USP Duramax Yardmate Owner's Manual/ Instructions For Assembly

Vinyl garden shed 5 ft x 3 ft / 1.7 m x 1.0 m
Hide thumbs

Advertisement

Quick Links

Download this manual
A L L
P U R P O S E
V I N Y L
G A R D E N
Vinyl Garden Shed
Vinyl Garden Shed
OWNER'S MANUAL /
Instructions for Assembly '5 Ft YardMate'-V2
Size 5 Ft x 3 Ft / 1.7 m x 1.0 m
Ver: 0.0
Your Total Solution To Maintenance Free Storage Sheds.
• All Weather Durable PVC
• Won't Dent, Rust, Rot or Mildew
• Tall Walk In Shed
• Never Needs Painting
• 53 Inch Wide Double Doors
• Easy Assembly
• Snow Load Tested 20lbs/sq. foot
• Pad Lock Ready (Lock not included)
Available Kits
• Modular 2.5 Ft Extension Kits Available
Approximate
Size
Area
5 Ft x 3 Ft
12 3/4 Sq. Ft. 76 1/2 Cu.Ft.
1.2 Sq.m.
1.7 m. x 1.0 m.
TM
A Product of
S H E D S
Building Dimensions :
Storage
Base Dimension
Volume
Width
Depth
2.2 Cu.m.
Height
(Approx.)
Exterior Dimension
Roof Edge to Edge
inch
cm.
inch
68 1/8
173
63 1/4
37 5/8
95.5
33
78 1/8
Patent #416.091
Customer
Service Hotline
(800) 483-4674
www.duramaxbp.com
Call us for any missing or damaged parts.
Do not return to the store.
Interior Dimension
Wall to Wall
cm.
inch
cm.
160.8
61 1/4
155.7
52 3/4
83.8
30 1/8
76.7
198.5
181.8
71 1/2
Door Opening
inch
cm.
134.1
70
177.8

Advertisement

loading
Need help?

Need help?

Do you have a question about the Duramax Yardmate and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for USP Duramax Yardmate

Summary of Contents for USP Duramax Yardmate

  • Page 1 A Product of A L L P U R P O S E V I N Y L G A R D E N S H E D S Vinyl Garden Shed Vinyl Garden Shed Patent #416.091 OWNER’S MANUAL / Instructions for Assembly ‘5 Ft YardMate’-V2 Size 5 Ft x 3 Ft / 1.7 m x 1.0 m (Approx.)
  • Page 2 Duramax Garden Shed Limited Fifteen Year Warranty U.S. Polymer Inc. will send a replacement part free of charge, in the event of material defects and or workmanship for a period of fifteen years from the date of purchase. This warranty is extended only to the original purchaser. A purchase receipt or other proof of date of original purchase will be required before warranty service is rendered.

  • Page 3: Safety And Precautions

    SAFETY & PRECAUTIONS Before You Begin... 1. Check your local building codes regarding footings, location, etc. 2. Select a site that allows enough working space around the shed. 3. Determine building foundation and anchor system. 4. Read and understand the Owner’s manual enclosed in the package. 5.
  • Page 4 SAFETY & PRECAUTIONS For your own safety, please read and follow these instructions during the shed assembly. 1. Always wear work gloves, long sleeves and eye protection during assembly of the shed. Some pieces of the shed contain sharp edges and can cause injury. 2.

  • Page 5: Care And Maintenance

    IMPORTANT Wear eye protection when using any form of power tools. Do not use voltage power tools in a wet or damp enviornment to avoid electric shock. Do not use any part of the shed as a means of personal support while attaching components during assembly. The shed must be constructed on a solid base foundation.
  • Page 6 Parts List PARTS ACCESSORIES CODE CODE CODE FCLE FDCL FCLE FDCR FCRE FCRE CB2E CB2B RS1E RS2E RS3E RS5E RS14E DSHE RS1E, RS3E DSHE CB2B, CB2E RS2E RS14E 1. Before starting installation, please refer Note Safety & Precautions. 2. Maximum no. of Extension can be build RS5E upto 5’x8’...

