CONGRATULATIONS ON PURCHASING YOUR NOTTINGHAM ANALOGUE TURNTABLE.

WE RECOMMEND THESE INSTRUCTIONS BE READ AT LEAST ONCE BEFORE STARTING.

WITH CARE UNPACK THE COMPLETE CONTENTS OF BOX(S) AND MAKE SURE ALL ITEMS ARE PRESENT AS PER

CHECK LIST ATTACHED.

SETUP AND ASSEMBLY

BEFORE STARTING SETUP, CHECK THE SURFACE YOU INTEND TO USE IS LEVEL AND STRONG ENOUGH TO TAKE

WEIGHT OF TURNTABLE.

STEP 1:- POSITION BASE (PLINTH) ONTO YOUR CHOICE OF LEVEL SURFACE, ADD BEARING CHASSIS

ONTO BASE PLINTH. LEVEL AS REQUIRED USING SPIRIT LEVEL PROVIDED (SEE PHOTO 2)

NOTE:- FRONT AND REAR RIGHT FEET ARE ADJUSTABLE. REAR LEFT LEG IS NON-ADJUSTABLE.

(PHOTO 3). TO ADJUST ARM MOUNT POSITION, IF REQUIRED, LOOSEN ARM MOUNT VIA THE HEXAGON

BOLT (AS INDICATED IN PHOTO 2). MAKE ADJUSTMENT. RETIGHTEN BOLT.

STEP 2:- POUR APPROX 1 & ½ CAPS( 1.5ml) OF OIL INTO BEARING WELL. THE PIPETTE SUPPLIED CAN BE

USED FOR EASE OF APPLICATION. (PHOTO 4)

STEP 3:- LOWER PLATTER ASSEMBLY INTO BEARING WELL AND ALLOW TO SETTLE. (PHOTO 5)

STEP 4:- LOWER GRAPHITE MAT ONTO TOP OF PLATTER. (PHOTO 6)

STEP 5:- PUT THE 3 DAMPING RINGS INTO TOP 3 GROOVES OF PLATTER

STEP 6:- ARM SETUP. FOR THE SET UP OF NOTTINGHAM ANALOGUE TONE ARMS. REFER TO INSTRUCTIONS

SUPPLIED WITH THE TONE ARM.

NOTTINGHAM ANALOGUE

HYPERSPACE

SET UP INSTRUCTIONS

Table of Contents

Do you have a question about the HYPERSPACE and is the answer not in the manual?

Page 1 NOTTINGHAM ANALOGUE HYPERSPACE SET UP INSTRUCTIONS CONGRATULATIONS ON PURCHASING YOUR NOTTINGHAM ANALOGUE TURNTABLE. WE RECOMMEND THESE INSTRUCTIONS BE READ AT LEAST ONCE BEFORE STARTING. WITH CARE UNPACK THE COMPLETE CONTENTS OF BOX(S) AND MAKE SURE ALL ITEMS ARE PRESENT AS PER CHECK LIST ATTACHED.
Page 2 IF YOU ARE USING A TONE ARM FROM AN ALTERNATIVE MANUFACTURER. YOU SHOULD REFER TO THEIR INSTRUCTION SPECIFICATIONS ADDITIONAL ARM INFORMATION FOR THE HYPERSPACE. WE HAVE INCLUDED TWO SMALL FOAM WEDGES. THESE CAN BE USED TO PREVENT THE PLATTER FROM MOVING DURING TONE ARM SETUP.
Page 3 ARM MOUNT ADJUSTMENT BOLT PHOTO 1 PHOTO 2 PUSH PULLEY ON CENTRALLY MOTOR CASSTTE BEARING CHASSIS SPIRIT LEVEL ARM MOUNT STATIC REAR LEG 4ML EARTHING POINT PHOTO 3 PHOTO 4 ADJUSTABLE FEET OIL 1..5ml INTO BEARING WELL...
Page 4 PHOTO 5 PHOTO 6 SPINDLE PLATTER GRAPHITE MAT PHOTO 7 PHOTO 8 FOAM WEDGES X 2 STYLUS GAUGE COMPLETE HYPERSPACE...
