LG GS73SXS Owner's Manual

Hide thumbs Also See for GS73SXS:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
OWNER'S MANUAL
SIDE BY SIDE
REFRIGERATOR
Read this owner's manual thoroughly before operating the appliance
and keep it handy for reference at all times.
LSXS26366*
GS73SXS
LSXS26386*
GS74SXS
GS73SDS
LSXS26396*
GS74SDS
LSXC22396*
GS73SGS
LS74SXS
GS74SGS
LSXS26326B
GS73SDD
LSXS26326W
MFL67653459
Rev.06_081318
LSXS26336*
GS73SGG
LSXS22423*
Copyright © 2017-2018 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG GS73SXS

Summary of Contents for LG GS73SXS

  • Page 1 Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. LSXS26366* LSXS26336* GS73SXS LSXS26386* GS73SGG GS74SXS GS73SDS LSXS22423* LSXS26396* GS74SDS LSXC22396* GS73SGS LS74SXS GS74SGS LSXS26326B GS73SDD LSXS26326W www.lg.com MFL67653459 Rev.06_081318 Copyright © 2017-2018 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRODUCT FEATURES 37 MAINTENANCE Cleaning Replacing the Water Filter SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 43 TROUBLESHOOTING FAQs: Frequently Asked Questions PRODUCT SPECIFICATIONS Before Calling for Service PRODUCT OVERVIEW 53 WARRANTY (USA) Exterior Interior 56 WARRANTY (CANADA) 11 INSTALLATION 60 NOTES Installation Overview Unpacking the Refrigerator...

  • Page 3: Product Features

    PRODUCT FEATURES PRODUCT FEATURES Depending on the model, some of the following functions may not be available. FILTERED WATER AND ICE DISPENSER The water dispenser dispenses fresh, chilled water. The ice dispenser dispenses cubed and crushed ice. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer door remains open.

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. These words mean: CAUTION You may be injured or cause damage to the product if you do not follow instructions.
  • Page 5 SAFETY INSTRUCTIONS • Keep packing materials out of the reach of children. Packaging material can be dangerous for children. There is a risk of suffocation. • Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may deteriorate. •...

  • Page 6: Grounding Instructions

    SAFETY INSTRUCTIONS • If connected to a circuit protected by fuses, use time delay fuse. • MAINTENANCE • Do not use a hair dryer to dry the inside of the refrigerator. • Do not light a candle to remove odors in the refrigerator. •...
  • Page 7 SAFETY INSTRUCTIONS CAUTION To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: • Do not hang on to or place heavy objects on the refrigerator’s dispenser. INSTALLATION •...

  • Page 8: Product Specifications

    Min. / Max. water pressure: Model 22 cu. ft. LSXC22396*, LSXS22423*. Description Standard-depth, Side by Side refrigerator Net weight 280 libras (127 kg) Model 26 cu. ft. GS73SXS,GS74SXS,LSXS26396*,LS74SXS,LSXS26326B,LSXS26326W,LSXS26366*,LSXS26386*,GS73SDS, GS74SDS,GS73SGS,GS74SGS,GS73SDD,LSXS26336*,GS73SGG. Description Counter-depth, Side by Side refrigerator Net weight 306.5 libras ( 139 kg )

  • Page 9: Product Overview

    PRODUCT SPECIFICATIONS PRODUCT OVERVIEW The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Exterior Filtered Water and Ice Dispenser Handle Dispenses purified water and ice.

  • Page 10: Interior

    10 PRODUCT SPECIFICATIONS Interior GS73SXS / LSXS26366*/ LSXS26386*/ GS73SD*/ GS74SDS / GS73SGS /GS74SGS / LSXS26336* / GS73SGG / LSXS22423*/ GS74SXS / LSXS26396* / LSXC22396* / LS74SXS / LSXS26326* / Automatic Icemaker Refrigerator Shelf Automatically produce and store ice. Shelves are adjustable to suit individual storage needs.

  • Page 11: Installation

    INSTALLATION INSTALLATION Installation Overview location. Unpacking the Refrigerator Choosing the Proper Location Disassembling/Assembling Connecting the Water Line Leveling and Door Alignment CAUTION • Connect to a potable water supply only. Note • Parts, functions, and options vary by model. Your model may not include all the Options, appears with a different name and / or different position.

