  • Page 1 WONDOM ICP1 User Guide IN-CIRCUIT PROGRAMMER FOR ADAU1701 DIGITAL SIGNAL - ICP1 By Sure Electronics Co., Ltd.
  • Page 2 Overview WONDOM ICP1 is an in-circuit programmer for customer programming of WONDOM products. On-board self-boot EEPROM is included in ICP1 for operating the board independently of the Analog Devices, Inc., SigmaStudio™ software. The package includes: ✓ IN-CIRCUIT PROGRAMMER FOR ADAU1701 DIGITAL SIGNAL - ICP1 x 1 ✓...
  • Page 3: Product List

    Product List Model Description Basic Cables Included ICP1 DB-DP11219 In-circuit Programmer for ADAU1701 Digital Signal 6Pin cable x 1 ICP3 DB-DP11224 WONDOM In-circuit Programmer with BLE Bluetooth for APP control 6Pin cable x 1 ICP5 DB-DP11226 In-circuit Programmer with UART for PC UI Control & BLE for APP 6Pin cable x 1 Control APM2...
  • Page 4: Interface Definition

    In this document, we will mainly give instructions on the following applications: How to achieve programming of APM2 / JAB3 with WONDOM ICP1 How to realize APP control of APM2 / JAB3 with WONDOM ICP1 KEY1 When programming, please make sure Reset SW at ①...
  • Page 5 Open Source Files for PROGRAMMING Products Function File Version Download APM2 Demonstration of Signal Flow Chart APM2_SigmaStudio.dspproj Download JAB3 - Mono Demonstration of Signal Flow Chart JAB3_SigmaStudio_MONO.dspproj Download JAB3 - Stereo Demonstration of Signal Flow Chart JAB3_SigmaStudio_STEREO.dspproj Download Note: All the "Demonstration of Signal Flow Chart" files are just for signal flow chart demonstration and customers can not use them as running programming.
  • Page 6 How to achieve programming of APM2/JAB3 with WONDOM ICP1? ICP1 IN-CIRCUIT PROGRAMMER FOR ADAU1701 DIGITAL SIGNAL - ICP1...
  • Page 7 Checklist Before starting, please make sure you have the following items on hand. Analog Devices, Inc. SigmaStudio™ WONDOM APM2+Extension Kit (APM3)/JAB3 WONDOM ICP1 with a 6-pin cable Accessories Speakers Cables Phone …...
  • Page 8: Quick Start

    Quick Start To quickly get started with the programming of WONDOM APM2 or JAB3 via ICP1, do the following steps: 1) Install the SigmaStuido software 2) Connect ICP1 to computer 3) Connect audio cables of APM2/JAB3 4) Power up the audio system 5) Connect ICP1 with APM2/JAB3 6) Program Click...
  • Page 9: How To Program

    How to program Be sure to follow these connection steps. POWERING UP THE BOARD SETTING UP THE ICP1 CONNECTING ICP1 WITH APM2 / JAB3 INSTALLING SIGMASTUDIO SOFTWARE PROGRAMMING CONNECTING THE AUDIO CABLES...
  • Page 10 Installing Sigmastudio software Download the installation package for SigmaStudio software in the Analog.com. Download address is as follows. Click the EXE file and finish installation according to the prompts. https://www.analog.com/en/design-center/evaluation-hardware-and- software/software/ss_sigst_02.html#software-overview...
  • Page 11: Setting Up The Hardware

    Setting up the hardware 1. Compile the needed program in advance. 2. Set the SW of ICP1 at  (PROGRAM)* and connect the ICP1 to the computer with a USB cable. Do not connect ICP1 with target products (APM2/JAB3) now. 3.
  • Page 12: Connecting Audio Cables

    Connecting Audio Cables This interface extension (APM3) provides three methods of audio input: ✓ RCA ✓ 3.5mm Aux 3.5mm PH-4PIN- ✓ PH-4PIN-2MM Headphone Output Connection This interface extension Use the 10 pin to 10 pin cornoid (APM3) provides three channels to connect APM2 with interface of audio output: extension kit (APM3) for playing...
  • Page 13: Powering Up The Board

    Powering up the board Make sure the SW1 of APM2 is set at ① (RUN). (Skip this step when programming JAB3) Power up the APM2. 1. Power of APM2: The DSP Kernel Board (APM2) could be powered by: 1) 5V micro USB through micro USB charging port (J2) 2) External 5-12V DC Supply through Vin control port (J3/J4) 3) External 3.3V DC Supply through +3.3V control port (J3/J4) 2.
  • Page 14 Programming 1.Click the “Link Compile Connect” (see figure 2) 2.Click the “Link Compile Download” (see figure 3) and and you will find “Ready: Compiled” in the you will find “Active: Compiled” in the lower right lower right corner of your computer. corner of your computer.
  • Page 15 Original Firmware Restore 1. Right click the “E2Prom” (see Figure 6) and click ‘Read/Write Window’. You will see the following interface (Figure 7). Figure 6 Figure 7 2. Click ‘Click here to browse for file’ and select firmware file (Figure 8). Then click ‘Display File’ like Figure 9. Figure 8 Figure 9...
  • Page 16 Original Firmware Restore 3. Click ‘Write Display to E2prom’ then click ‘OK’ of the prompt box (Figure 10). Figure 10...
  • Page 17: Troubleshooting

    TROUBLE SHOOTING TROUBLE HOW TO SOLVE ➢ Make sure the Micro USB cable is of good quality and supports data communication ICP1 cannot be recognized by PC ➢ Make sure ICP1 is not connected to controlled device (APM2) when connected to PC ➢...
