NOTTINGHAM ANALOGUE STUDIO INTERSPACE JUNIOR Setup Instructions

CONGRATULATIONS ON PURCHASING YOUR NOTTINGHAM ANALOGUE TURNTABLE.
WE RECOMMEND THESE INSTRUCTIONS BE READ AT LEAST ONCE BEFORE SETUP
WITH CARE UNPACK THE COMPLETE CONTENTS OF BOX AND MAKE SURE ALL ITEMS ARE
PRESENT AS PER CHECK LIST ATTACHED.
SET UP AND ASSEMBLY
BEFORE STARTING SETUP, CHECK THE SURFACE YOU INTEND TO USE IS LEVEL AND STRONG
ENOUGH TO TAKE WEIGHT OF TURNTABLE.
STEP 1:- POSITION BASE PLINTH ONTO YOUR CHOICE OF FLAT SURFACE. LEVEL AS REQUIRED
USING THE FOUR ADJUSTABLE FEET. A SPIRIT LEVEL IS PROVIDED. (PHOTO 1)
STEP 2:- MOTOR SETUP GENTLY PRESS THE PULLEY ONTO MOTOR SPINDLE. PUSH ON CENTRALLY.
NOT AT AN ANGLE. YOU WILL FIND IT USEFUL TO SUPPORT THE UNDERSIDE OF MOTOR
WHILST DOING THIS. (PHOTO 2)
STEP 3:- POUR APPROX ½ A CAP (0.5ml) OF OIL INTO BEARING WELL. THE PIPPETTE SUPPLIED CAN
BE USED FOR EASE OF APPLICATION. (PHOTO 3)
STEP 4:- LOWER PLATTER ASSEMBLY INTO BEARING WELL AND ALLOW TO SETTLE. (PHOTO 4)
STEP 5:- ARM SET UP. REFER TO THE INSTRUCTIONS ENCLOSED WITH THE TONE ARM.
ADDITIONAL ARM INFORMATION FOR YOUR TURNTABLE, WE HAVE INCLUDED TWO SMALL FOAM
WEDGES. THESE CAN BE USED TO PREVENT THE PLATTER FROM MOVING DURING TONE ARM
SETUP. SIMPLY RAISE THE PLATTER SLIGHTLY OUT OF THE BEARING, INSERT THE WEDGES IN THE
GAP, LOWER PLATTER ONTO WEDGES AND COMPLETE ARM SETUP. (MAKE SURE PLATTER IS
SETTLED IN BEARING BEFORE COMPLETING ARM SETUP.) REMOVE FOAM WEDGES AFTER ARM
SETUP AND RETAIN FOR FUTURE USE. (PHOTO 5)