  • Page 12: Unpacking The Refrigerator

    12 INSTALLATION Unpacking the Refrigerator Choosing the Proper Location WARNING Water Water supply must be easily connected for the • Use two or more people to move and install the automatic icemaker. refrigerator. Failure to do so can result in back injury or other injury.

  • Page 13: Dimensions And Clearances

    INSTALLATION Dimensions and Clearances • refrigerator through doors or narrow openings. • Assembling the Doors and Drawers in this manual. • The installation location chosen for the refrigerator should allow space behind the unit for connections and • Too small of a distance from adjacent items may result in lowered freezing capability and increased electricity consumption charges.

  • Page 14: Removing/Assembling Handles

    14 INSTALLATION Removing/Assembling Assembling the Refrigerator Handles Handles Assemble the mounting fasteners (1) at both ends of the handle with a 1/4 in. Allen rench. • When moving the refrigerator through a narrow opening, removing the doors is preferred. • The appearance of the handles may vary from what Place the handle on the door by fitting the handle is shown.
  • Page 15 INSTALLATION Removing the Freezer Door (with Lift the door to remove it from the lower hinge pin. Water Line Connection) Be careful to pull the water lines from behind the lower hinge pin. Enough for the water feed tube to be completely Before removing freezer door, disconnect water pulled out.
  • Page 16 16 INSTALLATION Disassembling/Assembling the Water Lines Lift the door from the lower hinge pin. Collet Tube Insert line Clip (Correct) Lower Hinge Gently press the collet and insert the tube until CAUTION only one line shows on the tube. • When lifting the hinge free of the latch, be careful that the door does not fall forward.

  • Page 17: Connecting The Water Line

    INSTALLATION Connecting the Water Line Assembling the Refrigerator Door Before Beginning Place the door onto the lower hinge pin. This water line installation is not covered by the refrigerator warranty. Follow these instructions carefully to minimize the risk of expensive water damage.

  • Page 18: Water Line Installation Instructions

    18 INSTALLATION If the water pressure from the reverse osmosis • Shutoff valve to connect to the cold water line. system is less than 20 psi or 138 kPa or 1.4 kgf/ cm The shutoff valve should have a water inlet with a (takes more than 4 seconds to fill a cup of 7 oz or minimum inside diameter of 5/32 in.
  • Page 19 INSTALLATION Drill the hole for the valve. Route the tubing. • Drill a ¼ in. hole in the water pipe using a sharp Route the tubing between the cold water line and bit. Remove any burrs resulting from drilling the the refrigerator.

  • Page 20: Leveling And Door Alignment

    20 INSTALLATION Leveling and Door Alignment Connect the tubing to the refrigerator. Leveling NOTE The refrigerator has two front leveling legs. Adjust the • Before making the connection to the refrigerator, be legs to alter the tilt from front-to-back or side-to side. sure that the refrigerator power cord is not plugged If the refrigerator seems unsteady, or the doors do into the wall outlet.

  • Page 21: Turning On The Power

    INSTALLATION Turning on the Power Door Alignment Both the left and right refrigerator doors have an • After installing, plug the refrigerator’s power cord adjustable nut, located on the bottom hinge, to raise into a 3-prong grounded outlet and push the and lower them to align properly.

  • Page 22: Operation

    22 OPERATION OPERATION Before Use Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION • Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator.

  • Page 23: Control Panel

    OPERATION Control Panel Depending on the model, some of the following functions may not be available. Control Panel Features Ice Type Press the Ice Type button to choose either cubed or crushed ice. The Cubed or Crushed Ice icon illuminates. * Water Filter Replace Filter icon turns on.

  • Page 24: Airflow

    20 seconds. * Wi-Fi To deactivate / activate: The Wi-Fi button, when used with the LG • With either refrigerator door opened, press and Smart Refrigerator smart phone app, allows the hold the Refrigerator and Ice Plus buttons at the refrigerator to connect to a home Wi-Fi network.

  • Page 25: Ice And Water Dispenser

    • Keep containers at an appropriate distance from • If ice or water dispenses unexpectedly, turn off the dispensers. Tall, narrow glasses should be the water supply and contact an LG Electronics held far enough from the ice outlet to prevent ice Customer Information Center.

  • Page 26: Ice Compartment

    26 OPERATION Cleaning the Dispenser Drip Tray CAUTION Grip the drip tray with both hands and pull it out. • When handling the ice bin, keep hands away from the icemaker tray area to avoid personal injury. • Storing cans or other items in the ice bin will damage the icemaker.

