Geokon GeoNet 8800 Series Product Tutorial

Hide thumbs Also See for GeoNet 8800 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Product Tutorial

Advertisement

Table of Contents
loading

Related Manuals for Geokon GeoNet 8800 Series

Summary of Contents for Geokon GeoNet 8800 Series

  • Page 1 Product Tutorial...
  • Page 2 Installing GeoNet Networks...
  • Page 3 Topics Covered in this Tutorial Initial Set Up  Powering the Network  Network Considerations  Connecting Sensors to Nodes  Final Steps ...

  • Page 4: Initial Setup

    Initial Setup...

  • Page 5: Getting Started

    Getting Started Begin with the Network  Supervisor and one Node The Node and Supervisor  should be in close proximity during setup...
  • Page 6 Attach the Antennae Complete the following with the Supervisor and the Node: Remove the rubber cap from the antenna mount Position the antenna on the mount Thread the antenna onto the mount by rotating the antenna clockwise until finger tight...

  • Page 7: Remove The Covers

    Remove the Covers Using a Phillips head screwdriver, loosen the cover screws by turning them counterclockwise Remove the covers from both units...

  • Page 8: Install The Batteries

    Install the Batteries Complete the following with the Supervisor and the Node: Align the positive (+) side of the D cell batteries with the left side of the battery holder Push the batteries straight down into the holder...
  • Page 9 Powering the Network...
  • Page 10 Power the Devices Power the Supervisor first, by moving the battery selector switch to ALKALINE or LITHIUM, depending on the type of batteries installed (The green LED on the side of the unit will flash twice, indicating it has power) Power the Node in the same manner as the Supervisor...
  • Page 11 Joining the Network The Node will connect to the  Supervisor within 20 seconds The red LED on the Supervisor  and the green LED on the Node will begin to flash simultaneously The Network Supervisor and  one Node is the minimal working Network size The Node will not collect data until the Network time has ...
  • Page 12 Adding More Nodes Additional Nodes can be added  to the Network for the next 60 minutes, while the Supervisor is in “deployment mode” If a Node does not join the  Network within 20 seconds of power up, it is out of range, on the wrong channel, or the Supervisor has left deployment mode The amount of time the Supervisor...

  • Page 13: Network Considerations

    Network Considerations...
  • Page 14 Network Considerations Nodes collect data from  sensors and forward the data to the Supervisor When installing Nodes, start  with those closest to the Supervisor and work outwards Place the Supervisor in the  center of the Network wherever possible...
  • Page 15 Network Considerations (Continued) GeoNet devices can only  communicate with other devices that are within range of their radio signal Radio ranges vary by model  and can be affected by the radio environment and obstructions (See the GeoNet instruction manual for complete radio specifications)
  • Page 16 Network Considerations (Continued) Nodes can communicate with  the Supervisor over greater distances and work around obstacles by using other Nodes as repeaters Each transmission from Node  to Node or Node to Supervisor is known as a “Hop” Up to four Hops can be made ...
  • Page 17 Network Considerations (Continued) GeoNet automatically  minimizes the number of hops each Node uses by bypassing Nodes which are not needed as repeaters...
  • Page 18 Network Considerations (Continued) Obstructions between,  around, or near GeoNet devices can cause reflections of the radio signal Reflected radio signals can  cause GeoNet devices to malfunction For optimum performance,  create as much space as possible between the straight line radio path and any obstructions (especially metallic objects)
  • Page 19 Connecting Sensors to Nodes...
  • Page 20 Connecting Sensors to Nodes Depending on the model of the Node, sensors are connected by  either a bulkhead connector (A) or bare leads (B)
  • Page 21 Connecting Sensors to Nodes: Bulkhead Connectors Remove the cap from the Node connector by rotating it counterclockwise Align the grooves of the sensor connector with the grooves of the Node connector Push the sensor connector into Node connector Twist the outer ring of the sensor connector clockwise until it locks into place...
  • Page 22 Connecting Sensors to Nodes: Bare Leads Loosen the cable gland nut and remove white plastic dowel Slide the sensor cable through the cable nut and cable gland...
  • Page 23 Connecting Sensors to Nodes: Bare Leads (Continued) Wire each conductor into the terminal block by pressing down on an orange tab, inserting the bare end of the conductor into the terminal block, and then releasing the tab Conductors are wired as follows: RED = VW+ BLACK = VW–...
  • Page 24 Connecting Sensors to Nodes: Bare Leads (Continued) Gently pull on each conductor to make sure it is secure Tighten the cable gland nut until it firmly grips the outer jacket of the cable Gently pull on the sensor cable to make sure it is held in place by the cable gland Cable gland nut must be properly...
  • Page 25 Connecting Sensors to Addressable Sensor Nodes Addressable sensors with bare  leads are wired as follows: GREEN = 485– RED = 12V BLACK = GND Addressable sensors that have a  bulkhead connector attached are connected in the same manner as previously discussed...

  • Page 26: Final Steps

    Final Steps...

  • Page 27: Completing The Installation

    Completing the Installation Complete the following with the Supervisor and the Node: Place the supplied desiccant packs inside the enclosure Make sure the cover gasket and the mating ridge on the enclosure are clean, and that the gasket is properly seated inside the groove Place the cover on the unit Tighten cover screws slowly, working in a diagonal pattern to...
  • Page 28 Mounting The mounting bracket makes it  easy to attach GeoNet devices to a wall, using bolts screws or onto a pole, using (B), a Hose Clamp , or U-bolts (Mounting hardware not included) Devices should be mounted  vertically, with the antenna pointing up...

  • Page 29: Computer Connection

    Computer Connection Connect the Network Supervisor to a computer using the factory supplied cable Read the Agent Software tutorial to learn how to install and use ’s Agent data GEOKON collection software...
  • Page 30  The GEOKON® logo and word mark are registered trademarks with the United States Patent and Trademark Office. GEOKON maintains an ongoing policy of design review and reserves the right to amend products and specifications without notice. ©GEOKON. All Rights Reserved. | Rev-A-4/6/2020...
