NOTE: D-BOX upgrades the ACM firmware on a regular basis. D-BOX therefore recommends that
you update your equipment to the latest firmware version, upon reception, with the Motion
System Configurator
Each ACM comes with a default configuration based upon the Motion System architecture. Here is the list of the
factory configurations. The letters describing the actuator position refers to the next table.
MOTION SYSTEM
ARCHITECTURE
1 actuator 1 YAW
2 actuators 2 BACK
3 actuators 2 BACK/1 YAW
4 actuators 2 BACK/2 FRONT
1
see the Motion System Configurator installation and user Manual, D-BOX document number 194-914-0010-EN3
S C
YSTEM ONFIGURATOR
1
.
FACTORY
CONFIGURATION
ACTUATOR POSITION
(See figure below)
Y
BL - BR
BL – BR - Y
BL – BR –FL - FR
3
DESCRIPTION
1 ACM-MASTER with 1 horizontal
actuator ensuring the YAW movement
of the simulator.
1 ACM-MASTER with 2 actuators at the
back of the pivot point on the simulator.
1 ACM-MASTER with 2 actuators at the
back of the pivot point on the simulator.
1 ACM-SLAVE with 1 horizontal actuator
ensuring the YAW movement of the
simulator.
1 ACM-MASTER with 2 actuators at the
front end of the simulator.
1 ACM-SLAVE with 2 actuators at the
back end of the simulator.