  • Page 27: Automatic Icemaker

    OPERATION Automatic Icemaker Turning the Automatic Icemaker On To turn the automatic icemaker On/Off, press and hold the Ice On/Off button on the control panel for three seconds. Normal Sounds You May Hear • Keeping the power turned on to the icemaker before the water line is connected can damage the icemaker.

  • Page 28: Storing Food

    28 OPERATION Storing Food Where to Store Food Each compartment inside the refrigerator is designed to store different types of food. Store food in the optimal space to enjoy the freshest taste. In-Door Ice Bin Fresh Zone If a large amount of ice is needed, transfer the Store fruit and vegetables in the crisper drawers ice in the in-door ice bin to an ice storage bin in to keep them fresh.

  • Page 29: Food Storage Tips

    OPERATION Food Storage Tips CAUTION Wrap or store food in the refrigerator in airtight and moisture-proof material unless otherwise noted. This • Do not overfill or pack items too tightly into door prevents food odor and taste transfer throughout the bins.

  • Page 30: Detaching/Assembling The Storage Bins

    30 OPERATION Detaching/Assembling the Storing Frozen Food Storage Bins Check a freezer guide or a reliable cookbook for further information about preparing food for freezing or food storage times. Fresh Zone Drawer The Fresh Zone drawers provide storage for fruit and Freezing vegetables.

  • Page 31: Instaview Function

    OPERATION InstaView Function Removing the Fresh Zone Cover Hold the cover with both hands and pull it out. The InstaView function on the Door-in-Door lets you see if you’re running low on frequently used items like beverages and snacks, without opening the refrigerator door.

  • Page 32: Adjusting The Refrigerator Shelves

    32 OPERATION Door-in-Door Case Detaching the Shelf To open the Door-in-Door case, pull evenly on the Remove all items from the shelf. Lift the back of marked area. The Door-in-Door Case is removable the shelf slightly to disengage the rail stops. for easy cleaning and adjustment.

  • Page 33: Smart Functions

    NOTE Connect your smartphone to the wireless router. • If you choose the simple login to access the LG SmartThinQ application, you must go through the appliance registration process each time you change your smartphone or reinstall the application.
  • Page 34 LG SmartThinQ Settings → Edit Product and register again. • Reorient or relocate the receiving antenna. • This information is current at the time of publication.

  • Page 35: Smart Grid Function

    • When the refrigerator operates in DAL mode, the available for download. Grid LED is illuminated on the refrigerator display. LG Electronics will also provide open source code • DAL mode is automatically deactivated after the to you on CD-ROM for a charge covering the cost period stipulated by the DAL signal (max.

  • Page 36: Smart Diagnosis™ Function

    Demand Response signal is sent. You can reactivate it. also override the Smart Grid function using the smart phone app. LG Open API You can manage Smart Grid features for the LG Smart Refrigerator. page on us.smartthinq.com. Open the right refrigerator door. API list...
  • Page 37 SMART FUNCTIONS NOTE • For best results, do not move the phone while the tones are being transmitted. • If the call center agent is not able to get an accurate recording of the data, you may be asked to try again. •...

  • Page 38: Maintenance

    MAINTENANCE MAINTENANCE For products with a standard stainless steel exterior, of the grain. Dry with a paper towel to avoid streaks. Cleaning of liquid dish soap in water, and rinse with hot water before drying. Do not use abrasive or harsh cleaners. WARNING Inside Walls •...

  • Page 39: Replacing The Water Filter

    (around 1 oz. or 25 cc) to drain. • • Visit your local dealer or distributor cover to collect any leaking water. Hold the water • lg.com • Use replacement cartridge: ADQ74793501(LT1000P) For further assistance, call: 1-800-243-0000 (USA) counterclockwise.
  • Page 40 40 MAINTENANCE Performance Data Sheet Model: LT1000P Use Replacement Cartridge: MDJ64844601(LT1000P) The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ANSI Standard 42, Standard 53 and Standard 401.
  • Page 41 MAINTENANCE Average NSF specified Average substance Avg % Permissible Influent Challenge Product Water Reduction Reduction Reduction Product Water Challenge Concentration Concentration Requirements Concentration Atenolol 240 ng/L 200 ± 40% ng/L > 95.50% 10.80 ng/L 30 ng/L Carbamazepine 1600 ng/L 1400 ± 40% ng/L 98.40% 25.60 ng/L 200 ng/L...
  • Page 42 • The disposable filter cartridge MUST be replaced lg.com website. every 6 months, at the rated capacity or if a For further assistance, the LG Electronics Customer noticeable reduction in flow rate occurs. Information Center is open 24 hours a day/7 days a •...

