TABLE OF CONTENTS Introduction of the Saunova 2.0 Control............3 Precautions .......................3 Power Controller ....................4 Control Unit to Heater ..................5 Contactor Unit ....................6 Sensors ......................6 Sensor location with heaters mounted on the wall ....... 7 Sensor location with heaters mounted on the floor ......7 Technical Diagram .....................8 Maximum Session Time ...................10 ......................10...
INTRODUCTION OF THE SAUNOVA 2.0 CONTROL Congratulations on your purchase of Saunova 2.0 Control Unit! Saunova 2.0 Control Unit is developed to enhance your sauna bathing with a variety of different features. It can adjust temperature, humidity, ventilation and light in your sauna. The Saunova 2.0 Control Units are available on a separate or built-in mounting on the Power Controller.
Power Controller The heater is connected to the electrical The Power controller or the separate control network semi-stationarily with a H07RN-F panel must not be located inside the sauna rubber cable or its equivalent. The use of room or in places where temperature PVC-insulated cable as a connecting cable can exceed 40°C.
Control Unit to Heater Connection Diagram Fig. 3 NOTE! Saunova 2.0 user interface can be installed either inside or outside the sauna room. Only one user interface can be used to control the heater. INSIDE SAUNA ROOM OUTSIDE SAUNA ROOM SENSOR(S) *) T/H ja TS2 USER INTERFACE...
Contactor Unit Follow the instructions that are supplied If the heater used is more than 9 kW, together with the contactor unit. an additional contactor is needed. The contactor unit is linked to the main Power Controller with a RJ12 cable (Fig.4). Installation of separate control panel with Fig.
Sensor location with heaters mounted on the wall Fig. 5 TEMPERATURE SENSOR WITH FUSE ON THE WALL Air Vent Sensor 2 (Optional) Temperature Sensor See Airvent installation NOTE Do not place the sensors too near to air ventilation (not under 1000mm) or not under 500mm from air ventilation, which is directed away from sensors.
Technical Diagram Fig. 9 Saunova 2.0 Control Unit Main Switch RJ Data Cable For Heaters more than 9 kW Interface 1 1 0 1 CONTACTOR UNIT Heater >9 kW SESSION 1 2 3 SAU-UI-V2 CONTROL SAFETY SAFETY SWITCH Max. 9.0 kW SWITCH REM ON REM ON...
Maximum Session Time 24 hours, it will be ON constantly. It needs to The maximum sauna session time depends be continuously monitored. on the purpose of the sauna. For domestic use, the total on-time of the sauna is limited The maximum heater on-time is set by to 6 hours.
The Power Controller Main Switch The power controller switch can be found on the top end of the unit. Using this switch, you can isolate the electronics from the mains power supply. In order to put the unit into operation, switch to the first position (switch position I).
DIP Switch SESSION DIP Switch Functions DIP Switch # Function Session time Session time Session time Combi mode Combi mode ON Combi mode OFF Slave Contactor Controller Combi heater with Combi heater with Empty 1 signal (Wm) for 2 signal (Empty & Level) for water level detection water level detection Safety/door switch...
Page 12
Description Power Rating Remarks Description Power Rating Remarks Control Steamer Rated Power 3 Phases 3kW AC1 Rated Power 3 Phases 9kW AC1 Rated Power Single Phase 3kW AC1 (3 x 3kW) Rated Voltage 230V 1N~ Rated Voltage 3 Phases 400V 3N~ Switching capacity 16A (3 Phases), Rated Power Single Phase...
Page 13
Subject to change without notice. www.sawo.com | info@sawo.com...
