Appendix I (Computer Mode)

Output Data

When the Computer is enabled during Setup, as an output device, the data is output in a format
that a PC can receive.
The only output for the D4000 Laser is Text Analysis (text) data output
Note:
The D4000 Auto Optic is required for full ISO/ANSI in-
spection and the printable Analog Scan Profile (graphic)
data
Figure I-1 (GS1-128 Failure)
GS1-128 Error
Message
Single Scan Analysis
Encoded bar code data
(stacked data to display
packed Subset-C
numeric characters)
*F0024680211115*
C11135791872329*
Encoded bar code
<*C><F1>010123456789012817121312
data (single line with
59<**>
brackets identifying
control characters)
Mod Check is:............ 8 059
Mod Check expected:...... 8 059 PASS
Decodability
Grade (46% / C)
Decodability........43%....2.4/C
Bar Code Error
Out-Of-Range................FAIL
(GS1 AI (17))
Bar code Width
Deviations Chart
Overall Results D/bility Warning Selected......C
Final Results...............FAIL
Figure I-2 (Code 3 of 9 Passing)
Encoded bar code data
Decodability
Grade (54% / B)
Bar code Width
Deviations Chart
002-7858
Inspector D4000L
Revision A.12
GS1-128
AI ( 17)
Scan Profile Analysis
Traditional Analysis
-100% Tol. +100%
-----RA-++++++++
Pass/Fail Analysis
Inspector D4000L
Revision A.12
Single Scan Analysis
Code 3of9
*P003299*
Scan Profile Analysis
Decodability........43%....2.4/C
Acceptable..................PASS
Traditional Analysis
-100% Tol. +100%
--------++AR++++
Wide/Narrow Ratio.......2.2 PASS
45
