- Page 1 WONDOM ICP3 User Guide IN-CIRCUIT PROGRAMMER WITH BLE BLUETOOTH FOR APP CONTROL - ICP3 By Sure Electronics Co., Ltd.
- Page 2 Overview WONDOM ICP3 is an in-circuit programmer integrated with Bluetooth BLE designed for customer programming and user interface control of WONDOM products. On-board self-boot EEPROM is included in ICP3 for operating the board independently of the Analog Devices, Inc., SigmaStudio™ software.
-
Page 3: Product List
Product List Model Description Basic Cables Included ICP1 DB-DP11219 In-circuit Programmer for ADAU1701 Digital Signal 6Pin cable x 1 ICP3 DB-DP11224 WONDOM In-circuit Programmer with BLE Bluetooth for APP control 6Pin cable x 1 ICP5 DB-DP11226 In-circuit Programmer with UART for PC UI Control & BLE for APP 6Pin cable x 1 Control APM2... -
Page 4: Interface Definition
In this document, we will mainly give instructions on the following applications: How to achieve programming of APM2 / JAB3 with WONDOM ICP3 How to realize APP control of APM2 / JAB3 with WONDOM ICP3 KEY1 For switch between programming and... - Page 5 Open Source Files for PROGRAMMING Products Function File Version Download APM2 Demonstration of Signal Flow Chart APM2_SigmaStudio.dspproj Download JAB3 - Mono Demonstration of Signal Flow Chart JAB3_SigmaStudio_MONO.dspproj Download JAB3 - Stereo Demonstration of Signal Flow Chart JAB3_SigmaStudio_STEREO.dspproj Download Note: All the "Demonstration of Signal Flow Chart" files are just for signal flow chart demonstration and customers can not use them as running programming.
- Page 6 Open Source Files for APP CONTROL Products Function Version File Demonstration of Signal Flow Chart APM2_APPCtrl.dspproj Download APM2 APM2_APPCtrl_V1.0.Hex V1.0 (For Miumax V1.0) Download Restoring Program APM2_APPCtrl_V2.0.Hex V2.0 (For Miumax V2.0) Download Demonstration of Signal Flow Chart JAB3_APPCtrl_MONO.dspproj Download JAB3 - Mono JAB3_APPCtrl_MONO_E2Prom_V1.0.Hex V1.0 (For Miumax V1.0) Download...
- Page 7 Open Source Files for APP CONTROL Version Update Declaration V1.0 Supporting APP - Miumax V1.0 V2.0 Supporting APP - Miumax V2.0 NOTES: 1. All the "Demonstration of Signal Flow Chart" files are just for signal flow chart demonstration and customers can not use them as running programming. If customers want JAB3 or APM2 to be recognized by PC UI or APP, please burn in the corresponding "Restoring Program"...
-
Page 8: Software Download
Software Download PROGRAMMING APP CONTROL Android Analog Devices, Inc. SigmaStudio™ WONDOM ‘Miumax’ Note: It is suggested to use browser to scan the QR code for Android phones. For iOS phones, customers can go to APP Store and search “Miumax” for download directly. - Page 9 As for the original firmware, please click HERE to download. As for how to restore the program, please kindly refer to our video guide on YouTube – “How to use WONDOM ICP3 to program ADAU1701 with SigmaStudio and realize APP control”.
- Page 10 How to achieve programming of APM2/JAB3 with WONDOM ICP3? ICP3 WONDOM IN-CIRCUIT PROGRAMMER WITH BLE VIDEO TUTORIAL > BLUETOOTH FOR APP CONTROL - ICP3...
- Page 11 Checklist Before starting, please make sure you have the following items on hand. Analog Devices, Inc. SigmaStudio™ WONDOM APM2+Extension Kit (APM3)/JAB3 WONDOM ICP3 with a 6-pin cable Accessories Speakers Cables Phone …...
-
Page 12: Quick Start
Quick Start To quickly get started with the programming of WONDOM APM2 or JAB3 via ICP3, do the following steps: 1) Install the SigmaStuido software 2) Connect ICP3 to computer 3) Connect audio cables of APM2/JAB3 4) Power up the audio system 5) Connect ICP3 with APM2/JAB3 6) Program Click... -
Page 13: How To Program
How to program Be sure to follow these connection steps. POWERING UP THE BOARD SETTING UP THE ICP3 CONNECTING ICP3 WITH APM2 / JAB3 INSTALLING SIGMASTUDIO SOFTWARE PROGRAMMING CONNECTING THE AUDIO CABLES... - Page 14 Installing Sigmastudio software Download the installation package for SigmaStudio software in the Analog.com. Download address is as follows. Click the EXE file and finish installation according to the prompts. https://www.analog.com/en/design-center/evaluation-hardware-and- software/software/ss_sigst_02.html#software-overview...
