- Page 1 D e t e c t i o n Quick Start Guide NEO Photo-ionization Detector...
- Page 2 Warnings Read Before Operating The NEO’s User’s Guide must be carefully read by all individuals who have or will have the responsibility of using, maintaining or servicing this product. The product will perform as designed only if it is used, maintained and serviced in accordance with the manufacturer’s instructions.
- Page 3 AVERTISSEMENT • N’utilisez jamais le moniteur lorsque le couvercle est enlevé. • Retirer le couvercle du moniteur et la batterie uniquement dans une zone connue comme non dangereuse. • La substitution de composants compromettra l’aptitude à la sécurité intrinsèque et annulera la garantie. •...
- Page 4 Key for a 5-second count down, until “Unit Off” is displayed. Charging Always fully charge the battery before use. Plug the charger to the bottom of NEO. The battery icon on the LCD shows the charge status. During active charging, the icon cycles from empty to full. Charging/Comm Cable The USB Charging/Communications cable allows charging the unit on a personal computer.
- Page 5 Testing the alarms Important! Test the alarms prior to performing a bump or span calibration test. If any alarm does not respond, check the Alarm Settings in Config Mode to make sure all alarms are enabled (Config Mode › Alm Setting ›...
- Page 6 Enter/Exit Config Mode Press and hold the Up and Down Keys together for 3 seconds, to enter Config Mode. • The Config Mode is password protected. • The default password is “0000”. • After all four digits are entered, move the cursor to √and press the Up Key to enter config mode.
- Page 7 Zero Calibration Zero calibration sets the baseline for the sensor and is done in normal fresh air or other clean air source. • To enter fresh air calibration: Config Mode › Calibration › Zero Calib. • To start fresh air calibration: Press the Right Key and a count-down timer starts.
- Page 8 Maintenance and Service Replace the inlet water trap filter on a regular basis, especially when used in dusty environments. For battery, lamp, or sensor replacement and other maintenance refer to the User Manual or contact the service department of WatchGas.
