- Page 1 OOH-LA-LA SWIVEL CHAIR ASSEMBLY INSTRUCTIONS Date: 2013-Oct-03 Rev: 2013-Dec-02 www.pbteen.com Page 1 of 4...
- Page 2 We do not recommend the use of chemical cleansers, abrasives, or furniture polish on our lacquered finish. • Hardware may loosen over time. Periodically check to make sure all connections are tight. Re-tighten if necessary. Date: 2013-Oct-03 Rev: 2013-Dec-02 www.pbteen.com Page 2 of 4...
- Page 3 Insert the Short Bolt with washers through pre-drilled holes in the Metal Bracket into insert nuts located on the seat bottom and secured with an Allen Key (D) as shown below. Repeat for the remaining (3) Short Bolts then tighten all bolts. Date: 2013-Oct-03 Rev: 2013-Dec-02 www.pbteen.com Page 3 of 4...
- Page 4 Philip Head Screw inside the black metal cap on Chair Base is fully engaged, but do not over tighten. This prevents the seat from lifting out of the Cylinder Metal Cap for Seat Height Adjustment Seat Tilt Adjustment Date: 2013-Oct-03 Rev: 2013-Dec-02 www.pbteen.com Page 4 of 4...
