LG LSXC22486 Series Owner's Manual
  1. Manuals
  2. Brands
  3. LG Manuals
  4. Refrigerator
  5. LSXC22486 SERIES
  6. Owner's manual

LG LSXC22486 Series Owner's Manual

Side by side refrigerator
Hide thumbs Also See for LSXC22486 Series:
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
SIDE BY SIDE
REFRIGERATOR
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
LSXC22486*/LSXC22436*/LSXC22426*
MFL67653499
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSXC22486 Series and is the answer not in the manual?

Questions and answers

Geri Spencer
June 25, 2025

How do I open the top shelf on the right door?
