Bugflector
For proper installation and best possible fit, please read all instructions BEFORE you begin.
For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219.
Important Safety Information
• CAUTION - Before driving, ensure that the hood shield is properly secured to vehicle.
• Do not use automatic "brush-style" car washes.
• Do not use cleaning solvents of any kind.
• Periodically check all components for tightness.
Contents
NOTE: Actual product may vary from illustration.
Hood shield
Tools Required
Car Wash Supplies
Preparation Before Painting / Installation
• A trial fit is recommended to ensure proper positioning and fit.
• Check fit of parts before painting as we will not accept the return of modified or painted parts.
• Wash and dry your vehicle to remove any debris and/or dirt from the installation area.
Installation Steps
1
Installation Instructions
®
- Bugflector II
Hood Insert x3
Bracket x2
Clean Towel
NOTE: Actual application may vary slightly from illustrations.
Open hood.
®
®
- Carflector
- Chrome Hood Shield
Screws x3
Washer x3
Machine Screw x2
Phillips Screwdriver
Locate (3) square holes on underside of hood.
2
Page 1 of 3
I - Sheet Number BF126 Rev.A
Bump Ons x4
Black Plastic Washer x2
Tape
Grease pencil
Protective Film x2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVS Bugflector and is the answer not in the manual?

Questions and answers

Summary of Contents for Lund AVS Bugflector

  • Page 1 Installation Instructions I - Sheet Number BF126 Rev.A ® ® ® ™ Bugflector - Bugflector II - Carflector - Chrome Hood Shield For proper installation and best possible fit, please read all instructions BEFORE you begin. For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219. Important Safety Information •...
  • Page 2: Installation Steps

    Installation Steps NOTE: Actual application may vary slightly from illustrations. Align center holes in hood shield with hood inserts Press (3) hood inserts into the (3) square holes. If installed in Step 3. Note the location of the two necessary use tape to hold them firmly in place. OUTBOARD holes in hood shield and mark with a grease pencil.
  • Page 3: Care And Cleaning

    Congratulations! You have purchased one of the many quality Auto Ventshade™ branded products offered by Lund International. We take the utmost pride in our products and want you to enjoy years of satisfaction from your investment. We have made every effort to ensure that your product is top quality in terms of fit, durability, finish and ease of installation.
  • Page 4: Instructions D'installation

    Instructions d’installation I – Numéro de feuille BF126 Rév. A Bugflector – Bugflector II – Carflector – Chrome Hood Shield Lisez l’ensemble des instructions AVANT d’installer le produit pour assurer une installation adéquate et un ajustement optimal. Pour joindre l’assistance technique ou commander des pièces manquantes, veuillez appeler le service à la clientèle au 1 800 241-7219. Consignes importantes de sécurité...
  • Page 5: Étapes D'installation

    Étapes d’installation REMARQUE : L’installation peut différer légèrement des illustrations. Enfoncez les (3) encarts de capot dans les (3) trous carrés. Alignez les trous centraux de la protection de capot avec les encarts de capot installés à l’étape 3. Notez la position des Si nécessaire, utilisez du ruban adhésif pour les maintenir deux trous EXTÉRIEURS de la protection de capot et faites une solidement en place.
  • Page 6: Entretien Et Nettoyage

    Lund International 800-241-7219 • Visitez notre site lundinternational.com © 2018 Lund, Inc. Tous droits réservés. Auto Ventshade™, le logo Auto Ventshade™ et le logo AVS™ sont des marques déposées Lund, Inc. ™ Page 3 de 3...
  • Page 7: Instrucciones De Instalación

    Instrucciones de instalación I - Número de hoja BF126 Rev.A ® ® ® ™ Bugflector - Bugflector II - Carflector - Chrome Hood Shield Para una instalación correcta y el mejor ajuste posible, lea todas las instrucciones ANTES de comenzar. Para pedir asistencia técnica u obtener piezas faltantes, llame a Atención al Cliente al 1-800-241-7219.
  • Page 8: Pasos Para La Instalación

    Pasos para la instalación NOTA: La aplicación real puede diferir levemente de las ilustraciones. Alinee los orificios centrales de la cubierta del capó con los Presione los (3) insertos del capó en los (3) orificios insertos del capó instalados en el Paso 3. Observe la ubicación cuadrados.
  • Page 9: Cuidado Y Limpieza

    ¡Felicitaciones! Usted ha adquirido uno de los tantos productos de marca de calidad Auto Ventshade™ que ofrece Lund International. Nos enorgullecen mucho nuestros productos y deseamos que disfrute años de satisfacción por su inversión. Nos hemos esforzado mucho para asegurarnos de que su producto sea de gran calidad en cuanto al ajuste, la durabilidad, el acabado y la facilidad de instalación.