  • Page 7: Exploded View

    Exploded View RS14E RS14E RS2E RS3E RS1E RS5E RS2E DSHE RS5E RS2E RS2E RS3E RS1E CB2B CB2E FCLE FCRE CB2E...
  • Page 8 A. Wall & Columns 1. It is important that these instructions Note are followed step by step. 2. All parts are clearly marked and care should be taken to use the correct one. 3. Don’t install under windy conditions. 4. If you are building the shed against a wall, build it 2.5 ft.
  • Page 9 FCRE FCRE FCRE Back Fig.1 FCRE Fig.2 2&3 Front Fig.3 Check the stamped label on top Note of all panels inside. FCRE FCRE Front Fig.1 Fig.1 Fig.2 2&3 Back Fig.3...
  • Page 10 Do not tighten the screw. Note Leave it loose FCRE FCRE Front Fig.1 Fig.2 CB2E CB2E FCRE CB2E FCRE Front Fig.2 Fig.1 Fig.1 Fig.2 Back...
  • Page 11 Fig.2 Fig.1 1&3 Back Fig.3 1&2 CB2B CB2B CB2E Back CB2B Fig.1 Fig.2 CB2B Fig.3 Back Fig.1...
  • Page 12 Fig.1 Fig.2 2&3 Fig.3 Do not tighten the screw. Note Leave it loose Fig.1 CB2B Fig.1 CB2B...
  • Page 13 A. Wall & Columns 1. It is important that these instructions Note are followed step by step. 2. All parts are clearly marked and care should be taken to use the correct one. 3. Don’t install under windy conditions. 4. If you are building the shed against a wall, build it 2.5 ft.
  • Page 14 CB2E CB2E FCLE Fig.1 Fig.2 2&3 FCLE CB2B CB2E CB2E Fig.3 After completing the center band Note assembly(CB2B & CB2E), fully tighten the four center band fittings (FCB) to the corner column.
  • Page 15 B. Roof Structures Parts Needed Code RS1E RS2E RS3E RS5E DSHE FDCL FDCR Back 1&2 Fig.1 Fig.2 1&2 Fig.1 Fig.2 FCRE 3&4 FCLE FCLE FCLE Fig.3 Fig.4...
  • Page 16 1&2 FDCR FDCR Front FCRE FCRE FCRE FDCL 3&4 Fig.1 Fig.2 FDCL FDCL FCLE FCLE Fig.3 Fig.4 Make Two Sets Note RS3E RS3E RS3E...
  • Page 17 RS1E 1&2 RS1E RS1E Front FDCR FCRE FCRE 3&4 Fig.1 Fig.2 RS1E RS1E FCLE FCLE FDCL Fig.3 Fig.4 RS1E RS1E Front DSHE DSHE DSHE 1&2 Fig.1 Fig.2 DSHE Fig.3...
  • Page 18 RS1E Back RS1E RS3E RS1E RS1E 1,2&3 Fig.1 Fig.2 RS3E Fig.3...
  • Page 19 Back RS5E RS1E RS5E Fig.1 RS5E RS5E RS1E Fig.2 RS2E RS2E RS2E RS2E RS2E RS5E RS5E RS2E Fig.1 Fig.2 RS2E RS2E RS3E RS3E Fig.3 Fig.4...
  • Page 20 C. Roof Panels Insert roof plugs into Facia Panel Note only as indicated. Parts Needed Code RS14E Apply silicone around the roof Note plugs and the pin holes before fixing the pins. Back Front Back...
  • Page 21 Use a screw driver to align the Note holes. Insert roof plugs into roof panels only as indicated. Back Back Apply silicone around Note Back the roof plugs. RS5E RS5E RS14E RS14E RS3E Outside View RS3E Inside View...
  • Page 22 D. Door Parts Needed Code Fig.1 Fig.2...

  • Page 23: Ventilation Kit

    E. Ventilation Kit Parts Needed: TOOLS YOU WILL NEED CODE Power Drill Dia 3/16” (5mm) drill bit Dia 1/2” (12.5mm) drill bit Note Optional ventilation kits can be installed on any of the wall panels. However, we recomend mounting them on the top of the shed’s back wall. Outside Outside...
  • Page 24 ADDITIONAL ACCESSORIES AVAILABLE These accessories are required in case of heavy snow or high wind areas. Please choose relevant accessories according to your needs. ANCHOR KIT (Soil) Wire rope with twist augers for sheds installed with foundation (Wood / Metal) on soil. For heavy wind area.
  • Page 25 U.S. Polymers, Inc. 1057 S. Vail Ave Montebello, CA 90640, United States of America...
