Excel Life
TM
Time Delay Switch
EM802TD
Technical characteristics
Incandescent
+ 50
C
o
+ 0
C
o
1 x 2.5 mm
2
2 x 1.5 mm
2
230 - 240V a.c.
50Hz
Max load
Minimum load = 10VA for all load types
* Electronic ballast only
Wiring
● Connect optional
Momentary Push
Switches (EM870X)
to enable switching from
multiple locations.
Important:
An unlimited number of EM870X can be connected to an EM802TD.
However, the total length of the load wire used to interconnect all of the EM870X should not exceed 50 metres.
Halogen
Fluorescent
tube
400VA*
400W
400W
EM802TD
ACTIVE
LOOP
LOAD
Wirewound
Electronic
Compact
transformer
transformer
Fluorescent
400VA
ACTIVE
MOMENTARY PUSH SWITCH
EM870X
LOAD
NEUTRAL
LED
Fan
motor
400VA
400VA
