- Page 1 USER MANUAL ENGLISH...
-
Page 2: Installation Precautions
UNPACKING Open the box, and take out the speakers and accessories. If you notice any defects in one of the elements as you unpack, please get in touch with your reseller. Before disposing of the packaging, make sure there is nothing left inside. Each box contains : 1 x active SENSA speaker Î... -
Page 3: Connecting The Speakers
POWERING To protect the bottom of your speakers, we recommend using the rubber feet provided. They also make it possible to uncouple the speakers, thus reducing the transmission of vibrations. Connecting the speakers The SENSA speakers must be interconnected with the 3 meters speaker cable provided (black cable mentioning “High performance OFC cable”). - Page 4 DESCRIPTION OF THE SPEAKER 1. RCA / Phono selection 9. Optic input 2. Power LED 10. RCA output (blue if activated / red in standby) 11. Input selection button 3. Auxiliary 1 input (RCA) 12. Volume control button 4. Auxiliary 2 input (1/8-inch (3.5mm) Jack) 13.
- Page 5 DESCRIPTION OF THE REMOTE 1. Power on/Standby 6. Bass adjustment 2. Increasing/decreasing the volume 7. Source selection 3. Skip forward/backward 8. Play/pause a track (Bluetooth mode only) (Bluetooth mode only) 4. Resetting the bass/treble adjustments 9. Mute 5. Treble adjustment When using the remote, always direct it towards the receiver on the front of the main speaker.
-
Page 6: Connecting Sources
Î When you search on your Bluetooth device (refer to the owner’s guide if needed), the SENSA speakers should appear under the name "SENSA SN01A" or "SENSA SN03A", you can then connect to them. Your speakers are now linked to your device and will reproduce the sound from the device. - Page 7 Connection via an RCA cable An RCA cable (included) enables you to connect your SENSA speakers to your television, CD player or other devices. To do so : Î Plug the red and white connectors into “RCA INPUT” on the back of the SENSA speaker, following the colours and do the same on the source.
- Page 8 Connection via a 1/8-inch (3.5mm) jack cable A 1/8-inch (3.5mm) jack cable (included) enables you to connect your SENSA speakers to many devices: smartphone, audio player, tablet, computer, television... To do so : Î Plug one end of the jack connector into the “AUX INPUT” terminal and the opposite end into your device.
- Page 9 CONNECTING AMPLIFIED DEVICES Connecting amplified external devices such a subwoofer Your SENSA speakers can be paired with a subwoofer or an additional pair of SENSA speakers. To do so, follow the designated colours to connect an RCA cable to the RCA OUTPUT and to your second system (please refer to the user manual of the second device), you can then use a subwoofer or connect an additional pair of amplified speakers.
- Page 10 BASS AND TREBLE ADJUSTMENT Your SENSA speakers have a band equalizer that enables you to adjust the low and high frequencies as you like. Adjusting the amount of bass: 6 positions available in 2dB steps over a range between 30 and 400Hz. (-6dB, -4dB, -2dB, 0dB, +2dB, +4dB, +6dB).
- Page 11 CAUTION To avoid the risk of electric shock, do not open the speaker.
- Page 12 ENCEINTES SENSA / SENSA SPEAKERS Spécifications techniques SENSA SN01A SENSA SN03A Technical specifications Enceintes actives bass-reflex Enceintes actives bass-reflex Type Active speakers Active speakers Diamètre haut-parleurs 1x10cm / 1x25mm 1x13cm / 1x25mm Driver diameters 1x4" / 1x1" 1x5" / 1x1"...
- Page 13 SENSA SN01A SENSA SN03A...
- Page 14 - DESIGN BY TRIANGLE IN FRANCE - ASSEMBLED IN CHINA...
