INSTALLER'S INSTRUCTIONS
CONTENTS
1
DESCRIPTION OF THE BOILER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 22
2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 31
3
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 35
4
USE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 32
It is advisable to check the following before turning on the boiler for the first time:
- Check that there are no liquids or flammable materials in the immediate vicinity of the boiler.
- Check that all electrical connections are secure and that the earth wire is connected to a proper grounding
system.
- Open the gas cock and check the seal on all connections, including the burner connection.
- Check that the boiler is set up to run on the type of gas available.
- Check that the discharge channel of the combustion waste is free.
- Check that gate valves are open, if there are any.
- Check that the heating system has been filled with water and that air has been bled out of it.
- Make sure that the circulator is not blocked.
- Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the
gas valve inlet.
FONDERIE SIME Co. Ltd based in Garbo Str. 27, Legnano (VR) in Italy certifies that their high-temperature water
boilers are CE labelled according to the Gas directives 30/396/ CEE and are equipped with a safety thermostat,
with a maximum calibration of 110 C,; furthermore they are excluded from the field defined by the Directive PED
97/23/CEE because these products meet the requirements provided in the article 1 comma 3.6 of the same
Directive.
IMPORTANT

Advertisement

loading
Need help?

Need help?

Do you have a question about the EKO OF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sime EKO OF Series

  • Page 1 – Purge the system, bleeding off the air present in the gas pipe by operating the pressure relief valve on the gas valve inlet. FONDERIE SIME Co. Ltd based in Garbo Str. 27, Legnano (VR) in Italy certifies that their high-temperature water boilers are CE labelled according to the Gas directives 30/396/ CEE and are equipped with a safety thermostat, with a maximum calibration of 110 C,;...
  • Page 2: Description Of The Boiler

    DESCRIPTION OF THE BOILER 1. 1 INTRODUCTION the European directives 90/396/ CEE, These boilers can be supplied with both 89/336/CEE, 92/42/CEE, natural (G20) and propane (G31) gas. ‘EKO OF’ is a premix boiler with natural 73/23/CEE and also the European Follow the instructions of this manual in gas draught in cast iron for heating with standards EN-656.
  • Page 3 BASIC COMPONENTS 1.3. 1 ‘EKO 3/6 OF – 3/4 OF PVA’ 1 Gas valve 2 Probe measurement sheath 3 Control Panel 4 Gas pressure switch with minimum rate (calibrated for G20 when upstream at 16,5 mbar and when downstream at 11,5 mbar) 6 Intermittent pilot 7 Combustion chamber door Burner manifold...
  • Page 4 TECHNICAL DATA 3 OF 3 OF PVA 4 OF 4 OF PVA 5 OF 6 OF Thermal Power Nominal 21,2 21,2 31,6 31,6 42,3 53, 1 Minimum (G20) 14,9 14,9 22,4 22,4 29,8 37,4 Minimum (G31) 18,0 18,0 27,0 27,0 36,0 45,2 Thermal Capacity...
  • Page 5 7 OF 8 OF 9 OF 10 OF 11 OF 12 OF Thermal Power Nominal 63,9 74,2 84,7 95,2 105,8 117,0 Minimum (G20) 44,9 52,3 60,5 68,0 73,5 83,0 Minimum (G31) 54,3 63,2 72,6 81,6 90,7 100,0 Thermal capacity Nominal 70, 1 81,5 93,0...
  • Page 6: Installation

    INSTALLATION Installation must be secure and has to be exclusively undertaken by a qualified specialist who will comply with all the H on the basis of the total instructions contained in this manual. thermal capacity: Moreover installation must be in com- –...
  • Page 7 The main factors to be taken into consi- must take into account the external tem- has to be ordered from SIME.
  • Page 8 NOTE: SIME shall not accept any liabi- orange and brown (fig. 5). Connectors control panel. 1 Interference filter 2 Connectors of control unit (black/ red/ brown) 3 Electronic device FM 12 4 Boiler’s terminal board...
  • Page 9 2.6.2 Electric systems CODES OF SPARE CONNECTORS: J1 code 6293578 J2 code 6293579 Type QAC31 outdoor temperature probe (optional) Interference filter Type QAZ21 boiler immersion probe (optional) Main switch Type QAZ21 boiler immersion probe (optional) Gas valve coil Heating system pump (vers. “3/4 OF PVA”) Gas valve coil Boiler pump Gas thermostat...
  • Page 10 CONTROL UNIT gle or double phase regulator of one sin- for boiler, hot water tank and heating RVA 43.222 (fig.7) gle boiler or as a cascade regulator for system. the control of a maximum of 16 boilers. – Boiler overheating protection. All boiler functions can be controlled by –...
  • Page 11: Features

    FEATURES 3. 1 CONTROL BOX alternatively, the transformer has inertia) when the burner goes out. burnt out. The boiler is equipped with FM 12 elec- tronic control and protection. Ignition – No detection of flame SMOKE SAFETY DEVICE and flame detection are controlled by The continuous spark discharge of the ‘EKO 3/6 OF - 3/4 OF PVA’...
  • Page 12: Use And Maintenance

    75% (G20) and 85% (G31) of nominal output before the burner goes out completely. The operating pressures is calibrated by SIME in the factory. Consequently these operating pressures should not be altered. Only when you switch to another type of gas is it permitted to alter the operating pressures (Table 1).
  • Page 13 4. 1 . 1 Adjusting maximum pressure Proceed as follows to set the maximum pressure (fig. 10): - Connect the column test pressure to Lock nut the socket which, in the case of the Coil ‘3/6 OF-3/4 OF PVA’ models, is loca- Adjusting maximum pressure ted on the burner manifold.
  • Page 14 USER’S INSTRUCTIONS WARNINGS – In case of fault and/or incorrect equipment operation, deactivate the boiler, without making any repairs or taking any direct action. Contact Authorised Technical Personnel. – The installation of the boiler and any servicing or maintenance job must be carried out by qualified personnel. Under no circumstances, should the devices sealed by the manufacturer be tampered with.
  • Page 15 At the end of each heating season, it is essential to have the boiler thoroughly checked and cleaned. Cleaning and maintenance must be carried out exclusively by SIME’s authorized technical staff. The boiler is equipped with a supply electric cable. Should this require replacement, contact exclusively Fig.
  • Page 16 CONTROL SYSTEM In order to get the highest potential out of the “RVA 43.222” regulator follow the instructions given below: TO TURN ON THE HEATING IF THE ROOMS ARE TOO HOT OR TOO COLD – Turn on the main switch. –...
