 Y0.5 Y0.5 Y0.6 Y0.6 Y0.7 Y0.7 Y1.0 Y1.0 Y1.1 Y1.1 Y1.2 Y1.2 Y1.3 Y1.3 Y1.4 Y1.4 Y1.5 Y1.5...
- Page 26 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Y2.6 Y2.6 Y2.7 Y2.7 24V power ground +24V 24V power output Note：Those points which have been defined functions are fixed in the system that cannot be changed any more by users. And functions of other points can be programmed by PLC.
-
Page 27: Appendix 1 Installation Dimension Drawings
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Appendix 1 Installation Dimension Drawings... - Page 28 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual...
- Page 29 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual...
- Page 30 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual...
- Page 31 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Y6.7 Y3.7 Y6.6 40.2 Y3.6 48.5 Y6.5 43.7 40.1 Y3.5 48.4 Y6.4 43.6 40.0 Y3.4 48.3 Y6.3 43.5 38.7 Y3.3 48.2 Y6.2 43.4 38.6 Y3.2 48.1 Y6.1 43.3 38.5 Y3.1 48.0 Y6.0 43.2 38.4...
-
Page 32: Appendix 2 Connection Between Nc Unit And Da98D Drive Unit（Obsolete Product
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Appendix 2 Connection between NC Unit and DA98D Drive Unit （obsolete product） Connection without brake DA98D Drive Unit 983Ta NC Unit (D-44 male) PBOUT- PZOUT- PBOUT+ PAOUT- PZOUT+ (D-15female) PAOUT+ (D-Sub 15-pin male) - Page 33 GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual Connection without brake DA98D Drive Unit 983Ta NC Unit (D-44male) HOLD+ HOLD- +24V PBOUT- PZOUT- PBOUT+ PAOUT- PZOUT+ (D-15 female) PAOUT+ (D-Sub 15male) PCZX *PCZX PCAX RSTP COM+ *PCAX FSTP 983Ta-00-776AX PCBX COM+...
-
Page 34: Gsk983Ta-H/ Gsk983Ta- V Turning Cnc System Connection Manual
GSK983Ta-H/ GSK983Ta-V Turning CNC System Connection Manual GSK983Ta-H/ GSK983Ta- V Turning CNC System Connection Manual Version Upgrading Records Date Version Content 2012-6-19 First Version...