-
Page 15: Setting Up The Hardware
Setting up the hardware 1. Compile the needed program in advance. 2. Set the SW of ICP3 at (PROGRAM)* and connect the ICP3 to the computer with a USB cable. Do not connect ICP3 with target products (APM2/JAB3) now. 3. -
Page 16: Connecting Audio Cables
Connecting Audio Cables This interface extension (APM3) provides three methods of audio input: ✓ RCA ✓ 3.5mm Aux 3.5mm PH-4PIN- ✓ PH-4PIN-2MM Headphone Output Connection This interface extension Use the 10 pin to 10 pin cornoid (APM3) provides three channels to connect APM2 with interface of audio output: extension kit (APM3) for playing... -
Page 17: Powering Up The Board
Powering up the board Make sure the SW1 of APM2 is set at ① (RUN). (Skip this step when programming JAB3) Power up the APM2. 1. Power of APM2: The DSP Kernel Board (APM2) could be powered by: 1) 5V micro USB through micro USB charging port (J2) 2) External 5-12V DC Supply through Vin control port (J3/J4) 3) External 3.3V DC Supply through +3.3V control port (J3/J4) 2. - Page 18 Programming 1.Click the “Link Compile Connect” (see figure 2) 2.Click the “Link Compile Download” (see figure 3) and and you will find “Ready: Compiled” in the you will find “Active: Compiled” in the lower right lower right corner of your computer. corner of your computer.
- Page 19 Original Firmware Restore 1. Right click the “E2Prom” (see Figure 6) and click ‘Read/Write Window’. You will see the following interface (Figure 7). Figure 6 Figure 7 2. Click ‘Click here to browse for file’ and select firmware file (Figure 8). Then click ‘Display File’ like Figure 9. Figure 8 Figure 9...
- Page 20 Original Firmware Restore 3. Click ‘Write Display to E2prom’ then click ‘OK’ of the prompt box (Figure 10). Figure 10...
-
Page 21: Troubleshooting
TROUBLE SHOOTING TROUBLE HOW TO SOLVE ➢ Make sure the Micro USB cable is of good quality and supports data communication ICP3 cannot be recognized by PC ➢ Make sure ICP3 is not connected to controlled device (APM2) when connected to PC ➢... -
Page 22: App Control
How to realize APP Control of APM2/JAB3 with WONDOM ICP3? Miumax ICP3 WONDOM IN-CIRCUIT PROGRAMMER WITH BLE BLUETOOTH FOR APP CONTROL - ICP3 VIDEO TUTORIAL >... - Page 23 Checklist Before starting, please make sure you have the following items on hand. “Miumax” APP WONDOM APM2+Extension Kit (APM3)/JAB3 Android WONDOM ICP3 with a 6-pin cable Accessories Speakers Cables Phone …...
- Page 24 CONTENTS CONNECT ICP3 AND POWER UP APPLICATION NOTES TROUBLE SHOOTING BUILD AN AUDIO SYSTEM WITH APP CONTROL APM2/JAB3...
-
Page 25: Audio System
Audio System WONDOM provides two solution for DSP, - APM2 + Extension Kit (APM3) + Amplifier - JAB3, an audio amplifier with ADAU1701 integrated APM2+ Amplifier Speakers Audio Source JAB3 Speakers Audio Source APM3 19VDC Power Supply 5VDC Power Power Supply Supply Build an audio system with WONDOM APM2 Build an audio system with WONDOM JAB3... - Page 26 Connect ICP3 1. Connect ICP3 to the APM2/JAB3 through the programming port with a 6-pin cable. Pin to Pin Programming Port of DSP/JAB3 Note: When ICP3 is connected to APM2/JAB3 pin to pin, it will be powered by APM2/JAB3 directly. No extra power supply is needed.
- Page 27 Connect ICP3 2. Set SW of ICP3 at (REMOTE) before running “Miumax” APP. 3. Make sure the Bluetooth of your device is on and click “Miumax” APP and they will pair automatically within several seconds. When the connection succeeds, you can see the prompt box. 4.
- Page 28 APP Control Please adjust the parameters slightly according to the specifications of your speakers.
-
Page 29: Application Notes
Application Notes Power-off Memory Function of ICP3 Switch to hardware control Power-off Memory Function is integrated in ICP3 When customers want to switch to hardware for APP control, which means the last setting of control (potentiometers on board integrated with your APP control will be saved in ICP3 and it will be DSP) from APP control mode, please do as follows. - Page 30 POINTS OF ATTENTION Connection Please make sure the Bluetooth of your device is on and the SW of ICP3 is set at (REMOTE) before clicking APP. Adjustment The adjustment through APP control is irreversible. Please pay attention to the limitation of your devices in case of permanent damage. Control Switch Setting of SW on ICP3 Setting of SW1 on APM2...
- Page 31 TROUBLE SHOOTING TROUBLE HOW TO SOLVE ➢ Make sure the Bluetooth of your phone is on APP connection failure ➢ Check the connection according to the steps ➢ Make sure The SW on ICP3 is set at (REMOTE) ➢ The SW on ICP3 is set at (REMOTE) ➢...