  • Page 43: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING FAQs: Frequently Asked Questions What are the best temperature settings for my refrigerator and freezer? The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). The default setting for the freezer is 0° Fahrenheit (-18° Celsius). Adjust these settings as necessary to keep food at desired temperatures.

  • Page 44: Before Calling For Service

    44 TROUBLESHOOTING Before Calling for Service Review this section before calling for service; doing so will save you both time and money. Cooling Problem Possible Cause Solutions The refrigerator control is set Turn the control ON. Refer to the Setting the Controls to OFF (some models).
  • Page 45 TROUBLESHOOTING Cooling Problem Possible Cause Solutions When the doors are opened often or for long periods of time, warm, humid air enters the compartment. This Doors are opened often or for raises the temperature and moisture level within the long periods of time. compartment.
  • Page 46 46 TROUBLESHOOTING Cooling/Ice & Water Problem Possible Cause Solutions When the doors are opened often or for long periods of time, warm, humid air enters the compartment. This Doors are opened often or for raises the temperature and moisture level within the long periods of time.
  • Page 47 TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Demand exceeds ice storage The icemaker will produce approximately 70-184 cubes capacity. in a 24 hour period. Connect the refrigerator to a cold water supply with House water supply is not adequate pressure and turn the water shutoff valve fully connected, valve is not turned on open.
  • Page 48 48 TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Foreign substances or frost on the ice-detecting sensor The ice detecting sensor is can interrupt ice production. Make sure that the sensor obstructed. area is clean at all times for proper operation. The refrigerator is not connected to Connect the refrigerator to the water supply and turn the a water supply or the supply shutoff...
  • Page 49 TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Infrequent use of the ice dispenser will cause the cubes to stick together over time, which will prevent them from Infrequent use of the dispenser. properly dispensing. Check the ice bin for ice cubes clumping/sticking together.
  • Page 50 50 TROUBLESHOOTING Ice & Water Problem Possible Cause Solutions Refrigerator or freezer doors are not Water will not dispense if any of the refrigerator doors closed properly. are left open. After the water filter is replaced, dispense 2.5 gallons of water (flush for approximately five minutes) to remove Water filter has been recently trapped air and contaminants from the system.
  • Page 51 TROUBLESHOOTING Parts & Features Problem Possible Cause Solutions Food packages are blocking the Rearrange food containers to clear the door and door door open. shelves. Ice bin, crisper cover, pans, shelves, Push bins all the way in and put crisper cover, pans, door bins, or baskets are out of shelves and baskets into their correct positions.
  • Page 52 52 TROUBLESHOOTING Noises Problem Possible Cause Solutions The defrost control will click when the automatic defrost cycle begins and ends. The thermostat control Clicking Normal Operation (or refrigerator control on some models) will also click when cycling on and off. Rattling noises may come from the flow of refrigerant, the water line on Normal Operation...

  • Page 53: Warranty (Usa)

    Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics (“LG”) will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product and applies only when purchased and used within the United States including U.S.
  • Page 54 If you and LG are unable to resolve the dispute within 30 days, either party...
  • Page 55 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar optout@lge.com, with the subject line: “Arbitration Opt Out”...
  • Page 56 Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. (“LGECI”) will, at its option, repair or replace the Product upon receipt of proof of the original retail purchase. This limited warranty is valid only to the original retail purchaser of the Product and applies only to a Product distributed, purchased and used within Canada, as determined at the sole discretion of LGECI.
  • Page 57 (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
  • Page 58 If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein.
  • Page 59 Limited Warranty. Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar optout@lge.com, with the subject line: “Arbitration Opt Out;”...

  • Page 60: 60 Notes

    60 NOTES...
  • Page 61 LG Customer Information Center For inquiries or comments, visit www.lg.com or call: 1-800-243-0000 U.S.A. 1-888-542-2623 CANADA Register your product Online! www.lg.com...

This manual is also suitable for:
