Tire Linc
Tire Pressure & Temperature
Monitoring System 2.0
Installation and Owner's Manual
(For Aftermarket Applications)
Tire Linc
Tire Pressure &
Temperature
Monitoring System 2.0
Installation and Owner's Manual
(For Aftermarket Applications)
Part #
Part #
2020106863
2020106299

Introduction

®
Tire Linc
is a tire pressure and temperature monitoring
system (TPMS). The TPMS issues an alert via the
OneControl
1
temperature falls out of the programmable range.
1
2

Key System Components

2
• Sensors - Stem mount, 188 psi maximum pressure
reading, -58 to 401 °F (-50 to 205 °C) temperature
3
measurement range.
3
• Repeater - Receives sensor data, communicates with
4
Phone App via Bluetooth Low Energy (BLE).
4
6
• Repeater Dock - Provides power to repeater, which
7
. . . . . . . .
"docks" to this base.
9
• OneControl App - Displays real-time tire pressures,
10
temperatures and visual alerts for faults.
12
12
NOTE: Images used in this document are for reference
12
only when assembling, installing and/or operating this
12
12
product. Actual appearance of provided and/or purchased
parts and assemblies may differ.
12
1
®
®
Tire Linc Aftermarket Kit
Tire Linc Aftermarket Kit
Description
Description
®
Tire Linc
4-stem sensor kit
®
Tire Linc
stem sensor 2-pack; for spare sensors
or triple axle trailer
®
app when a trailer's tire(s) pressure or
CCD-0003848
Rev: 05.01.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tire Linc 2020106863 and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert Components Tire Linc 2020106863

Summary of Contents for Lippert Components Tire Linc 2020106863

  • Page 1: Table Of Contents

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Tire Linc Aftermarket Kit Tire Linc Aftermarket Kit Part # Part # Description...

  • Page 2: Safety

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Parts List Additional information about this product can be obtained from lci1.com/support or by using the myLCI app. Replacement kits can be ordered from https://store.lci1.

  • Page 3: Resources Required

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Resources Required ® • OneControl • Cordless or electric drill or screw gun • Appropriate drive bits • #8 x ” self-tapping pan head screws •...

  • Page 4: Installation And Setup

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Installation and Setup Connect One Control App to Repeater Snap the repeater (Fig.2A) into the dock (Fig.2B). 1. Download the LCI OneControl app (Fig.3) for either an NOTE: The dock is keyed and the repeater can only be iOS or Android smart phone.
  • Page 5 Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) 5. Select the “Add an accessory” button (Fig.6A). 3. Follow the app’s installation prompts to configure the OneControl app. NOTE: Optionally, press the Pair Mode button (Fig.2D) on the Repeater and look for TireLinc in the app’s listing.

  • Page 6: Stem Sensor Pairing Sequence

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) 7. Select a vehicle class (Fig.8) and press continue. Stem Sensor Pairing Sequence The pairing sequence for Stem Sensors (Fig.10) is as 8. Select a vehicle and press finish (Fig.9A). follows: 1.

  • Page 7: Use Smart Phone To Pair Sensors To Repeater

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Use Smart Phone to Pair Sensors to Repeater PRESSURE app screen. The app will display a list of tires with instructions to screw the first stem sensor onto the NOTE: If a wrong trailer type is chosen or there is a new Front Left tire stem (Fig.13).
  • Page 8 Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) 4. Press the Finished button (Fig.15A) to exit TIRE of the last received sensor data. Make sure sensors are PRESSURE Sensor Configuration mode. not removed during the learning process or the pressure limit values will be incorrectly estimated.

  • Page 9: Operation

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Operation When Stem Sensors are under pressure, data is transmitted to the repeater, when tires are: • moving/rotating, every one minute; • not moving/not rotating, every 15 minutes. 1.

  • Page 10: Tire Limits Example

    Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) F. High Temperature Threshold — posts the currently programmed high temperature limit for the selected tire. G. Maximum Temperature Change Limit — posts the UNDER OR OVER PRESSURIZED TIRES CAN currently programmed maximum +/- temperature change CAUSE UNFORESEEN, DETRIMENTAL EFFECTS...
  • Page 11 Tire Linc ® Tire Pressure & Temperature Monitoring System 2.0 Installation and Owner’s Manual (For Aftermarket Applications) Fig.21 Fig.19 Fig.22 Fig.20 lci1.com 574-537-8900 CCD-0003848 Rev: 05.01.20...

  • Page 12: Troubleshooting

    Tire Linc into configuration mode, which requires Manual information may be distributed as a complete uninstalling the stem sensors. document only, unless Lippert Components provides explicit consent to distribute individual parts. Factory Reset In the event a wrong trailer type is chosen or if there is a All manual information is subject to change without new trailer configuration, the settings can be reset.
