PEBCO®
DUSTLESS LOADING/SELF-CONTAINED DUSTLESS LOADING SPOUTS
8. Place the outer sleeve assembly into the outlet assembly. Do not tighten any attachment bolts at
9. Place the stacking cone assembly back into the outlet assembly and attach the lifting cables to the
10. Raise the assembly up into a position where you can reattach the cone support cables to the lug at
11. Raise the spout until the top of the sleeve can be attached to the inlet assembly. Once attached,
12. After everything is reassembled, check to see if the outlet assembly is level. This can be adjusted
13. Readjust the rotary limit switch full-up/full-down positions as needed. (Refer to Section 6.7 for

6.12 MOUNTING BOLT INSPECTION

Check the mounting bolts. Replace and/or tighten any loose or missing bolts. Use the same quality
of bolts used in installation. This should be done annually.

6.13 SCDLS FILTER INSPECTION AND REPLACEMENT

Filters on SCDLS units should be inspected monthly to insure they are in good working condition.
Filters should be replaced when the static pressure as measured by the Dust Collector Timer
Controller exceeds 4 in (w.c.). The timer controller is contained within an enclosure on the unit.
(Some systems may be configured such that the Dust Collector Timer Controller is connected to a
computer terminal. If this is the case, the pressure can be read directly from the terminal.) So long as
the pressure module is installed, the unit will display the current pressure by default; if this is not the
case, see the manufacturer's data.
!!! WARNING !!!
Prior to performing any maintenance inside the unit, the system must be isolated from all external power
sources. If work is being done on the system and the drive motor engages, it could result in personal
injury or death.
If the static pressure exceeds 4 in (w.c.), the filters can be replaced by removing the access panels
on the plenum (Figure 5).
second ring up from the bottom of the outer sleeve assembly. IT IS IMPORTANT TO CUT FROM
THE BOTTOM UP! After cutting, there should always be a ring at the end of the sleeve.
this time.
outlet assembly.
the top of the inlet. Lower the spout until the cones hang freely, and attach the cone support cables
to the outlet assembly.
lower the spout until the sleeve hangs freely. When the sleeve is straight (no twists), attach the
sleeve to the outlet assembly.
by using the lifting eyebolts.
rotary limit switch adjustment.)
MAINTENANCE RECOMMENDATIONS
